PULSA PV
joule pulsa pv solar high performance ac solar module installation guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pulsa PV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for joule Pulsa PV

Summary of Contents for joule Pulsa PV

  • Page 1 PULSA PV joule pulsa pv solar high performance ac solar module installation guide...
  • Page 3 Inverter Serial No’s....... Inverter Serial No’s....... Scan the page or alternatively take a photo with smart phone of complete sheet with all information filled in. This must be completed by the installer and a copy sent to Joule - warranty@joule.ie...

  • Page 5: Table Of Contents

    Table of Contents Why Install Photovoltaic Solar Panels? Contribution to Running Costs Advantages Features Maximising Performance Transportation and Installation Notes Safety Instructions General Safety Handling Safety Installation Safety Fire Safety 14 Technical Specification Mechanical Installation Select suitable locations for installation Components supplied Installation Locating the Inverter Installing Branch Connectors...

  • Page 6: Why Install Photovoltaic Solar Panels

    Locating the Unit Why Install Photovoltaic Solar Panels? Since the revisions to Part L of the Building Regulations in March 2014 there has been a need for a greater contribution from renewable sources of energy for domestic and commercial constructions. One way to comply with the updated regulations is by in- stalling Photovoltaic (PV) Solar Panels.

  • Page 7: Contribution To Running Costs

    PULSA PV installation manual Contribution to Running Costs The table below gives typical consumptions of standard electrical devices. Even when electrical devices are turned off they may still be consuming power. Photovoltaic Solar Panels can contribute towards the operation of these products with the contribution given being determined by the amount of panels installed.

  • Page 8: Advantages

    Locating the Unit Advantages This next generation design eliminates the need for expensive DC wiring components and centralized power inverters. Also, the Photovoltaic AC Module dramatically re- duces the complex design and installation process associated with a traditional DC solar power system. AC Advantages •...

  • Page 9: Features

    PULSA PV installation manual Features Advantages Durability assured Up to 17% module efficiency Salt mist corrosion certification Outstanding performance in weak- Ammonia corrosion certification light conditions Excellent temperature coefficient Fire test certification giving higher yields in the long term Positive current sorting...

  • Page 10: Maximising Performance

    Locating the Unit Maximising Performance...

  • Page 11: Transportation And Installation Notes

    PULSA PV installation manual Transportation and Installation Notes...

  • Page 12: Safety Instructions

    • Joule Pulsa modules do not need special cables for connection. All of the modules have permanent junction boxes, cables and connectors.

  • Page 13: Fire Safety

    PULSA PV installation manual • Under normal conditions, a module is likely to produce more current and/or voltage than reported under Standard Test Conditions (STC). Accordingly, the values of ISC and VOC marked on the module nameplate should be multiplied by a factor when determining the component voltage ratings, conductor current ratings, fuse sizes, and the size of controllers connected to the photovoltaic system.

  • Page 14: Technical Specification

    Locating the Unit Technical Specification Mechanical characteristics Dimensions (mm) Solar cells Polycrystalline 156mm x 156mm square, 6 x 10 pieces in series 1640 Collector height 75mm / 2.95 inch Collector width 992mm / 39.06 inch 1360 Collector lenght 1640mm / 64.57 inch Weight (kg) 21.6kg / 47.6lbs 8-9x14...
  • Page 15 PULSA PV installation manual...

  • Page 16: Mechanical Installation

    Select suitable locations for installation Select a suitable location for installing the modules. Joule recommends that to achieve the best performance the modules should face south. The exact tilt angle and orientation of mounted modules should be recom- mended by a licensed/qualified installer.

  • Page 17: Installation

    PULSA PV installation manual Installation Select the appropriate installation method as per the installation diagram. The module clamps should not come into contact with the front glass and must not deform the module frame. Avoid any shadowing effects from the module clamps.
  • Page 18 Locating the Unit Mechanical Installation Mechanical Installation Roof fixing bolts are drilled down through the slate or tile covering the roof. The rub- ber gasket on the bolt keeps the penetration point in the roof weather proofed. A UV- resistant EPDM gasket with sealing cone and support collar is counter screwed with a third mounting nut and safely seals the roof.

  • Page 19: Locating The Inverter

    • With the rail in position the Microinverters are then fitted. • Each Joule Pulsa panel requires its own Microinverter and the Microinverters should be fitted to the right hand side of the connection cables that are fixed to the Pulsa panel.

  • Page 20: Electrical Installation

    Locating the Unit Electrical Installation Lightning Surge Protection Lightning protection and resulting voltage surge are protected in accordance with BS 7671 and EN 62305-1. It is assumed that the PV modules are installed in accordance with related standards and that the Microinverter is a part of a broader lightning pro- tection system in accordance with BS 7617 and EN 62305-1, -3.

  • Page 21: Installation Procedure

    PULSA PV installation manual Installation Procedure Installing the Enphase Engage Cable and Accessories involves several key steps: 1. Measure AC at the Electricity Network Connection 2. Install the AC Branch Circuit Junction Box 3. Position the Enphase Engage Cable 4. Attach the Microinverters to the Mounting Rail 5.
  • Page 22 Locating the Unit Electrical Installation Step 2 – Install the AC Branch Circuit Junction Box Risk of Electrical Shock. • Be aware that installation of this equipment includes risk of electric shock. Do not install the AC junction box without first removing AC power from the Enphase Sys- tem.

