Omron M2 Classic Instruction Manual

Arm Cuffs:
If air starts to leak from the arm cuff, please replace with a new one.
Refer to "6. Optional Parts".
O
Digital Automatic
Blood Pressure Monitor
Model M2 Classic
Instruction Manual Medium cuff
O. Medium cuff: arm circumference 22-32 cm
P. Large cuff: arm circumference 32-42 cm
Introduction
2. Preparation
Thank you for purchasing the OMRON M2 Classic Digital Automatic Blood Pressure
Monitor.
2.1 Using the AC Adapter
The OMRON M2 Classic is a fully automatic blood pressure monitor, operating on the
oscillometric principle. It measures your blood pressure and pulse rate simply and quickly. Notes:
For comfortable controlled inflation without the need of pressure pre-setting or • Never plug or unplug the power cord with wet hands.
re-inflation the devices uses its advanced "IntelliSense" technology. • Use only the original AC adapter designed for this unit. Use of
unsupported adapters may damage the unit.
The unit also stores up to 30 measurements in memory.
1. Insert the AC adapter
Please read this instruction manual thoroughly before using the unit. For specific
information about your own blood pressure, CONSULT YOUR DOCTOR. plug into the AC adapter
jack on the right side of
Important Safety Information the main unit.
Consult your doctor prior to using in pregnancy or if diagnosed with arrhythmia
2.
Plug the AC adapter
or arteriosclerosis.
Please read this section carefully before using the unit. into an electrical outlet.
Warning:
To disconnect the AC adapter, unplug the AC adapter from the electrical outlet
• Indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injury. first and then immediately remove the AC adapter plug from the main unit.
(General Usage)
• Always consult your doctor. Self-diagnosis of measurement results and
self-treatment are dangerous.
2.2 Installing/Replacing the Batteries
• People with severe blood flow problems, or blood disorders, should consult a
doctor before using the unit, as cuff inflation can cause internal bleeding.
1. Turn the main unit upside down.
(AC Adapter Usage)
• Never plug in or unplug the power cord from the electric outlet with wet hands.
(Battery Usage)
2.
Slide the battery cover in the direction
• If battery fluid should get in your eyes, immediately rinse with plenty of clean
of the arrow while pressing the ribbed
water. Consult a doctor immediately.
Caution:
part of the cover.
• Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury to the user or patient or damage to the equipment or other property.
3. Install or replace four "AAA" size
(General Usage)
• Do not leave the unit unattended with infants or persons who cannot express their consent.
batteries so that the + (positive) and -
• Do not use the unit for any purpose other than measuring blood pressure.
(negative) polarities match the polarities
• Do not disassemble the unit or arm cuff.
• Use only the approved arm cuff for this unit. Use of other arm cuffs may result
indicated on the battery compartment.
in incorrect measurement results.
• Make sure that the air tube is not wrapped around other parts of your body
4.
when taking measurements at night. This could result in injury when the air Put the battery cover back in place.
pressure in the air tube is increased.
Slide the battery cover as indicated,
• Do not leave the cuff wrapped on the arm if taking measurements during the
until it clicks into place.
night. This could result in injury.
• Do not inflate the arm cuff over 299 mmHg.
• Do not use a mobile phone or other devices that emit electromagnetic fields,
Note: The measurement
near the unit. This may result in incorrect operation of the unit.
• Do not operate the unit in a moving vehicle (car, airplane). values continue to be
• To inflate the cuff manually, refer to Chapter 3.3. If the cuff is over inflated, it stored in memory even
can cause internal bleeding.
after the batteries are replaced.
(AC Adapter Usage)
• Use only the original AC adapter designed for this unit. Use of unsupported
2.3 Battery Life & Replacement
adapters may damage and/or may be hazardous to the unit.
• Plug the AC adapter into the appropriate voltage outlet. If the battery low symbol (
• Do not use the AC adapter if the unit or the power cord is damaged. Turn off
replace all four batteries at the same time.
the power and unplug the power cord immediately.
- When the battery low symbol (
(Battery Usage)
will still be able to use the unit for a short while. You
• If battery fluid should get on your skin or clothing, immediately rinse with
plenty of clean water.
should replace the batteries with new ones as soon as possible.
• Use only four "AAA" alkaline batteries with this unit. Do not use other types of batteries.
- When the symbol (
• Do not insert the batteries with their polarities incorrectly aligned.
batteries with new ones at once. Turn the unit off before replacing the batteries.
