Installation and Operating Instructions
An accredited competent person must carry out the installation of this
appliance; alternatively, your local Building Control Officer can approve the
completed installation, should a non-accredited engineer undertake the
installation. It is an offence, under UK law, not to comply with this advice.
Please hand these instructions to the stove user when the installation is
complete. Leave the system ready for operation and instruct the user in the
correct use of the appliance and operation of controls.
JINHCR03 Rev A 18/07/12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hunter HAWK 3
Summary of Contents for Hunter HAWK 3
- Page 1 H A W K 3 M U L T I F U E L C L E A N B U R N S T O V E Installation and Operating Instructions An accredited competent person must carry out the installation of this appliance;...
-
Page 2: Technical Specification
Hawk 3 CE Technical Specification Stove Mass 62 kg Wood Total Efficiency 70.9 % Nominal Heat Output 4.1 KW Mean CO Emission (at 13% O2) 0.24 % Mean Flue Gas Temperature 270 °C Flue Gas Mass Flow 5.6 g/s Ancit Total Efficiency 66.7 %... -
Page 3: Important Warning
Assembly Instructions PLEASE READ THESE INSTRUCTIONS CAREFULLY It is important that your stove is correctly installed, as Hunter Stoves Limited cannot accept responsibility for any fault arising through incorrect use or installation. Important Warning This stove must not be installed into a chimney that serves any other heating appliance. -
Page 4: Fire Bricks
Fire Bricks The Fire Bricks, in this appliance, are factory fitted. The following set of photos show the removal sequence that you will need to employ when servicing your Hunter Stove. Side Bricks Remove all the Riddling Bars and Door Seal Bar. -
Page 5: Health And Safety Precautions
These instructions cover the basic principles to ensure satisfactory installation of the stove, although detail may need slight modification to suit particular local site conditions. In all cases the installation must comply with current Building Regulations, Local Authority Byelaws, European and national standards and other specifications or regulations as they affect the installation of the stove. -
Page 6: Installation
Installation Chimney The chimney height and the position of the chimney terminal should conform to Building Regulations. Check that the chimney is in good condition, dry, free from cracks and obstructions. The diameter of the flue should not be less than 125mm and not more than 200mm. If any of these requirements are not met, the chimney should be lined by a suitable method. -
Page 7: Material Clearances
Material Clearances The stove can be recessed in a suitable sized fireplace but a permanent free air gap of at least 150mm on top and 50mm (although we recommend 150mm) around the sides and 50mm at the back of the stove to obtain maximum heat output and for access to the rear of the stove. All non-combustible walls closer than 300mm to the stove should be at least 75mm thick. -
Page 8: Commissioning And Handover
Commissioning and Handover Upon completion of the installation, allow a suitable period of time for any fire cement and mortar to dry out. A small fire may then be lit and checked to ensure the smoke and fumes are taken from the stove up the chimney and emitted safely to atmosphere. -
Page 9: Operating Instructions
Operating Instructions This appliance is not suitable for use in a shared flue This appliance should not be operated with the doors open Aerosol Sprays Do not use an aerosol spray on or near the stove when it is alight. Air Controls This stove has been designed to burn cleaner and more efficiently than a conventional wood burning stove. -
Page 10: Multifuel Grate
Multifuel Grate Your Hunter Stove is fitted with a locomotive type grate. So that de-ashing can be carried out cleanly and easily, it is riddled from the outside of the stove with the doors closed. The grate is designed to burn both wood and solid fuels. - Page 11 Burn only dry, well-seasoned wood, which should have been cut, split and stacked for at least 12 months, with free air movement around the sides of the stack to enable it to dry out. Burning wet or unseasoned wood will create tar deposits in the stove and chimney and will not produce a satisfactory heat output.
-
Page 12: Safety Notes For Your Guidance
Safety notes for your guidance FIRES CAN BE DANGEROUS – Always use a fireguard in the presence of children, the elderly or the infirm. The fireguard should be manufactured in accordance with BS 6539 – Fireguards for use with solid fuel appliances. DO NOT OVERFIRE –... -
Page 13: General Maintenance
Rope Check the rope around the door and glass. If the rope is becoming detached, use Hunter Stoves rope glue to reattach it. If the rope is in a poor condition, a replacement rope kit may be ordered from the Hunter Stoves spares range. -
Page 14: Chimney And Flue Ways
Chimney and Flue ways It is important that the chimney, flue ways and any connecting flue pipe are swept regularly. This means at least once a year for smokeless fuels and at least twice a year for wood and other fuels. The baffle will need to be removed from its supports in order to sweep the chimney (see assembly instructions). -
Page 15: Stove Spares
STOVE SPARES Only Hunter Stoves authorised spares should be used with this stove STANDARD DOOR Door – Standard (HCR06/037) Door Catch Assembly (DCH4) Door Glass (HCR06/039) Glass Clip (HHR08/164) Door Handle Glass Clip Screw (HCR06/059) (FSJM05008SS) Primary Air Spinner Rope Sealing Kit... - Page 16 STOVE BODY ASSEMBLY – PART SECTION - MULTIFUEL Hinge Gasket (HCR03/039) (CH05/042) Hinge Pin (FRRE10-1.50) Side Brick – M/F Baffle (HCR03/044 (HCR03/047) Side Plates Tertiary Air Bar (HCR03/031 A/B) (HCR03/046) Rear Brick – M/F (HCR03/048) Door Seal Bar (HCR06/030) Riddling Support (HCR03/020) Riddling Bar - Upper Ashpan...
