- Page 1 CWR260DZ Built in Wine Cellar Owner’s Manual This owner’s manual provides instructions on safe installation, use, and maintenance. Please read it carefully and save it for reference. http://www.edgestar.com...
-
Page 2: Table Of Contents
Table of Contents Important Safeguards……………………………………. 2 Specifications……………………………………………... 3 Parts and Features……………………………….………. 4 Installation…………………………………………………. 5 Operation………………………………………………..5 Temperature Control………………………………...…… 6 Rack Removal and Insertion………………………….. Troubleshooting…………………………………………… 8 Limited Warranty………………………………………….. 10 First Time Operating Instructions Before use, make sure all packaging labels and materials are removed from the unit. -
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS When using an electrical appliance, basic precautions should always be followed, including the following: BEFORE USE, PLEASE READ AND FOLLOW ALL INSTRUCTIONS FOR THIS WINE COOLER • Do not use if the power supply cord is damaged. If damaged, it must be replaced by the manufacturer or a similarly qualified person. -
Page 4: Specifications
• The cord should be secured behind the unit and should not be left exposed or dangling. • Do not move this cooler without emptying it of its contents and securing the door in a closed position. 1. Key Specifications Model Number CWR260DZ Capacity 26 Bottles Input Power 100W Rated Frequency 60Hz 1.8kw.h/24h... -
Page 5: Parts And Features
2. Major Parts and Features Important Note: Even if your refrigerator looks slightly different; the operation will essentially be the same. Picture is provided for reference. 1 Dual-pane window 2 Front grill 3 Adjustable legs 4 Main shelving 5 Cabinet 6 Main control panel 7 Temperature indicator 8 Light switch... -
Page 6: Installation
3. Installation • Clear unit of any loose packaging materials. • Confirm you have all required loose parts and pieces. • Place the unit on a flat, dry surface that is able to support the unit while fully loaded. • This unit is designed to be either recessed or free standing. •... -
Page 7: Temperature Control
5. Temperature Control Preset temperature control: This unit is factory programmed at ‘storing’ temperature. manufacturer presets temperature at 54°F (12°C). Manual temperature control: To manually adjust temperature, press the button on the control panel to decrease, and the button to increase by 1 degree inside the unit. This unit has a range from 45°F (7°C) to 65°F (18°C). -
Page 8: Rack Removal And Insertion
6. Rack Removing and Insertion Be sure to have the door all the way opened when pulling shelves out of the rail compartment to avoid damage. How to remove a rack: - Remove bottles - Remove the stopper from each side of the rack, and gently pull up. -
Page 9: Troubleshooting
7. Troubleshooting Symptoms Possible causes Solutions There is a power Ensure the cooler is failure. plugged in and the power outlet has power. The wine The cooler is not cooler does plugged in. not turn on. Replace the broken fuse A house fuse has in your fuse box or reset blown or the circuit... - Page 10 Symptoms Possible causes Solutions The room Run the cooler in the temperature is higher appropriate ambient than the temperature. recommended ambient temperature Minimize the number of (77°F). times the door is opened. The cooler The door is being turns on and opened often.
-
Page 11: Limited Warranty
DESCRIPTION OF WARRANTY SERVICE: All defective product components covered by this warranty will be repaired or replaced, at EdgeStar’s option, free of charge on a mail-in basis to EdgeStar’s authorized repair facility during the first 90 days from the date of original purchase. - Page 12 Once an EdgeStar authorized representative has confirmed that your product is eligible for warranty service, the product must be returned to an EdgeStar authorized repair facility. The purchaser is solely responsible for prepaying all shipping related costs to and from the repair facility.
- Page 13 For information on EdgeStar and to view our full line of products, please visit our website: http://www.edgestar.com EdgeStar Products Box 81336 Austin, Texas 78708-1336 Toll Free: 1-866-319-5473...