• Replace old batteries with new ones immediately. Replace all four batteries at
the same time.
• Remove the batteries if the unit will not be used for three months or more.
• Remove the batteries if the unit will not be used for three months or more.
• Dispose of batteries according to applicable local regulations.
• Do not use new and used batteries together.
General Precautions Four new "AAA" alkaline batteries will last for approximately 300 measurements,
• Do not apply strong shocks and vibrations to or drop the unit and arm cuff.
when used to take two measurements a day.
• Do not take measurements after bathing, drinking alcohol, smoking,
Since the supplied batteries are for monitoring use only, they may have
exercising or eating.
a shorter life and do not last for 300 measurements.
• Do not forcibly bend the arm cuff or bend the air tube excessively.
• When removing the air tube, pull on the air plug at the connection with the
main unit not the tube itself. 3. Using the Unit
• Do not inflate the arm cuff when it is not wrapped around your arm.
• Do not wash the arm cuff or immerse it in water. 3.1 Applying the Arm Cuff
• Read and follow the "Important information regarding Electro Magnetic
Compatibility (EMC)" in the Technical Data Section.
Be sure to wrap the arm cuff correctly so that you get accurate results.
• Read and follow the "Correct Disposal of This Product" in the Technical Data
Measurements can be taken in light clothing. However, please remove
Section when disposing of the device and any used accessories or optional parts.
thick clothes, such as sweaters, before taking a reading.
Note: You can take a measurement on either your left or right arm. The blood
1. Overview
pressure can differ between the right arm and the left arm and therefore
also the measured blood pressure values can be different. Omron
Main unit:
A E
recommends to always use the same arm for measurement. If the
values between the two arms differ substantially, please check with your
physician which arm to use for your measurement.
1.
Insert the air plug into the air jack
on the left side of the main unit.
D
F
C
B
2.
Apply the arm cuff to your upper arm. The air tube should be
A. Display D. AC adapter jack
centred on the inside of your arm and point down the inside of
B. O/I START button E. Battery compartment
C. M (Memory) button F. Air jack the arm, so that the air tube runs down the inside of your
forearm and is in line with your middle finger.
Display:
G
H
I K
L
J
M
N 3. When the cuff is positioned correctly, close the fabric fastener firmly.
G. Systolic blood pressure L. Pulse display
Taking a Reading on the Right Arm
H. Diastolic blood pressure M. Deflation symbol
I. Memory symbol N. Battery low symbol
Apply the cuff so that the air tube is
(Displayed when viewing
at the side of your elbow.
values stored in memory) Note: If your systolic or diastolic
J. Irregular heartbeat symbol pressure is outside the Notes:
K. Heartbeat symbol standard range • Be careful not to rest your arm on
1. Flashes during measurement (above 135/85 mmHg), the air tube, or otherwise restrict
2. If flashing after measurement the Heartbeat symbol ( ) the flow of air to the cuff.
complete indicates blood pressure will blink. Refer to • The cuff should be 1 to 2 cm above
out of recommended range "3.2 Taking a Reading". the elbow.
3.2 Taking a Reading
1.
Sit on a chair with your feet flat on
the floor and place your arm on a
P
Q table so that the arm cuff will be
Q
at the same level as your heart.
Keep still and do not talk during measurement.
2.
Press the O/I START button to turn the unit on.
R
R
Large cuff
Q. Air Tube
R. Air Plug
Note: To cancel a measurement, press the O/I START button to turn the
unit off and to release the air in the arm cuff.
3.
Check the measurement results.
The unit automatically stores blood
pressure and pulse rate into its memory.
Refer to "3.4 Using the Memory
Function".
Notes:
• Self-diagnosis of measured results and treatment are dangerous.
Please follow the instructions of your doctor.
• Wait 2-3 minutes before taking another blood pressure reading.
Waiting between readings allows the arteries to return to the condition prior
to taking the blood pressure measurement.
Important:
• If your systolic or diastolic pressure is outside
the standard range, the heartbeat symbol will
blink when the measurement result is displayed.
Recent research suggests that the following
values can be used as a guide to high blood
pressure for measurements taken at home.
Systolic Blood Pressure
Diastolic Blood Pressure
This criteria is for home blood pressure measurement.
• Your blood pressure monitor includes an irregular
heartbeat feature. Irregular heartbeats can influence
the results of the measurement. The irregular
heartbeat algorithm automatically determines if the
measurement is usable or needs to be repeated.
If the measurement results are affected by irregular
heartbeats but the result is valid, the result is shown together with the
irregular heartbeat symbol ( ).
