Page 1: Wired Remote Controller
WIRED REMOTE CONTROLLER KJR-86C-E INSTALLATION & OWNER´S MANUAL Please read this manual carefully before operation and keep it for future reference. intensity.mx MAN-O-KJR86C-0615... - Page 2 This manual gives detailed description of the precautions that should be brought to your attention during operation. In order to ensure correct service of the wired controller please read this manual carefully before using the unit. For convenience of future reference, keep this manual after reading it.
-
Page 3: Table Of Contents
CONTENTS PAGE INSTALLATION I. SAFETY PRECAUTIONS..............2 II. OTHER PRECAUTIONS...............4 III. INSTALLATION PROCEDURE............ 6 IV. WIRING FIGURE OF THE WIRED REMOTE CONTROLLER CON- NECT WITH THE INDOOR UNIT..........9 OPERATION I. MAIN PARAMETERS..............15 II. MAIN FUNCTIONS..............15 III. NAMES AND FUNCTIONS OF KEYS..........16 IV. -
Page 4: Installation
INSTALLATION... -
Page 5: Safety Precautions
I. SAFETY PRECAUTIONS The following contents are stated on the product and the opera- tion manual, including usage, precautions against personal harm and property loss, and the methods of using the product correctly and safely. After fully understanding the following contents (identifiers and icons), read the text body and observe the follow- ing rules. - Page 6 Icon description lcon Meaning It indicates forbidding. The forbidden subject-matter is indicated in the icon or by images or characters aside. It indicates compulsory implementation. The compulsory subject-matter is indicated in the icon or by images or characters aside. Warning Please entrust the distributor or profes- sionals to install the unit.
-
Page 7: Ii.other Precautions
II.OTHER PRECAUTIONS Installation Location Do not install the unit in a place with much oil, steam, sulfide gas. Otherwise, the product may deform and fail. Preparation before installation 1. Check whether the following assemblies are complete. Name Qty. Remarks Wired remote Controller Installation &... -
Page 8: Remote Controller
2. Prepare the following assemblies on the site. Name Qty. Remarks General electrical box size, Electrical box embedded in the wall in advance. PVVR-0.5mm2x4,embedded in the 4-core shielding wire wall in advance. Embedded in the wall in advance, Wiring tube(insulation casing) the longest is 12M. -
Page 9: Iii.installation Procedure
III.INSTALLATION PROCEDURE Principle diagram of wired remote controller: 4-Core Shield Cable, the length is decided by Indoor Unit display panel installation Indoor Unit Fig.3.1 Installation instruction figure Attached connecting wires for the display panel 4-core shielding wire Display panel embedded in the wall Fig.3.2... - Page 10 4-core shielding wire embedded in the wall Fig.3.3 Fig.3.4 Fig.3.5...
-
Page 11: Warning Warning
box screw bar to the wall. Make 1.Insert the 4-core plug of the sure when install the screw bar to connecting wires for the signal the electrical box screw bar, make receiving panel into the 4-core it as flat as the wall. socket of the signal receiving panel. -
Page 12: Wiring Figure Of The Wired Remote Controller Connect With The Indoor Unit
IV. Wiring figure of the wired remote controller connect with the indoor unit 1.Wiring figure of the wire controller connect with the four-way cassette type indoor unit Indoor unit electric Plane of indoor unit controlling box Electric controlling boxs’ plug CN10 Main board 10-core connecting... - Page 13 2.Wiring figure of the wire controller connect with the courtyard-style duct type indoor unit Indoor unit electric controlling box Plane of indoor unit Electric controlling boxs’ plug CN10 Main board 10-core connecting wire group Display panel 4-core shield cable Back of the wired remote controller A B C D fig.4.2...
- Page 14 3.Wiring figure of the wire controller connect with the high-static pressure duct type indoor unit Indoor unit electric controlling box Electric controlling boxs’ plug CN10 Main board Display panel A B C D Back of the wired remote controller 4-core shield cable fig.4.3...
- Page 15 4.Wiring figure of the wire controller connect with the wall hanging type indoor unit Indoor unit electric controlling box Plane of indoor unit Electric controlling boxs’ plug CN10 Main board 10-core connecting wire group Display panel 4-core shield cable Back of the wired remote controller A B C D fig.4.4...
- Page 16 5.Wiring figure of the wire controller connect with the stand-hanging type indoor unit Indoor unit electric controlling box Plane of indoor unit Electric controlling boxs’ plug CN10 Main board 10-core connecting wire group Display panel 4-core shield cable Back of the wired remote controller A B C D fig.4.5...
-
Page 17: Operation
OPERATION... -
Page 18: Main Parameters
I.MAIN PARAMETERS MODEL Voltage input Ambient tempera- ture range Ambient humidity range II.MAIN FUNCTIONS 1. Set HEAT/ COOL operation mode; 2. Set fan speed; 3. Temperature setting range: 17°C-30°C; 4. Power down memory function; 5. Room temperature display. -
Page 19: Names And Functions Of Keys
III. NAMES AND FUNCTIONS OF KEYS... -
Page 20: Iv.operation Method
FUNCTION ON/OFF On/Off the unit FAN SPEED Select fan speed SET TEMP UP Increase setting temperature SET TEMP DOWM Decrease setting temperature Quickly set the operation tempareture 26°C SHORTCUT to 26°C IV.OPERATION LCD screen of the wired remote METHOD controller off. ON/OFF Selecting mode: 1.When the unit is turned off,... - Page 21 Select the fan speed: 1.When the unit is turned on, press the FAN SPEED key to set the fan speed of indoor unit. The fan speed switching order is: AUTO LOW HIGH AUTO 2.Setting the fan speed to AUTO then the indoor unit will actually run at LOW speed.
