RE010070948EN
Operation manual
Geopro RE
Read these instructions carefully!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Geopro RE and is the answer not in the manual?

Questions and answers

Related Manuals for Oilon Geopro RE

Summary of Contents for Oilon Geopro RE

  • Page 1 RE010070948EN Operation manual Geopro RE Read these instructions carefully!

  • Page 3: Table Of Contents

    Contents Introduction ............................4 Ground source heat pump operation principle................5 2.1. RE ground source heat pump operation principle ...............6 2.2. Collecting heat ........................6 2.3. Coefficient of perfomance....................7 2.4. Sizing heat pump .........................7 Geopro controller operation ......................8 3.1. Operating display functions ....................8 3.2.

  • Page 4: Introduction

    1. Introduction These instructions are made for Geopro –ground source heat pump user. Remember to ask installator to fill in implementation record, which is returned to manufacturer. Installation report is prerequisite for manufacturer quarantee. Read these instructions carefully before using the device. Given instructions must be followed.

  • Page 5: Ground Source Heat Pump Operation Principle

    2. Ground source heat pump operation principle 1. Vaporiser 2. Compressor 3. Superheating exhausting 4. Condenser 5. Subcooler Image 1. Ground source heat pump operating principle. Heat pump unit operation is based on vaporisation and circulation of refrigerant in heat pump. Refrigerant vaporisation requires heat energy.

  • Page 6: Re Ground Source Heat Pump Operation Principle

    2.1. RE ground source heat pump operation principle 1. Vaporiser 6. Subcooler buffer tank 2. Compressor, de-superheating, option 7. Warm water 3. Condenser 8. HC 1 heating circuit 4. Sub cooler, option 9. Cold water 5. Superheating buffer tank Image2. RE ground source heat pump operation principle. RE ground source heat pump standard model does not include super heater exchanger or subcooler.

  • Page 7: Coefficient Of Perfomance

    2.3. Coefficient of perfomance Heat pump efficiency ratio is measured with coefficient of performance, COP. COP indicates the amount of heat energy transferred into compressor in relation to used electrical energy. COP depends largely on heat source and heating network temperatures. The highest possible heat source temperature and the lowest possible supply water temperature improve efficiency ratio.

  • Page 8: Geopro Controller Operation

    3. Geopro controller operation 3.1. Operating display functions Tap –button, DHW heating mode selection 2. Heating mode selection Cooling (Activated with Cooling button, not in use) Automatic (According to programmed time) Comfort setpoint Reduced setpoint Frost protection setpoint 3. Info –button, displays measurement results and failures 4.

  • Page 9: Operation

    3.2. Operation Browsing through menus: 1. Press OK –button to access menu levels. 2. Select desired menu level using adjusting wheel, and press OK -button. 3. Find submenu or value you want to adjust, and press OK -button. 4. Turn adjusting wheel to change value or selection. If you do not make changes, you will return to basic display.

  • Page 10: Changing Room Temperature Settings

    3.3.4. Changing room temperature settings Desired room temperature can be changed by turning adjusting wheel at standard mode.. When turning adjusting wheel flashing setting appears on display, and it can be raised or lowered using adjusting wheel. Accept change by pressing OK –button, and rejected with Return –button.

  • Page 11: Setting Holiday Heating Circuit

    3.3.7. Setting holiday heating circuit At menu level Holiday heating circuit 1 (2) user can set dates when room temperature is reduced, for example during vacation. Setting is operational only when heating circuit is set on automatic mode. 3.3.8. Adjusting domestic hot water temperature and mode Domestic hot water heating can be turned off and on using tap -button at the upper left corner of the display.

  • Page 12: Additional Equipment Control

    3.4. Additional equipment control Additional equipment has to be ordered separately, and is not in use in standard models. 3.4.1. Cooling circuit 1 If cooling circuit is installed to ground source heat pump, cold water from drilled well can be used for cooling with air conditioner.

  • Page 13: User Menu Levels And Factory Settings

    3.5. User menu levels and factory settings Table below shows end user level operating lines and factory settings. Time of day and date Line Parameter Function Setting Hours / minutes Set time. Day / month Set date. Year Set year. Operator section Line Parameter...
  • Page 14 4 DHW Time prog Line Parameter Function Setting Preselection Select dates for time limits. Mon - Sun 1. Phase on Clock time when temperature level is raised to comfort 04:00 setpoint. 1. Phase off Clock time when temperature level is lowered to reduced 09:00 setpoint.
  • Page 15 Heating circuit Line Parameter Function Setting Operating mode 1000 Set operation mode. Automatic 1010 Comfort Set room temperature for heating circuit to reach at comfort setpoint setpoint. 1012 Reduced Set room temperature for heating circuit to reach at reduced setpoint setpoint.
  • Page 16 Diagnostics consumers Line Parameter Function Setting 8700 Outside Current outside temperature. temperature Outside temp 8701 Minimum outside temperature. Outside temp 8702 Maximum outside temperature. 8740 Room temp 1 Room temperature for circuit 1 outside sensor, if any. 8741 Room temp Heating circuit 1 room setting.

  • Page 17: Maintenance

    4. Maintenance 4.1. Cleaning collector circuit filter WARNING! Switch off electricity from device before maintenance work. Open screen carefully, there is fluid in pipe. Check that you have necessary tools available. Note! 1. Switch off device from main switch. 2. Close screen isolation valves. 3.

  • Page 18: Troubleshooting

    4.2. Troubleshooting Error message codes Definition Sensor Cause Action Outside sensor No outside Check outside sensor sensor. connection. Flow sensor 1 No measurement Check L1 flow sensor from outgoing connection. water Flow sensor 2 No measurement Check L2 flow sensor from outgoing connection, additional.
  • Page 19 Low pressure Compressor intake pressure is below low pressure minimum limit Compressor 1 Compressor overloaded overloaded BX same sensors BX-outputs connected using same address BX/e'module same sens. BX- outputs connected using same address E’module same funct. Same function for additional modules E’mod/m’grp same funct.
  • Page 20 GSSH010020904FI_draft 4/23...
  • Page 22 OILON HOME OY P.O.Box 5, 15801 Lahti Visiting address : Tarmontie 4, 15860 Hollola Tel. (03) 85 761 fax (03) 857 6239 info@oilon.com www.oilon.com...
