INSTRUCTIONS FOR
12V 1200A
Power Pack
Stock No.24341
Part No.PP12VB/HD1200
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY TO ENSURE THE SAFE AND
EFFECTIVE USE OF THIS PRODUCT.

GENERAL INFORMATION

These instructions accompanying the product are the original instructions. This document is part of the product, keep it
for the life of the product passing it on to any subsequent holder of the product. Read all these instructions before
assembling, operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been designed, and
contains all the necessary information to ensure its correct and safe use. By following all the general safety instructions
contained in this manual, it will ensure both product and operator safety, together with longer life of the product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper Tools policy
of continuous improvement determines the right to make modifications without prior warning.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PP12VB and is the answer not in the manual?

Questions and answers

Related Manuals for Draper PP12VB

Summary of Contents for Draper PP12VB

  • Page 1: General Information

    AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.

  • Page 2: Title Page

    Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Draper Tools Limited. In all cases this copyright notice must remain intact.

  • Page 3: Table Of Contents

    CONTENTS 2.1 CONTENTS Page content Page TITLE PAGE INTRODUCTION ....................2 REVISION HISTORY................... 2 UNDERSTANDING THIS MANUAL ..............2 COPYRIGHT NOTICE ..................2 CONTENTS CONTENTS ......................3 GUARANTEE GUARANTEE ..................... 4 INTRODUCTION SPECIFICATION ....................5 HEALTH & SAFETY INFORMATION GENERAL SAFETY INSTRUCTIONS FOR POWER PACK USE ......6 ADDITIONAL SAFETY INSTRUCTIONS FOR POWER PACK USE.......

  • Page 4: Guarantee

    This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorised. Your Draper guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your proof of purchase within the guarantee period.

  • Page 5: Introduction

    INTRODUCTION 4.1 SPECIFICATION Stock no ..........................24341 Part no ......................PP12VB/HD1200 Recommended maximum capacity: Petrol ........................3000cc Diesel ........................2000cc Output: Voltage ........................12V Amperage: Starting ......................600A Peak......................1200A Worklight..........................3W Weight ..........................6.5kg Integral battery: Type ...................Dry lead acid sealed battery Voltage ........................

  • Page 6: Health & Safety Information

    IMPORTANT: Draper Tools Limited recommends that this machine should not be modified or used for any application other than that for which it was designed. If you are unsure of its relative applications do not hesitate to contact us in writing and we will advise you.

  • Page 7: Additional Safety Instructions For Power Pack Use

    HEALTH & SAFETY INFORMATION – Prior to initial use charge for 30 hours. – If the charger receives a sharp blow or is otherwise damaged in any way, do not disassemble. Have it checked by a qualified service person. Return to source. –...
  • Page 8 HEALTH & SAFETY INFORMATION – Avoid overdischarge, and charge the battery immediately after discharge. – Unsatisfactory storage conditions may cause deterioration in battery performance, shorten service life and could cause rust to form on the terminals. – Do not allow metallic objects to touch or bridge the terminals especially jewellery. Failure to observe the precautions may cause the battery to overheat, emit hydrogen gas, leak, ignite or explode.

  • Page 9: Connection To The Power Supply

    HEALTH & SAFETY INFORMATION – Used batteries are recyclable. When returning used batteries, insulate their terminals with adhesive electrical insulation tape. If not, the residual electricity in used batteries may cause fire or explosion. – This battery is fully recyclable and should be accepted at any location that excepts common automotive batteries.

  • Page 10: Technical Description

    TECHNICAL DESCRIPTION 6.1 IDENTIFICATION (10) (10) 12V socket power output On/Off Charging indicator. switch. 12V DC power socket. Worklight On/Off Switch. (10) Charging port. Battery test push button. (11) Worklight. Negative (-) black battery cable & clamp. Positive (+) red battery cable & clamp.

  • Page 11: Unpacking & Checking

    Lay the contents out and check them against the parts shown below. If any part is damaged or missing; please contact the Draper Helpline (the telephone number appears on the Title page) and do not attempt to use the power pack.

  • Page 12: Operation And Use

    OPERATION AND USE 8.1 RECHARGING POWER PACKS – FIG. 1 FIG. 1 Before first use, fully charge the integral battery for 30hrs. To check the integral battery's status, press the battery test button (3). NOTE: If the battery is fully discharged, the charging time should be 50hours.

  • Page 13: Jump Starting

    OPERATION AND USE 8.2 JUMP STARTING – FIGS. 2 – 3 FIG. 2 Refer to the General Safety Instructions for information regarding the handling of lead acid batteries etc. For 'Maintenance' type lead acid batteries remove the cell caps to monitor the electrolyte levels prior to commencing.
  • Page 14 OPERATION AND USE Engine cranking requires a large amount of current. FIG. 3 The engine that requires starting must be in a good mechanical condition as prolonged cranking is not possible. When attempting to crank vehicles equipped with large capacity batteries or in severe climates it will be necessary to pre-charge the vehicle battery for approximately 15 minutes before attempting a jump start.

  • Page 15: Worklight

    OPERATION AND USE 8.3 WORKLIGHT – FIG. 4 FIG. 4 When using the power pack in poorly lit conditions the worklight (11) can be utilised. To illuminate position switch (11) to the on position. 8.4 12V POWER OUTLET – FIG. 5 FIG.

  • Page 16: Maintenance And Parts Replacement

    The appliance must be correctly ventilated during operation. All servicing and maintenance not listed in this manual must be carried out by an approved Draper service agent (see back cover for contact details).

  • Page 17: Explanation Of Symbols/Pictograms

    10. EXPLANATION OF SYMBOLS/PICTOGRAMS 10.1 EXPLANATION OF SYMBOLS/PICTOGRAMS Class II construction (double insulated). For indoor use only. Automatic overload protection. Isolating transformer. Do not dispose of WEEE* as unsorted municipal waste. * Waste Electrical & Electronic Equipment.

  • Page 18: Disposal

    11. DISPOSAL 11.1 DISPOSAL - At the end of the product’s working life, or when it can no longer be repaired, ensure that it is disposed of according to national regulations. - Contact your local authority for details of collection schemes in your area. In all circumstances: •...
  • Page 19 NOTES...
  • Page 20 - Sales Fax: (023) 8049 4209 - General Enquiries: (023) 8026 6355 - Service/Warranty Repair Agent For aftersales servicing or warranty repairs, please contact the Draper Tools Helpline for details of an agent in your local area. YOUR DRAPER STOCKIST DBCH061112...