  • Page 23: Step 4 - Attach The Microinverters To The Mounting Rail

    • Position the Engage Cable to the right hand side of the centre of the panel so that connectors that are attached to the panels are not obstructed when fitting the Joule Pulsa panel to the mounting rail.

  • Page 24: Step 5 - Dress The Engage Cable

    Locating the Unit Electrical Installation Step 5 – Dress the Engage Cable Adhere to the following requirements: • Do not expose the connection to directed, pressurized liquid (water jets, etc.). • Do not expose the connection to continuous immersion. • Do not expose the AC connector to continuous tension (e.g., avoid pulling or bend- ing the Engage Cable near the connectors) •...
  • Page 25 PULSA PV installation manual • Place tie wraps on either side of the drop connector. Use one or two tie wraps, or other support scheme to secure the Engage Cable between connectors. • Remove and discard the temporary shipping caps from the Engage Cable.

  • Page 26: Step 6 - Terminate The Unused End Of The Engage Cable

    Locating the Unit Electrical Installation • Install sealing caps on all unused AC connectors. Unused AC connectors are live when the system is energized. • Do not use the shipping cap to cover unused connectors. The shipping cap does not provide an adequate environmental seal. Enphase sealing caps are required for protection against moisture ingress.
  • Page 27 PULSA PV installation manual To guarantee the safety of the wire organizer and to ensure that it remains sealed, please make sure that all parts are present and that all seals are seated correctly in the wire organizer. The wire organizer must be complete, as shown.

  • Page 28: Step 7 - Connect The Engage Cable To Ac Junction Box(Es)

    Locating the Unit Electrical Installation Replacing or Removing the Terminator • If the terminator must be replaced or removed, observe the following. • Risk of Electrical Shock. Be aware that installation of this equipment includes risk of electric shock. Do not install the AC junction box without first removing AC pow- er from the Enphase System.
  • Page 29 PULSA PV installation manual...
  • Page 30 Locating the Unit Electrical Installation Fixing the Pulsa Solar Module to the rails 1. Push click components into the upper groove of the cross beam profile, insert square nuts into the click components and distribute at approximate distances along the length of the profile. 2.

  • Page 31: Electrical Installation - Microinverter

    PULSA PV installation manual Electrical Installation - Microinverter The Microinverter with integrated ground delivers increased energy harvest and re- duces design and installation complexity with its all-AC approach. With the advanced M215, the DC circuit is isolated and insulated from ground, so no Ground Electrode Conductor (GEC) is required for the Microinverter.

  • Page 32: Technical Specification

    Locating the Unit Electrical Installation - Microinverter Technical Specification...
  • Page 33 PULSA PV installation manual...
  • Page 34 Locating the Unit Electrical Installation - Microinverter Electrical Installation Legend 1. Joule Pulsa Photovoltaic Panel 2. Microinverter 3. Drop Connector 4. Branch Terminator 5. Junction Box 6. 20A Lockable 2-pole AC Isolator 7. PV Generation Meter (not supplied) Consumer Board 9.

  • Page 35: Engage And Wire Sizing Overview

    In this document, calculations are provided for both Engage Cable options. Regard- less of the application, Joule recommends that the total percentage of voltage rise in the AC wiring be less than 2%, with (an inclusive) less than 1% voltage rise.

  • Page 36: Sample Calculation

    Locating the Unit Electrical Installation - Microinverter Circuit length: There is often little choice in circuit length, but center-feeding the dedicat- ed branch circuit will significantly reduce voltage rise within the branch, See ‘Advantages of Center-Feeding the AC branch Circuits’ in the following section. Voltage margin: If the service voltage is chronically high, the utility will sometimes per- form a tap change on the distribution transformer.
  • Page 37 PULSA PV installation manual Example: • 3 branches of 17 = 51 M215s • current of 3 branches = 47.43A • wire gauge for sub-panel feed = 25mm • 35 mm CU resistance = .000524Ω/m • Length of Microinverter sub-panel feed = 30m •...

  • Page 38: Voltage Rise For M215S With The 230V Engage Cable

    Locating the Unit Electrical Installation - Microinverter Voltage Rise for M215s with the 230V Engage Cable 230V Engage Internal VRise...

  • Page 39: Step 8 - Verification And Commissioning

    PULSA PV installation manual Step 8 – Verification and Commissioning Prior to final connection to the electricity network, ensure that all AC and DC wiring is correct. • Ensure that none of the AC and DC wires are pinched or damaged.

  • Page 40: Maintenance

    Perform an annual check In order to ensure optimum module performance, Joule recommends the following: • If necessary, the glass front of the module can be cleaned with water and a soft sponge or cloth.

  • Page 41: Replacing A Microinverter

    PULSA PV installation manual Replacing a Microinverter To ensure the Microinverter is not disconnected from the PV modules under load, ad- here to the following disconnection steps in the order shown: 1. Using a clamp-on meter, verify there is no current flowing in the DC wires between the PV module and the Microinverter.
  • Page 44 JOULE IE JOULE UK JOULE PL mail Kylemore Park West, Ballyfermot, Dublin 10 mail Unit 17C&D Power Road, Plantation Bus. Pk. mail 23-200 Kraśnik, ul. Towarowa 34. +353 (1) 623 7080 Bromborough, Wirral, CH62 3RN +48 (0) 128811171 +353 (1) 626 9337...
