- Page 1 User Manual DuraPANEL Series DuraPANEL 24” DuraPANEL 26”...
- Page 2 Disclaimer ISIC A/S makes no representation or warranties with respect to the contents or use of this manual, and specifically disclaims any express or implied warranties of merchantability or fitness for any particular purpose. Further, ISIC A/S reserves the right to revise this publication and to make changes to its content at any time, without obligation to notify any person or entity of such revisions or changes.
-
Page 3: Table Of Contents
DURAPANEL CONNECTIONS .................. 6 DURAPANEL FRONT PANEL CONTROLS (ECDIS AND RADAR) ........ 7 CONNECTOR PIN-OUT ................... 8 TECHNICAL SPECIFICATIONS DURAPANEL 24” ............. 9 TECHNICAL SPECIFICATIONS DURAPANEL 26” ........... 10 MECHANICAL OUTLINE DURAPANEL 24” ............. 11 MECHANICAL OUTLINE DURAPANEL 26” ............. 12 10 DURA COMMUNICATION PROTOCOL .............. -
Page 4: Features
Features Congratulations with your purchase of a DuraPANEL. This short form manual is designed to get you started working with your new DuraPANEL. The DuraPANEL series of Panel Computers are all designed for the demanding operating conditions at sea. The DuraPANEL series are tested for full compliance to marine-standards IACS E10 and IEC 60945. -
Page 5: General Considerations On Installation And Operation
The DuraPANEL is designed to work at conditions according to IEC 60945. However, keeping the temperature and vibration level at a minimum will extend the life time of the product. ISIC recommend operating this product at normal room temperature (20-25 °C), with the lowest level of vibration and humidity. -
Page 6: Durapanel Connections
DuraPANEL connections Below is a view of optional connections to the monitor. The default inputs are: power, RS- 232, DVI and VGA. DuraPANEL24 connections: RS232 LAN2 USB 3.0 x 4 LAN1 POWER DC POWER AC HDMI LINE OUT MIC IN CHASSIS DuraPANEL26 connections: RS232... -
Page 7: Durapanel Front Panel Controls (Ecdis And Radar)
DuraPANEL front panel controls (ECDIS and Radar) The front panel controls are illuminated and will be dimmed continuously depending on changing of backlight brightness. DuraPANEL front: ECDIS LED STATUS LED DOWN POWER STATUS: This LED will illuminate green when the monitor is powered on and red when the monitor is powered down. -
Page 8: Connector Pin-Out
Connector pin-out RS-232 Pin1 RS-232 SUB-D 9-pol male DuraPANEL TX DuraPANEL RX Mating part: SUB-D 9 pole female, Norcomp 172-E09-20201 or equivalent. Power input DC (optional) The nominal input power voltage is 24V (18-36VDC). The input is galvanic isolated and protected against reverse polarity. -
Page 9: Technical Specifications Durapanel 24
Technical specifications DuraPANEL 24” DuraPANEL - General ® CPU: Intel Core® i3-4330TE– 2,4 GHz 2 cores, 4 threads (CPUMark 3,224) ® Optional Intel Core i5-4590T 2,0 GHz 4 cores, 4 threads (CPUMark 5,758) ® Optional Intel Core i7-4770TE 2,3 GHz 4 cores, 8 threads (CPUMark 8,800) ®... -
Page 10: Technical Specifications Durapanel 26
Technical specifications DuraPANEL 26” DuraPANEL - General ® CPU: Intel Core® i3-4330TE– 2,4 GHz 2 cores, 4 4hreads (CPUMark 3,224) ® Optional Intel Core i5-4590T 2,0 GHz 4 cores, 4 threads (CPUMark 5,758) ® Optional Intel Core i7-4770TE 2,3 GHz 4 cores, 8 threads (CPUMark 8,800) ®... -
Page 11: Mechanical Outline Durapanel 24
Hole position: ` 0,1 Sheet: 1 of 1 Angle, straightness and flatness: DS/ISO 2768-H Designed by 22-05-2015 Approved by ISIC A/S, Edwin Rahrs Vej 54, DK-8220 Brabrand. Tlf.: +45 70207077. Web: www.isic.dk Mechanical outline DuraPanel WS Glass 24'' Subject: Drawing no. Rev. Scale:... -
Page 12: Mechanical Outline Durapanel 26
Sheet: 1 of 1 Drawing size: Angle, straightness and flatness: DS/ISO 2768-H Designed by 23-06-2015 Approved by ISIC A/S, Edwin Rahrs Vej 54, DK-8220 Brabrand. Tlf.: +45 70207077. Web: www.isic.dk Subject: Drawing no. Rev. Scale: 07426-000 Mechanical outline DuraPanel Glass 26'' AC... -
Page 13: Dura Communication Protocol
[cm] distance [cm] (5.4°/H deviation or a (18°/H deviation or a horizontal magnetic flux of horizontal magnetic flux of 0.094µT) 0.313µT) DuraPANEL 24” DuraPANEL 26” Power Consumption Test object / condition Ptyp [W] Pmax [W] DuraPANEL 24” DuraPANEL 26”... -
Page 14: Troubleshooting
Send it to ISIC A/S for repair. Servicing the unit In case that the unit still fails after following the troubleshooting send the unit to ISIC for repair via our RMA service on our web. User Reference Manual – DuraPANEL series... -
Page 15: Isic Info / Support
During office-hours (Mo-Fr: CET 0800 - 1600) at +45 70 20 70 77 Service: Before shipment for service Request Return Material Authorization number at homepage www.isic-systems.com under AFTER SALES TECH SUPPORT RMA By mail to service@isic-systems.com User Reference Manual – DuraPANEL series... -
Page 16: Revision History
Revision history Rev A August 2015 First release User Reference Manual – DuraPANEL series PN: 07354-000 Rev A Page 16... -
Page 17: Appendix A: Pixel Policy
TFT display. To regulate the acceptability of defects and protect the end user, ISIC A/S complies with the ISO 9241-307:2008 standard. This standard recommends how many defects are considered acceptable in a display, before it should be replaced within the terms of the warranty. - Page 18 Pixel Pixel defect type 1 Pixel constantly lit Pixel defect type 2 Pixel constantly dark Pixel defect type 3a Pixel defect type 3b Sub-pixel/dot constantly lit Sub-pixel/dot constantly dark (red, blue, green) (red, blue, green) Cluster A cluster consists of 5 x 5 pixels. Cluster pixel defect type 1 Cluster pixel defect type 2 Pixels in a cluster area constantly lit...
- Page 19 Pixel faults accepted by ISIC A/S The maximum number of pixel faults that is considered acceptable at different screen resolutions is shown in the table below. This is the native resolution and not the resolution as adjusted by user. Class II...
-
Page 20: Appendix C: Declaration Of Conformity
Appendix C: Declaration of Conformity User Reference Manual – DuraPANEL series PN: 07354-000 Rev A Page 20... - Page 21 Edwin Rahrs Vej 54 DK-8220 Brabrand Denmark Web: http://www.isic-systems.com Email: service@isic-systems.com User Reference Manual – DuraPANEL series PN: 07354-000 Rev A Page 21...
