4.3.5 Firewall

4.3.5.1 MAC/IP/Port Filtering

Item Description
MAC/IP/Port
Select Enable or Disable the MAC/IP/Port Filtering function.
Filtering
Item Description
Source MAC
Fill in the MAC address of source NIC, to restrict data transmission.
address
Dest IP Address Fill in the IP address of destination, to restrict data transmission.
Source IP Address Fill in the IP address of source, to restrict data transmission.
Protocol Select the protocol that you want to restrict. There are four options: None, TCP,
UDP and ICMP.
Dest Port Range Fill in the start-port and end-port number of destination, to restrict data
transmission.
Source Port Range Fill in the start-port and end-port number of source, to restrict data transmission.
Action
Select Accept or Drop to specify the action of filtering policies.
Comment Make a comment for the filtering policy.
V3.0.0
