Revo REHVD0309-1 Quick Installation Manual

1. Description
This manual applies to REHVD0309-1 network camera.
The network Camera provides a network service for a progressive-scan image sensor that can be
monitored on a real-time screen regardless of distance or location. By using its dedicated program,
many users are able to access the Network Camera at once, or a single user can monitor various
network cameras at the same time. It also enables users to play, store and retrieve a monitored image
by using a PC. All the settings and real-time monitoring screens are also provided through web access.
The Network Camera is fully featured for security surveillance and remote monitoring needs. It is
based on a DSP compression chip, and makes it available on the network as real-time, full frame rate
Motion JPEG and H.264 (or MPEG-4) video streams.
The alarm input and alarm output can be used to connect various third party devices, such as door
sensors and alarm bells.
• Installation Steps
Follow these steps to install the network camera on your local network (LAN):
1. Check the package contents against the list below.
2. Connect the Network Camera. See page 3.
3. Set an IP address. See page 4.
4. Set the password. See page 6.
• Package Component
The system comes with the following components:
Network Camera unit
• Contents in the installation CD
1. The REHVD0309-1 User's Manual
2. The SmartManager User's Manual
3. The Revo Remote Pro HD User's Manual
4. The SmartManager Installation software
5. The Revo Remote Pro HD Installation software
Note: Check your package to make sure that you received the complete system, including all
components shown above.
Installation CD Installation Guide
REHVD0309-1, Quick Installation Guide
Template Sheet Accessory Kit
