- Page 1 1000TVL VACRON-P Color Camera 2013. V1.0 User Manual...
-
Page 2: Table Of Contents
1000TVL VACRON-P Camera Index FEATURES ........................1 Specifications ........................2 Structure of Product ......................3 OSD Operation ......................... 4 (1.1) AE Mode Setting ................... 4 (1.2) Standard AE ....................4 (1.3) SWDR ......................5 (1.4) BLC ....................... 5 (1.5) HLC ....................... 6 (1.6) -
Page 3: Features
A. FEATURES 1/3” CCD High Solution Optics Double Frequency WDR Color Camera High Resolution Color 1000TVL 2D/3D Noise Reduction (HDNR) Optics Double Frequency WDR(128dB) Digital Slow Shutter from x2 up to x512 (Max) Adaptive Backlight compensation function ( BLC ) / Anti-Headlight (HLC) ... -
Page 4: Specifications
1000TVL VACRON-P Camera B. Specifications Video System NTSC Pick Up Element SONY 1/3” CCD Image Sensor Image Signal Process Digital Signal Processor Number Of Pixels 1020 (H) × 508 (V) 1024 (H) × 596 (V) Picture Elements Approx. 520K Approx. 610K... -
Page 5: Structure Of Product
1000TVL VACRON-P Camera C. Structure of Product Box Camera OSD operation Auto Iris Lens Set up / Up / Right Connector / Left / Down Power Indicator Power Input Video Out DC12V/AC24V... -
Page 6: Osd Operation
1000TVL VACRON-P Camera D. OSD Operation ■ Main menu ■OSD Setup Setup: 1.Click one time to enter the Main menu Click twice ( to Exit OSD menu, Reload Fty , Return to Previous page, Exit & Save) UP / Down: Selection. -
Page 7: (1.3) Swdr
1000TVL VACRON-P Camera (1.3) SWDR Auto switch: Set to Auto/On Level: Value 0~10 Set the ratio of WDR. Small value will have more ratio for the outdoors; in the other hand, big value will have more ration for the indoors. -
Page 8: (1.5) Hlc
1000TVL VACRON-P Camera Symbol will be shown on the upper left corner of Live view. Normal Back light compensation (1.5) High light compensation Set Range: Click Right button to enter the menu, press SETUP button in order to set up next corner point. (in this area, any brighter... -
Page 9: (1.6) Demist
1000TVL VACRON-P Camera (1.6) Demist Demist: Set the level of Demist. If set Auto, the DSP will turn on/off the function and decide the level of demist (Auto, Low, Middle, High). 3D-NR: On/Off the 3D-NR function Symbol... -
Page 10: Color Adjust
1000TVL VACRON-P Camera 2. Color Adjust Color adjust settings (2.1) White Balance Tracking Mode 2-8.5k、Tracking Mode 2-10k (2.2) Brightness 0~99 (2.3) Color-Red Red (0~99) (2.4) Color-Green Green (0~99) (2.5) Color-Blue Blue (0~99) (2.6) Contrast 0~99 (2.7) Saturation 0~99 (2.8) CR suppress... -
Page 11: Image Adjust
1000TVL VACRON-P Camera 3. Image Adjust Image adjust settings (3.1) Day & Night Mode: Auto-Progressive Like human eyes Mode: B/W Change to B/W mode Color burst: On/Off Color burst... - Page 12 1000TVL VACRON-P Camera Mode: Color Change to Color mode. Mode: Ext For external control, the input pin is the PIO 0 on the PCB board. Color burst On/Off Color burst IR Input level Set Input level (High, Low) to make it work! iii.
-
Page 13: (3.2) Digital Slow Shutter
1000TVL VACRON-P Camera Mode: Auto-general When reaching assigned brightness, change to BW. i. Color burst On/Off Color burst ii.Delay control Delay time for changing Day/Night mode (0~255） iii. Day→Night Set the start point from Color mode to BW mode. -
Page 14: (3.3) 3D Dnr
1000TVL VACRON-P Camera (3.3) 3D DNR (0~3), To reduce image Noise DNR OFF： Noisy 3D-DNR On/Auto Clearly (3.4) 2D DNR 0~32 (3.5) Sharpen 0~7, The higher value, the stronger effects. (3.6) FC suppress 0~15, The higher value, the stronger effects. -
Page 15: (4.2) D-Zoom
1000TVL VACRON-P Camera Set Area Motion detection area set up ( Click Right button to set up / click to remove the area and Exit). Sensitivity (-2~2), The higher number, the more sensitive. Warning Trigger Level: (High/Low/Off) An alarm outputs when a motion is detected. -
Page 16: (4.3) Privacy Mask
1000TVL VACRON-P Camera (4.3) Privacy mask Opacity (0~3), Mask transparency setting. Mask select (1~8), Select and set up the mask, maximum 8. Set mask range Mask range set up (click Right button to set up) Switch ON/OFF ... -
Page 17: System Setting
1000TVL VACRON-P Camera E. System setting System setting (1.1) Lens Mode: To select lens type, DC in door/ DC outdoor/ Manual. Brightness: only be activated with DC IRIS (-50~50). Aperture speed: only available for Lens of DC IRIS (0-7) ... -
Page 18: Attachment A: Utc Controller Installation
1000TVL VACRON-P Camera F. Attachment A: UTC Controller Installation... - Page 19 FUHO TECHNOLOGY Co., LTD No. 30, Lane 726, Jinma Rd, Sec. 3, Chang Hua City, Taiwan. TEL:886-4-751-2881 FAX:886-4-751-5860 Made in Taiwan http://www.vacron.com...
