Aven Mighty Scope 1.3M Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

High Performance
Precision Tools
FOR MICROCOPY
INSPECTION & ASSEMBLY
In Industrial , Scientific
& Research Applications
Visit us at www.TestEquipmentDepot.com
99 Washington Street
Melrose, MA 02176
Phone 781-665-1400
Toll Free 1-800-517-8431

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mighty Scope 1.3M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aven Mighty Scope 1.3M

Summary of Contents for Aven Mighty Scope 1.3M

  • Page 1 High Performance Precision Tools FOR MICROCOPY INSPECTION & ASSEMBLY In Industrial , Scientific & Research Applications 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com...
  • Page 2 Mighty Scope 1.3M Instruction Manual...

  • Page 3: Table Of Contents

    Contents Features Specifications Contents PC System Requirements Driver Installation Procedure Getting Started Software Installation (PC) Mighty Scope Controls MacroViewer Software Function Key Lists Compare Video Setup Preview picture mode Measuring Software Installation (Mac) MacroViewer Software (Mac) Function Key Lists Compare Video Setup Measuring Draw (Mac)

  • Page 4: Features

    Features Applications The Mighty Scope digital microscope provides a Science Engineering adjustable magnification range, and the 500X model Work Dermatology provides 500X(fixed) magnification. The built-in brightness Detailed Repair adjustable LEDs provides proper illumination of the object. Assembly The magnified image can be viewed, captured and Quality Control recorded directly from the computer screen.

  • Page 5: Pc System Requirements

    PC System Requirements Getting Started Stand Assembly • Chip set: Pentium 4 2.4GHz CPU or equivalent, AMD Phenom II or above, Northbridge Intel ® i945GZ or above • RAM: 512MB DDR or above • USB: At least one USB 2.0 •...

  • Page 6: Software Installation (Pc)

    Software Installation (PC) 1. Insert the software installation CD into the CD-ROM drive. The installation program will appear automatically on your screen. (If the installation program doesn’t appear, open the MicroViewer folder and double click AutoRun.exe) 2. Click “Install MicroViewer 1.3MP” button (Fig.1). Connect the scope holder to the vertical post and tighten set-screw...
  • Page 7 Software Installation (PC) cont. 3. Install the MicroViewer 1.3MP program and restart the computer. 1 . 3MP 1 . 3MP 1 . 3MP 1 . 3MP 1 . 3MP 1 . 3MP 1 . 3MP...

  • Page 8: Mighty Scope Controls

    Mighty Scope Controls 4. Connect the Might Scope to the computer (Fig. 2). 5. Double Click the [ MicroViewer 1.3MP ] software, the start-up screen will show up (Fig. 3). 6. Place the camera on or above the object to be FIG.
  • Page 9 Mighty Scope Controls 11. When magnifying an object, adjust the focus knob slightly to the left or right, depending on the working distance, until image is clear (Fig. 9). 12. If the object has too much relief or if a higher FIG.

  • Page 10: Microviewer Software

    MicroViewer Software 1. Double click the [ MicroViewer 1.3 ] icon on your desktop (Fig. 14). • Make sure the Mighty Scope is plugged into the USB port. FIG. 14 • Key in the Serial Number (which can be found on the outside of the CD envelope) or just press the “Evaluate”...

  • Page 11: Compare

    MicroViewer Menu Snapshot Zoom in/out Take a picture. Select the zoom-in and zoom-out function on a live image or on (Saved as a BMP file) captured pictures. The maximum Shortcut key: F3 magnification is 6x. The arrow keys *The max resolution for software on the keyboard will move the image.
  • Page 12 Micro Viewer Comparison Mode 1. Plug two microscope USB cables into the PC USB ports (Fig. 17). 2. Click the Compare button, and the compare window will appear on the screen. The live image FIG. 17 shows in the left zone (Fig. 18). *For the best results screen resolution requirement should be at least 1440x900 pixel 1.
  • Page 13 MicroViewer – Compare Menu 1. Why does the combined Camera 2 picture become distorted Enable/Disable the image when I preview the image? of the second microscope. A: It will distort the image because of the ratio on the Snapshot screen. Please go to the Take a picture.

  • Page 14: Video Setup

    Video Setup - Overview Click the Setup button for the video dialogue box (Fig. 20). 1. Source: User can to choose the image source if there is multiple microscopes connected to the PC. 2. Video Format: Supports resolution options: 640x480 | 1280x1024. *Both the Snapshot and Record format will be changed 3.

