- Page 1 INSTRUCTION MANUAL...
-
Page 3: Table Of Contents
CONTENTS 1. Features ......................3 2. Displays and Buttons ..................3 3. Setting the Time ....................4 4. Setting the Date ....................6 5. Using the Chronograph ................. 8 6. Zero Positioning of Chronograph Hands .... 10 (After Replacing the Battery) 7. -
Page 4: Features
1. Features This watch is an analog quartz watch equipped with features including a 24 hour display and chronograph function. 2. Displays and Buttons ※ ※ Chronograph Chronograph Chronograph second hand minute hand second hand Hour hand Button (A) Button (A) 24 hour hand Minute hand Minute hand... -
Page 5: Setting The Time
3. Setting the Time Minute hand Hour hand Second hand Time correction position In the case the crown is of the screw-lock type, loosen the screw by turning the crown to the left before operating the crown, and after having returned the crown to the normal position following operation, turn the crown to the right while pushing it in to securely retighten it. - Page 6 1. Pull the crown out to the time correction position when the second hand has reached the 0 seconds position. 2. Turn the crown to set the time. * The 24 hour hand moves in conjunction with the hour hand. Pay attention to AM and PM when setting the time.
-
Page 7: Setting The Date
4. Setting the Date Date correction position Date... - Page 8 1. Pull the crown out to the date correction position. 2. Turn the crown to the right to set the date. * The crown turns freely and the date does not change if the crown is turned to the left. * If the date is set while the time on the watch is between the hours of about 9:00 PM and 1:00 AM, the date may not change on the following day.
-
Page 9: Using The Chronograph
5. Using the Chronograph The chronograph function of this watch is able to measure and display elapsed time up to 59 minutes 59 seconds in 1 second units. After the chronograph displays elapsed time for 59 minutes 59 seconds, it resumes timing from 0 seconds. - Page 10 [Note] The chronograph continues to keep time with the chronograph hands until it is stopped even after 60 minutes have elapsed. Once timing is finished, promptly press button (A) to stop the chronograph, and then press button (B) to reset it to 0 seconds. If timing is allowed to continue, the battery will continue to wear down and eventually be depleted causing the watch to stop before the end of the indicated battery life.
-
Page 11: Zero Positioning Of Chronograph Hands (After Replacing The Battery)
6. Zero Positioning of Chronograph Hands (After Replacing the Battery) When resetting the chronograph after replacing the battery, if the chronograph second hand does not return to the 0 seconds position or if the chronograph second hand has shifted out of position due to a strong impact, perform zero positioning of the chronograph hands according to the procedure described below. - Page 12 [Chronograph Hand Zero Positioning] 1. Pull the crown out to the time correction position. 2. Press button (A) to position the chronograph second at the 0 position. * The chronograph second hand can be advanced rapidly by depressing button (A) continuously. 3.
-
Page 13: Precautions
7. Precautions CAUTION: Water-resistance performance There are several types of water-resistant watches, as shown in the following table. The unit "bar" is roughly equal to 1 atmosphere. * WATER RESIST(ANT) xx bar may also be indicated as W.R. xx bar. Indication Minor exposure to water (washing face,... - Page 14 For correct use within the design limits of the watch, confirm the level of water- resistance of your watch, as indicated on the dial and case, and consult the table. Examples of use Moderate exposure Operation of the to water (washing, crown or button with Marine sports Scuba diving...
- Page 15 • If moisture has entered the watch, or if the inside of the crystal is fogged up and does not become clear within a day, immediately take the watch to your dealer or Citizen Service Center for repair. Leaving the watch in such a state will allow corrosion to form inside.
-
Page 16: Cleaning The Watch
• If seawater enters the watch, place the watch in a box or plastic bag and immediately take it in for repair. Otherwise, pressure inside the watch will increase, and parts (crystal, crown, buttons, etc.) may come off. CAUTION: Keep your watch clean. •... - Page 17 CAUTION: Replacing the battery • For replacement of the battery, take your watch to your dealer or Citizen Service Center. • Replace the battery as soon as possible if the service life of the battery has expired.
- Page 18 • Do NOT use the watch in places where it is exposed to high temperature, such as in a sauna. Doing so may result in a skin burn. • Do NOT leave the watch in a place where it is exposed to high temperature, such as the glove compartment or dash-board of a car.
- Page 19 Your watch needs inspection once in every two or three years for safety and long use. To keep your watch water-resistant, the packing needs to be replaced regularly. Other parts need to be inspected and replaced if necessary. Ask for Citizen geuine parts upon replacement.
-
Page 20: Specifications
8. Specifications ※ ※ 1. Caliber. No: F50 • F51 2. Type: Analog quartz watch 3. Timekeeping accuracy: Within ±20 seconds per month on average (when worn at normal temperatures of +5°C to +35°C / 41°F to 95°F) 4. Crystal oscillator: 32,768 Hz 5. - Page 21 ⑨...
