H o m e A l a r m D i v i s i o n H o m e A l a r m D i v i s i o n
F I T T I N G I N S T R U C T I O N S F I T T I N G I N S T R U C T I O N S
T e c h n i c a l c h a r a c t e r i s t i c s T e c h n i c a l c h a r a c t e r i s t i c s
Power supply: -------------------------------------230 - 240 V AU.50 - 60 Hz or 12 V
DC (SELV)
Battery autonomy time: ---------------------C11: 12 hours
Dimensions C11: --------------------------------105 x 110 x 115 mm
Alarm cycle duration: -------------------------50 seconds
Maximum alarm cycles per channel: 6
Alarm relay capacity: --------------------------C11: 10A
Sound output: -------------------------------------C11: 118 dB
Lithium battery powered remote controls with over 4 million possible
codes.
H o w t o I n s t a l l H o w t o I n s t a l l
Please refer to the following points step by step.
1 1 - W h e r e t o I n s t a l l W h e r e t o I n s t a l l
-Choosing the correct location is very important so please carefully
consider the following points:
-Since the central unit requires a 230 V or 12 V power supply, try to
install the unit as close as possible to an outlet;
-The siren must be able to sound freely and must not be placed behind
obstacles that could dampen the sound;
-The C11 can either be fitted to a wall or ceiling; the higher it is placed
the greater the range it will cover (see fig. 1);
-The P.I.R. sensor must be fitted facing the area to be protected and must
have a clear view without being obstructed by walls, curtains or
partitions;
-Do not turn the P.I.R. toward fireplaces or stoves (or any source of
excessive heat) or toward the exterior of windows or glass walls;
C A U T I O N : to guarantee that the memorisation or cancellation of C A U T I O N :
remote controls takes place correctly, make sure that the alarm system
has been powered for at least 24 hours (in order to charge the internal
batteries) then disconnect it from the power source before proceeding.
2 2 - - R e m o t e c R e m o t e c o n t r o l m e m o r i s a t i o n o n t r o l m e m o r i s a t i o n
A coded remote control is used for carrying out all the various operations
of activation, deactivation and so on.
One of these is supplied with the central unit, and the following steps
must be carried out to make it operative:
Switch on the alarm central unit (ON position) by turning the key on the
rear of the C11 central unit clockwise.
The central unit will emit a low volume BEEP:
Press the remote control button and keep it pressed until the unit emits 3
brief beeps and the red LED begins to flash. Once the button is released,
after about 10 seconds the control unit will emit a prolonged beep to
indicate that storing has been accomplished.
2 . 1 2 . 1 - - M e m o r i s a t i o n o f a d d i t i o n a l r e m o t e c o n t r o l s M e m o r i s a t i o n o f a d d i t i o n a l r e m o t e c o n t r o l s
( o p t i o n a l ) ( o p t i o n a l )
If additional remote controls are purchased, the central unit must
memorize them in order to make them operative. To do this, proceed as
follows:
Step 1. Using the original remote control provided with the central unit,
carry out a series of activations/deactivations (press the button 16 times
consecutively, waiting a few seconds between one operation and the
next), until the central unit emits 3 consecutive beeps.
Step 2. Press the button of the new transmitter within 8 seconds until
the central unit emits 3 BEEPS to indicate that the signal has been
received. At this point, the new transmitter has been added to the list of
those enabled.
-Step 3. Repeat Step 2 for each additional transmitter that you want to
enable, including "old" ones. If you repeat Step 2 with a transmitter that
has already been enabled, the central unit still emits 3 beeps, but this
operation has no utility.
C 1 1 C 1 1
-When transmission of all the available remote controls is completed,
wait approximately 8 seconds; the central unit will then exit from the
remote control storing phase.
-From this moment on, only transmitters that have been enabled can
control the unit.
3 3 - - I n s t a l l i n g t h e C 1 1 I n s t a l l i n g t h e C 1 1
-Join the two half-brackets as shown in Fig. 3 and attach them to the wall
or ceiling using the screws and the plastic screw anchors provided in the
kit (make two Ø 7 mm holes) (see fig. 4).
-If necessary, make the following connections as shown in the general
wiring diagram, with the key of the C11 unit in the OFF position and the
220 V mains supply disconnected.
-When all connections have been made, position the connection cover in
its seat and secure it using the 2 self-tapping screws as shown in Fig. 2.
Then attach the control unit onto the bracket using the 2 socket head
screws as shown in Fig. 4.
The product should be connected to the domestic supply
§
(230v).
All electrical connections must be made by qualified
§
personnel
Note! Risk of electric shock! Always disconnect the electric
§
power source by means of the main circuit breaker of the
domestic electricity supply (230v) before making any
connections.
The product contains rechargeable batteries, which must be
§
disposed of correctly and not together with domestic waste.
Use special recycling containers for differentiated waste
collection provided by your local authority.
4 - F i n a l F i n a l c h e c k c h e c k
a) Activate the central unit by pressing the button on the remote control.
The unit emits 2 beeps and the Red LED flashes.
b) Within 25 seconds from activation, simulate an alarm by tripping the
PIR sensor. The central unit will emit one beep to indicate that the alarm
signal has been received. At this point, you have 25 seconds to retest the
PIR sensor.
c) Wait 25 seconds and put the unit into alarm status by simulating the
tripping of the PIR sensor. The unit will emit several beeps (lasting about
3 seconds), after which the internal siren goes into operation for about
50 seconds.
PLEASE NOTE:
Keep the keys supplied with the alarm central unit in a safe place. If both
keys are lost, it is not possible to remove or deactivate the alarm central
unit without causing irreparable damage.
C A U T I O N C A U T I O N