  • Page 15: Preview Picture Mode

    Preview – Picture Mode Drag the picture from the list bar to the live zone or just double click the picture in the list bar. The Image will show in the live zone for editing. (Fig. 21). Drawing mode The Drawing mode button opens Microsoft Paint to draw on the picture.
  • Page 16 Measuring -Overview Click the Measurement button to open the measurement window. The image will be frozen. You can calibrate or measure the frozen image (Fig. 22). VGA monitor size: Select the monitor size. H/V ratio: Select the monitor’s correct aspect ratio to insure correct measurements Calibrate: Adjust the calibration.
  • Page 17 Measuring - Calibration 1. Place a scale under the camera and adjust the focus knob until the image is sharp (Fig. 23). 2. Click the “Snapshot” button to capture the picture, double click this picture in the list bar. 3. Click the “Measurement” button to open the Measurement Window.
  • Page 18 Measuring - Angles 1. Click the “Measurement” button to open the Measurement Window. 2. Click the check box next to “Measure.” (Fig. 26) 3. Select the mode “Angle” from the drop down. 4. Set the “Accuracy” to the number of decimal points displayed in the measurement.
  • Page 19 Measuring - Circle/Ellipse 1. Click the “Measurement” button to open the Measurement Window. 2. Check the “Measure” box (Fig. 31). 3. Select the“Circle” Mode for circle or “Ellipse” mode for ellipse. 4. Check the “Cross” function to display crosshairs. FIG. 31 5.
  • Page 20 Measuring - Line 1. Click the “Measurement” button to open the Measurement Window. 2. Check the “Measure” box. (Fig. 35). 3. Select the “Line” Mode. 4. Hold the right button of the mouse at the first FIG. 35 measurement point. (Fig. 36). 5.
  • Page 21 Measuring - Rectangle 1. Click the “Measurement” button to open the Measurement Window. 2. Check the “Measure” box, 3. Select the “Rectangle” Mode (Fig. 39). 4. Click and hold the right button of the mouse at corner of the object (Fig. 40). FIG.
  • Page 22 Measuring - Triangle 1. Click the “Measurement” button to open the Measurement Window. 2. Check the “Measure” box. 3. Select the “Triangle” Mode. (Fig. 43). 4. Click and hold the right button of the mouse at the first point of the object. (Fig. 44). FIG.
  • Page 23 Measuring - Radius/Arc 1. Click the “Measurement” button to open the Measurement Window. 2. Check the “Measure” box. 3. Select the “3DotRadius” Mode (Fig. 48). 4. Click and hold the right button of the mouse at the first point of the arc (Fig. 49). FIG.
  • Page 24 Software Installation (Mac) 1. Insert the software installation CD into the CD-ROM drive. The installation program will appear automatically on your screen. 2. Drag the “MicroViewer” icon to the Applications folder. 3. Open your application folder and double-click to open the MicroViewer software. 4.
  • Page 25 MicroViewer Software (Mac) 1. Double click the [ MicroViewer ] icon on your desktop or in your Applications folder (Fig. 53). • Make sure the Mighty Scope is plugged into the USB port. 2. The MicroViewer window will show up and you should FIG.
  • Page 26 MicroViewer Menu (Mac) Preview Draw Input words, draw lines, circles Enable the live image of the and freehand. microscope. (Saved as a JPG file) Measurement Snapshot Measure lines, circles, angles, Take a picture. rectangles or triangles (Saved as a JPG file) (Please see the Measurement Section for Record more detail)
  • Page 27 Micro Viewer Comparison Mode (Mac) 1. Click the Compare button and the compare window will appear on the screen. The live image shows on the left side (Fig. 55). 2. The live image shows in the left side. Click on the right image and double click a picture or a video in the list bar.
  • Page 28 Media Setup - Overview (Mac) Click the Preference button for the media compression type of video. dialogue box (Fig. 57). Time lapse: If you need time-lapse function, check the “Enable Time Lapse“ Video source: Allows the user to box and select the time-lapse ratio. (i.e. choose or switch the image source if If you choose”60:1”...

  • Page 29: Measuring

    Measuring -Overview (Mac) Click the Measurement button to open the measurement dialogue window (Fig. 58a | Fig. 58b). Calibrate: Click “Calibrate” button at the top of the dialogue box to enter calibration mode. Reference Unit: Select the measurement unit for calibration. There are three different units: mm/inch/mil Reference Size: Select the unit of measurement or calibration.

  • Page 30: Measuring

    Measuring - Calibration (Mac) 1. Place a scale under the camera and adjust the focus knob until the image is sharp (Fig. 59). 2. Click the “Measurement” button to open the Measurement Window. FIG. 59 *You must calibrate again if you change the distance, magnification, or resolution.
  • Page 31 Measuring - Angles (Mac) 1. Click the “Measurement” button to open the Measurement window. 2. Click the “Measure” button. Change the measure mode to “Angle.“ (Fig. 62) 3. Click and hold the mouse button at the first point of the angle. (Fig. 63) FIG.
  • Page 32 Measuring - Circle/Ellipse (Mac) 1. Click the “Measurement” button to open the Measurement window. 2. Click the “Measure” button. Change the measure mode to “Circle or Ellipse.“ (Fig. 67). 3. Click and hold the button of the mouse at the edge of the object (Fig.
  • Page 33 Measuring - Line (Mac) 1. Click the “Measurement” button to open the Measurement window. 2. Click the “Measure” button. Change the measure mode to “Line.“ (Fig. 71) 3. Click and hold the mouse button at the first measurement point. (Fig. 72). FIG.
  • Page 34 Measuring - Rectangle (Mac) 1. Click the “Measurement” button to open the Measurement window. 2. Click the “Measure” button. Change the measure mode to “Rectangle.“ (Fig. 75) 3. Click and hold the mouse button at corner of the object (Fig. 76). FIG.
  • Page 35 Measuring - Triangle (Mac) 1. Click the “Measurement” button to open the Measurement window. 2. Click the “Measure” button. Change the measure mode to “Triangle.“ (Fig. 79) 3. Click and hold the mouse button at the first point of the object. (Fig. 80). FIG.
  • Page 36 Measuring - 3-Dot-Radius (Mac) 1. Click the “Measurement” button to open the Measurement window. 2. Click the “Measure” button. Change the measure mode to “3DotRadius.“ (Fig. 84) 3. Click and hold the mouse button at corner of the object (Fig. 85). FIG.

  • Page 37: Draw (Mac)

    Draw (Mac) Click the Draw button to access the drawing menu and functions (Fig. 88). Draw Menu (Mac) Cursor Move the window Line Tool Draw lines with custom line weights and color Circle Tool Draw circles with custom line weights and color Delete Tool FIG.

  • Page 38: Faq

    99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com Q. After inserting the software installation CD into the CD-ROM drive, Q. After installing the why doesn’t the install start automatically? MicroViewer 5.0MP, why A: Due to the computer’s system security, many system’s software doesn’t the MicroViewer 1.3M disables the CD-R/USB Auto run function.
