Operating Instructions

Model No.
Indoor Unit
CS-YA18NKS
CS-YA24NKS
ENGLISH
Before operating the unit, read these operating
instructions thoroughly and keep them for future
reference.
© Panasonic Appliances Air-Conditioning Malaysia
Sdn. Bhd. 2012. Unauthorized copying and distribution
is a violation of law.

Air Conditioner

Outdoor Unit
CU-YA18NKS
CU-YA24NKS
F568392