If the irregular heartbeats cause the measurement to be invalid,
no result is shown. If the Irregular heartbeat symbol ( ) is shown
after you have taken a measurement, repeat the measurement.
If the Irregular heartbeat symbol ( ) is shown frequently, please
make your doctor aware of it.
4. Remove the arm cuff.
5.
) appears on the display, Press the O/I START button to turn the unit off.
Note: If you forget to turn the unit off, it will automatically shut itself off after
) starts to blink, you
five minutes.
) remains lit, the batteries are exhausted. You should replace the What is Irregular Heartbeat?
An irregular heartbeat is a heartbeat rhythm
that varies by more than 25% from the
average heartbeat rhythm detected
while the unit is measuring the systolic
and diastolic blood pressure.
If such an irregular rhythm is detected
more than twice during measurement,
the irregular heartbeat symbol ( )
appears on the symbol when the
measurement results are displayed.
What is Arrhythmia?
A heartbeat is stimulated by electrical signals that cause the heart to contract.
Arrhythmia is a condition where the heartbeat rhythm is abnormal due to flaws in
the bio-electrical system that drives the heartbeat. Typical symptoms are
skipped heartbeats, premature contraction, an abnormally rapid (tachycardia) or
slow (bradycardia) pulse. This can be caused by heart disease, aging, physical
predisposition, stress, lack of sleep, fatigue etc. Arrhythmia can only be
diagnosed by a doctor through a special examination.
Whether the appearance of the irregular heartbeat symbol (
indicates arrhythmia or not can only be determined by an examination and
diagnosis by your doctor.
Warning:
If the irregular heartbeat symbol ( ) is shown frequently, please make your doctor
aware of it. Conducting self-diagnosis and treatment based on measurement
results is dangerous. Be sure to follow the instructions of your doctor.
3.3 Instructions for Special Conditions
If your systolic pressure is known to be more than 170 mmHg, press
and hold the O/I START button until the arm cuff inflates 30 to
40 mmHg higher than your suspected systolic pressure.
1.
Press the O/I START button
1 - 2 cm
to turn the unit on.
Measurement starts.
2. When the cuff starts to inflate, press the O/I START button
and keep it pressed until the pressure is 30 to 40 mmHg
higher than your suspected systolic pressure.
Note: You cannot inflate the cuff above 299 mmHg. (An error will be displayed
1 to 2 cm
if you try to inflate the cuff above 300 mmHg.)
3.
Release the O/I START button when the cuff has been
inflated to the desired pressure.
The cuff starts to deflate and measurement starts.
4.
The rest of the procedure is the same as for normal
measurement. Refer to "3.2 Taking a Reading", steps 3 to 5.
Note: Do not apply more pressure than necessary.
3.4 Using the Memory Function
This unit has a memory capable of storing 30 sets of readings. Every
time you complete the measurement, the unit automatically stores the
blood pressure and pulse rate.
Note: When 30 sets of readings are stored in memory, the oldest set will be
deleted to store a new set.
1.
Press the Memory (M) button.
The result from the most recent measurement is displayed.
Systolic blood
pressure
Diastolic blood
pressure Important:
Pulse display
If your systolic or diastolic pressure is
outside the standard range, the heartbeat
symbol will blink when the measurement
result is displayed.
Refer to "3.2 Taking a Reading".
Note: If there are no measurements results
stored in memory, the screen to the right
is displayed.
2.
Press the Memory (M) button repeatedly to
cycle through the previous measurement
results.
The Memory number appears for a second
before the pulse rate is displayed.
Above 135 mmHg
The newest set is numbered "1".
Above 85 mmHg
At the end of the measurement, if an irregular heartbeat is
detected, the irregular heartbeat symbol will be displayed
with the result.
3.
Press the O/I START button to turn the unit off.
If you forget to turn the unit off, it will automatically shut
itself off after five minutes.
To Delete All the Values Stored in Memory
You cannot delete individual stored readings, all the
readings in the unit will be deleted.
1.
To delete stored readings, first press the Memory (M) button.
Then while holding it down, press the O/I START button
simultaneously for about 2-3 seconds. All readings will
then be deleted.
1
2
2. Press the O/I START button to turn the unit off.
Irregular Heartbeat If you forget to turn the unit off, it will automatically shut
itself off after five minutes.
Pulse
Blood
pressure
Irregular Heartbeat 4. Handling Errors and Problems
Short Long
4.1 Error Messages
Pulse
Blood
Error Display Cause Remedy
pressure
Carefully read and repeat the
Cuff is under inflated.
steps listed under section 3.3.
