CT-340
Domestic Refrigerator
Operation Instructions
Contents
Cautions--------------------------------------------------------1~2
Refrigerator diagram-------------------------------------------3
Location------------------------------------------------------------4
Preparation----------------------------------------------------5~7
Functions-------------------------------------------------------8~9
Operation--------------------------------------------------------10
Refrigerator storage-------------------------------------------11
Cautions----------------------------------------------------------12
Suggestions------------------------------------------------------13
Freezer storage-------------------------------------------------14
Cautions----------------------------------------------------------15
Defrosting,Cleaning and Cesstion-------------------16~19
Questions and Answers---------------------------------20~22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CT-340 and is the answer not in the manual?

Questions and answers

Related Manuals for Teka CT-340

Summary of Contents for Teka CT-340

  • Page 1: Table Of Contents

    CT-340 Domestic Refrigerator Operation Instructions Contents Cautions--------------------------------------------------------1~2 Refrigerator diagram-------------------------------------------3 Location------------------------------------------------------------4 Preparation----------------------------------------------------5~7 Functions-------------------------------------------------------8~9 Operation--------------------------------------------------------10 Refrigerator storage-------------------------------------------11 Cautions----------------------------------------------------------12 Suggestions------------------------------------------------------13 Freezer storage-------------------------------------------------14 Cautions----------------------------------------------------------15 Defrosting,Cleaning and Cesstion-------------------16~19 Questions and Answers---------------------------------20~22...

  • Page 2: Cautions

    Cautions Cautions Cautions Cautions Cautions Disposal of the old appliance Before disposing an old appliance, please make sure it’s inoperative and safe. Unplug the appliance and remove or destroy all of the springs, latches, or bolt-locks in order to avoid the risk of child entrapment. It must be noted that the refrigeration system contains insulating gases and refrigerants, which require specialized waste disposal.

  • Page 3: Specifications

    Cautions Cautions Cautions Cautions Cautions *Damaged appliances are not to be put into operation. In case of doubt ,consult your supplier. *Connection and installation of the appliance are not to be carried out in strict compliance with the relative instructions set forth in the Use’s Guide. *For the purpose of safety ,the appliance must be properly grounded in accordance with specifications.

  • Page 4: Refrigerator Diagram

    Refrigerator Diagram Refrigerator Diagram Refrigerator Diagram Refrigerator Diagram Refrigerator Diagram =Control panel Lamp ==================== =cêÉëÜ=ÑççÇ=Åçåí~áåÉê Food shelf ===== =Bottle holder Egg holder =Bottle fence =================== =Drawers qÜáë= Çá~Öê~ã= ã~ó= îÉêó= ëäáÖÜíäó= ïáíÜ= íÜÉ= ä~óçìí= çÑ= íÜÉ qÜáë= Çá~Öê~ã= ã~ó= îÉêó= ëäáÖÜíäó= ïáíÜ= íÜÉ= ä~óçìí= çÑ= íÜÉ qÜáë= Çá~Öê~ã= ã~ó= îÉêó= ëäáÖÜíäó= ïáíÜ= íÜÉ= ä~óçìí= çÑ= íÜÉ...

  • Page 5: Location

    Location Location Location Location Location *The refrigerator should be placed on a flat and solid surface. If the refrigerator is placed on a plinth, flat, strong and fire-resistant materials must be used. The front black foot of the refrigerator can be anti-clockwise adjusted clockwise or anti-clockwise to lift or lower Adjustable Foot...

  • Page 6: Preparation

    Preparation Preparation Preparation Preparation Preparation NK NK NK NK NKUnpacking Remove all packing materials. OK OK OK OK OKCheck attached accessories and materials. Checking should be conducted with reference to the Packing List. Contact the local distributor if shortage is found. PK PK PK PK PKEnsure that the refrigerator is properly lo- cated.
  • Page 7 Preparation Preparation Preparation Preparation Preparation iÉÑíLoáÖÜí=aççê=léÉåáåÖ iÉÑíLoáÖÜí=aççê=léÉåáåÖ iÉÑíLoáÖÜí=aççê=léÉåáåÖ iÉÑíLoáÖÜí=aççê=léÉåáåÖ iÉÑíLoáÖÜí=aççê=léÉåáåÖ The door of the refrigerator can be opened both from the left or right as required. The following are the steps required to position the door to open to the right. Lower hinge Lower pivot pin 1.

  • Page 8: Preparation

    Preparation Preparation Preparation Preparation Preparation _ìáäíJáå=áåëí~ää~íáçå _ìáäíJáå=áåëí~ää~íáçå _ìáäíJáå=áåëí~ää~íáçå _ìáäíJáå=áåëí~ää~íáçå _ìáäíJáå=áåëí~ää~íáçå 1. Ensure that the doors of the kitchen unit and the refrigerator are of the same opening direction. (Take gçáåí=ëçÅâÉí the right-opening door as an example) cáÖìêÉ=N 2. Fix the joint sockets to the freezer and refrigerator doors with the provided screws (Figure 1).

