CAMERA OVERVIEW
( C MOUNT LENS )
( CS MOUNT LENS )
Level potentiometer
(for DC type A/I lens)
1.
Back focus Lock Screw – Allows the user to secure the backfocus
setting.
2
SIDE VIEW
C Mount Ring
Back Focus Ring
BACK VIEW (12VDC / 24VAC)
V. Phase Potentiometer
LEVEL PHASE PWR
Function
Switch
Power Input
Terminal
FRONT VIEW
Back Focus Lock Screw
LENS
VIDEO OUT
~
G
~
12VDC / 24VAC CLASS 2
Camera Mounting Bracket
Power LED
Auto Iris Lens
Connector
Video Out BNC
Connector
Continued on next page