Repeat measurement. Remain
Movement during
still and do not talk during
measurement.
measurement.
) in the results
Insert the air plug securely.
Air plug disconnected.
Refer to section 3.1.
Arm cuff not applied Apply the arm cuff correctly.
correctly. Refer to section 3.1.
Clothing is interfering Remove any clothing
with the arm cuff. interfering with the arm cuff.
Air is leaking from the
Replace cuff with new one.
arm cuff.
Arm cuff has been Do not inflate the arm cuff
inflated above
above 299 mmHg.
299 mmHg.
Refer to section 3.3.
Replace all four "AAA"
Battery power is low. batteries with new ones.
Refer to section 2.2.
Blinks or appears
continuously
Contact your OMRON retail
Device error.
outlet or distributor.
4.2 Troubleshooting 7. Technical Data
Product Description
Problem Cause Remedy
Model
Apply the arm cuff
Display
Arm cuff not applied correctly.
Measurement Method
correctly. Refer to section 3.1.
Measurement Range
The reading is
Remain still and do not
Movement or talking
Memory
extremely low (or talk during
during measurement.
measurement. Accuracy
high).
Remove any clothing
Clothing is interfering Inflation
interfering with the arm
with the arm cuff. Deflation
cuff.
Pressure Detection
Make sure that the air
Power Source
The air plug is not
jack is connected
Battery Life
securely inserted into
securely.
Arm cuff pressure
the main unit.
Refer to section 3.1.
does not rise. Operating Temperature/
Humidity
Air is leaking from the Replace the arm cuff
Storage Temperature/
arm cuff. with a new one.
Humidity/ Air Pressure
Apply the cuff correctly Console Weight
so that it is firmly
Cuff Weight
Arm cuff deflates too
wrapped around the
The arm cuff is loose.
soon. arm.
Outer Dimensions
Refer to section 3.1.
Cuff Dimensions
Inflate the cuff so that it
Cannot measure or The arm cuff has not is 30 to 40 mmHg
above your previous
readings are too low been inflated
measurement result.
or too high. sufficiently. Cuff material
Refer to section 3.3.
Package Content
The unit loses power The batteries are Replace the batteries
during measurement. empty. with new ones.
Note: Subject to technical modification without prior notice
The batteries are Replace the batteries • This OMRON product is produced under the strict quality system of OMRON
empty. with new ones.
Healthcare Co. Ltd., Japan. The Core component for OMRON blood pressure
Nothing happens
monitors, which is the Pressure Sensor, is produced in Japan.
when you press the
The batteries have Insert the batteries with
• Disposal of this product and used batteries should be carried out in accordance
buttons.
been inserted the correct (+/ -)
with the national regulations for the disposal of electronic products.
incorrectly. polarity.
Press the O/I START button and repeat
measurement.
If the problem continues, try replacing the
Other problems.
batteries with new ones.
If this still does not solve the problem, contact
your OMRON retail outlet or distributor.
This device fulfils the provisions of EC directive 93/42/EEC (Medical Device Directive).
This blood pressure monitor is designed according to the European Standard EN1060,
Non-invasive sphygmomanometers Part 1: General Requirements and Part 3:
Supplementary requirements for electromechanical blood pressure measuring systems.
5. Maintenance and Storage
Please read the instruction manual carefully before
using the device.
Maintenance
Important information regarding Electro Magnetic Compatibility (EMC)
To protect your unit from damage, please observe the following:
With the increased number of electronic devices such as PC's and mobile
• Do not subject the main unit and cuff to extreme
(cellular) telephones, medical devices in use may be susceptible to
temperatures, humidity, moisture or direct sunlight.
electromagnetic interference from other devices. Electromagnetic
• Do not fold the cuff or tubing tightly.
interference may result in incorrect operation of the medical device and
• Do not inflate the arm cuff over 299 mmHg. create a potentially unsafe situation.
Medical devices should also not interfere with other devices.
• Do not disassemble the unit.
• Do not subject the unit to strong shocks or vibrations In order to regulate the requirements for EMC (Electro Magnetic
Compatibility) with the aim to prevent unsafe product situations, the
(for example, dropping the unit on the floor).
EN60601-1-2:2007 standard has been implemented. This standard defines
• Do not use volatile liquids to clean the main unit.
the levels of immunity to electromagnetic interferences as well as maximum
The unit should be cleaned with a soft, dry cloth.
levels of electromagnetic emissions for medical devices.