  • Page 9: Functions

    Functions Functions Functions Functions Functions 1 Control panel When refrigerator is connected a power source, the green lamp (E) and the red over- temp warning lamp (G) illuminate. A. Refrigerator temperature setting E. Power indicator (green) B. Freezer temperature setting F.

  • Page 10: Functions

    Functions Functions Functions Functions Functions 5 Freezer temperature display Temperature Range Indicator Temperature of the freezer can be displayed. -13 ~-16 The indicator F illuminates at different scales -16 ~-19 for temperature ranges as shown in the table. -19 ~-23 -23 ~-25 Quick freezing mode 6 Over temperature warning and buzzer release...

  • Page 11: Operation

    Operation Operation Operation Operation Operation 1 Connect the refrigerator to the power supply. After connection of the power supply, the green indicator illuminates and the refrig- erator operates. The red warning indicator might illuminates once in a while and automatically extinguishes when the set temperature in the refrigerator is reached. 2 Temperature setting Temperatures in the refrigerator and the freezer are controlled by the thermostats.

  • Page 12: Refrigerator Storage

    Refrigerator storage Refrigerator storage Refrigerator storage Refrigerator storage Refrigerator storage The refrigerator is for short-term food storage or for daily con- sumption. Although the temperature in most areas in the refrigeration compartment can be regu- lated between 0 and 10 , extended periods of food storage is not recommended. Refrigerator should only be used for short-term storage.

  • Page 13: Cautions

    Cautions Cautions Cautions Cautions Cautions *Hot food must be cooled to room temperature before storing in the refrigerator. *Dry any water droplets on the food before placing it in the refrigerator. *It is recommended that food be sealed in suitable storage bags before placing it in the refrigerator.

  • Page 14: Suggestions

    Suggestions Suggestions Suggestions Suggestions Suggestions *Storage period will be extended if vegetables are placed with their roots towards the cold source. *Leaves of carrots or turnips should be removed before storage. *Eggs should be stored vertically in the egg holder. *Frozen food can be placed in the cold compartment before serving, as this will conserve energy.

  • Page 15: Freezer Storage

    Freezer storage Freezer storage Freezer storage Freezer storage Freezer storage Long-term storage of food As the freezer storage temperature is very low, fresh food can be stored in the freezer compartment for a long time. Food requiring long-term storage can be stored in the frozen food compartment.

  • Page 16: Cautions

    Cautions Cautions Cautions Cautions Cautions *Hot food should not be stored in the refrigerator until it has cooled down to room temperature. *Food cut into small portions will freeze faster and be easier to defrost and cook. The recommended weight for each portion is less than 2.5kg.

  • Page 17: Defrosting,Cleaning And Cesstion

    Defrosting Defrosting Defrosting Defrosting Defrosting Defrosting the refrigerator The refrigerator is designed for automatic defrost- ing. Frost formed on the back wall will melt and Water Outlet flow via the drainpipe to the evaporating container over the compressor on the back of the refrigera- tor, where the heat generated by the compressor Cleaning Rod will evaporate the water.
  • Page 18 Cleaning Cleaning Cleaning Cleaning Cleaning Cleaning The refrigerator should be cleaned regularly to prevent the formation of bad odors. *Disconnect the power before cleaning the refrigerator. *Clean the refrigerator with soft towel or sponge wet with warm water. (mild detergent) Caution: Do not use a hard brush, steel brush, detergent, gasoline or other solvents, hot water, acid or alkali for cleaning.

  • Page 19: Power Failure

    Cessation Cessation Cessation Cessation Cessation Power failure Even in summer, food can be stored in the refrig- erator for a few hours after a power failure. *Don't put additional food into the refrigerator during a power failure. *If prior notice of a power failure is given, make some ice and put it in a container in the top of the cold storage compartment.

  • Page 20: Moving The Refrigerator

    Cessation Cessation Cessation Cessation Cessation During Vacations *Remove the food from refrigerator if the vacation is short. Turn the temperature selection knob to the proper position, and make sure that the door of the refrigerator is properly closed. *If the vacation is long, take out the food from the refrigerator and disconnect the power.

  • Page 21: Questions And Answers

    Questions and Answers Questions and Answers Questions and Answers Questions and Answers Questions and Answers Following circumstances are not problems: *A slight sound might be produced by the evaporator and the pipes due to temperature changes. *The compressor will operate for comparatively longer periods if excessive quantity of food is stored or the ambient temperature is high.
  • Page 22 Questions and Answers Questions and Answers Questions and Answers Questions and Answers Questions and Answers Following circumstances are not problems: *A slight continuous sound will be heard when the liquid refrigerant circulates. *Excessive vibration will be resulted in the following circumstances: a) The refrigerator is not well positioned and adjusted.

  • Page 23: Questions And Answers

    Questions and Answers Questions and Answers Questions and Answers Questions and Answers Questions and Answers Please determine the cause of the problem before making any repairs. *Disconnection of power supply (plug, socket and fuse); Operation failure of the *Voltage is low. refrigerator *The bulb is bad;...
