d. L2TP
If you select L2TP, please fill in these fields on next page.
Item Description
L2TP Server IP Allow user to make a tunnel with remote site directly to secure the data transmission
Address among the connection. User can use embedded L2TP client supported by this router to
make a VPN connection. If you select the L2TP support on WAN interface, fill in the
IP address for it.
User Name Fill in the user name and password to login the L2TP server.
Password Fill in the user name and password to login the L2TP server.
Address Mode Static: To configure the IP address information by manually, please fill in the related
setting at below.
Dynamic: The option allows the machine to get IP address information automatically
from DHCP server on WAN side.
IP Address Fill in the IP address for WAN interface.
Subnet Mask Fill in the subnet mask for WAN interface.
Default Gateway Fill in the default gateway for WAN interface out going data packets.
Operation Mode Keep Alive: Keep the L2TP connection all the time. Please also configure the Redial
Period field.
Manual: Let user connect the L2TP connection manually.
When you finish these settings, then click Next button to jump at Step3.