• Do not wash the arm cuff or immerse it in water.
This medical device manufactured by OMRON Healthcare conforms to this
• Do not use petrol, thinners or similar solvents to clean EN60601-1-2:2007 standard for both immunity and emissions.
Nevertheless, special precautions need to be observed:
the arm cuff.
• Do not use mobile (cellular) telephones and other devices, which generate
strong electrical or electromagnetic fields, near the medical device. This
may result in incorrect operation of the unit and create a potentially unsafe
situation. Recommendation is to keep a minimum distance of 7 m. Verify
correct operation of the device in case the distance is shorter.
Further documentation in accordance with EN60601-1-2:2007 is available at
• Use a soft, moistened cloth and soap to clean the arm cuff.
OMRON Healthcare Europe at the address mentioned in this instruction manual.
• Do not carry out repairs of any kind by yourself. Documentation is also available at www.omron-healthcare.com.
If a defect occurs, consult your OMRON distributor.
Correct Disposal of This Product
Calibration and Service
(Waste Electrical & Electronic Equipment)
• The accuracy of this blood pressure monitor has been
This marking shown on the product or its literature, indicates
carefully tested and is designed for a long service life.
that it should not be disposed of, with other household wastes
at the end of its working life. To prevent possible harm to the
• It is generally recommended to have the unit inspected every
environment or human health from uncontrolled waste disposal,
two years to ensure correct functioning and accuracy.
please separate this from other types of wastes and recycle it
Please consult your authorised OMRON dealer.
responsibly to promote the sustainable reuse of material resources.
Storage
Household users should contact either the retailer where they purchased
Keep the unit in its storage case when not in use. this product, or their local government office, for details of where and how
they can take this item for environmentally safe recycling.
1.
Unplug the air tube from the air jack.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product should not be mixed with
Gently fold the air tube
other commercial wastes for disposal.
into the arm cuff.
This product does not contain any hazardous substances.
Note: Do not bend the air tube excessively.
Do not store the unit in the following situations:
Manufacturer
• If the unit is wet.
• Locations exposed to extreme temperatures, humidity, direct sunlight,
dust or corrosive vapours.
• Locations exposed to vibrations, shocks or where it will be at risk of
falling.
EU-representative
6. Optional Parts
Medium arm cuff Large arm cuff AC adapter
Arm circumference Arm circumference
Exclusive
22 - 32 cm 32 - 42 cm distributor in
Russia & importer
Production Facility
CM-9997579-7 CL-9970672-9 R Adapter-9997605-0
HEM-7117-ALRU_A_M02_090619.pdf
Digital Automatic Blood Pressure Monitor
OMRON M2 Classic (HEM-7117-ALRU)
LCD Digital Display
Oscillometric method
Pressure: 0 mmHg to 299 mmHg
Pulse: 40 to 180/min.
30 Measurements
Pressure: ±3 mmHg
Pulse: ±5% of display reading
Automatic by electric pump
Automatic pressure release valve
Capacitive pressure sensor
4 "AAA" batteries 1.5V or AC/ DC adapter (6V 4W)
Capacity of new alkaline batteries is approx. 300
measurements
10°C to 40°C/ 30 to 85% RH
-20°C to 60°C/ 10 to 95% RH/ 700-1060 hPa
Approximately 289g without batteries
Medium cuff: approximately 120g
Large cuff: approximately 180g
Approximately 114 (w) mm × 84 (h) mm × 129 (l) mm
Medium cuff: approximately 146 mm × 446 mm
(Arm circumference 22 to 32 cm)
Large cuff: approximately 174 mm × 652 mm
(Arm circumference 32 to 42 cm)
Nylon
Main unit, medium cuff, large cuff, instruction manual,
storage case, battery set, AC adapter, guarantee card,
blood pressure pass
= Type B
OMRON HEALTHCARE CO., LTD.
24, Yamanouchi Yamanoshita-cho, Ukyo-ku, Kyoto,
615-0084, Japan
OMRON HEALTHCARE EUROPE B.V.
Kruisweg 577, 2132 NA Hoofddorp,The Netherlands
www.omron-healthcare.com
ComplectService Ltd.
1/1, Tishinskaya sq, Moscow, Russia,123056
www.csmedica.ru
OMRON DALIAN CO., LTD.
Economic & Technical Development Zone
Dalian 116600, China
Made in China
IM-HEM-7117-ALRU-02-11/09
5327736-0B
