USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D´UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI
MANUALE D'USO
PAR 56/64
1 W LED CANS CLP56RGB1W / CLP64RGB1W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PAR 56 CAN and is the answer not in the manual?

Questions and answers

Related Manuals for Cameo PAR 56 CAN

Summary of Contents for Cameo PAR 56 CAN

  • Page 1 USER´S MANUAL BEDIENUNGSANLEITUNG MANUEL D´UTILISATION MANUAL DE USUARIO INSTRUKCJA OBSŁUGI MANUALE D‘USO PAR 56/64 1 W LED CANS CLP56RGB1W / CLP64RGB1W...
  • Page 2 Thank you for choosing Cameo Lights! We have designed this product to give you reliable operation over many years. Please, take a few moments to read these instructions carefully, as we want you to enjoy your new Cameo Lights products quickly and to the fullest.
  • Page 3 PAR 56/64 1 W LED CANS CLP56RGB1W / CLP64RGB1W...

  • Page 4: Preventive Measures

    • If your product fails to function correctly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Cameo dealer for service. • Only use fuses of same type and rating.
  • Page 5 SAFETY: OPERATING DETERMINATIONS If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and the warranty becomes void. Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks, lamp failure etc. Do not endanger your own safety and the safety of others! Incorrect installation or use can cause serious damage to people and property.
  • Page 6 • Long life LEDs OPERATING INSTRUCTIONS The Cameo LED CAN is a DMX-512 controllable, colour mixing spot made up of high efficiency and super bright LED’s. There are three colours (red, green and blue) whose intensity can be controlled individually allowing the creation of an unlimited range of colours.

  • Page 7: Back Panel

    BACK PANEL:...

  • Page 8: Mode Selection

    MODE SELECTION: Programmes STATIC COLOUR MODE: Press the mode button and use the up and down buttons to select one of the 7 desired colours. 1, Red 2, Green 3, Blue 4, Yellow 5, Cyan 6, Purple 7 White COLOUR CHANGING MODE Press the mode button to select the Colour Change programme.
  • Page 9 MODE SELECTION / DMX CONTROL MODE: The Cameo PAR LED CAN has two DMX modes to choose from, 4 channel or 6 Channel. To access the 4 Channel mode, press the mode button to show a red Red Dot dot illuminated under the first digit of the DMX address. The unit is now ready...

  • Page 10: Dmx Linking

    DMX LINKING: DMX-512 DMX (Digital Multiplex) is a universal protocol used as a form of communication between intelligent fixtures and controllers. A DMX controller sends DMX data instructions from the controller to the fixture. DMX data are sent as serial data that travel from fixture to fixture via the “DATA IN“ and “DATA OUT” XLR terminals located on all DMX fixtures (most controllers only have a “DATA OUT”...

  • Page 11: Dmx Cables

    DMX CABLES: NOTICE: • Be sure to follow figures 2 & 3 when making your own cables. Do not connect the cable’s shield conductor to the ground lug or allow the shield conductor to come in contact with the XLR’s outer casing. Grounding the shield could cause a short circuit and erratic behaviour.

  • Page 12: Specifications

    SPECIFICATIONS: CLP 56 WEIGHT & DIMENSIONS (WITHOUT BRACKET) Length 220 mm Width 220 mm Height 370 mm Weight 2.1 kg Beam angle 25 ° POWER Power consumption 25 W AC input 100 V AC - 250 V AC / 50 Hz / 60 Hz FUSE Main F1A for 120V / F2A for 250V...

  • Page 13: Manufacturer's Declarations

    MANUFACTURER´S DECLARATIONS: LIMITED WARRANTY This Limited Warranty applies to the Adam Hall, LD Systems, Defender, Palmer, Cameo and Eminence branded products. The statutory warranty rights towards the seller are not affected by this guarantee. In fact, it justifies, additional independent warranty claims towards Adam Hall.

  • Page 14: Limitation Of Liability

    MANUFACTURER´S DECLARATIONS: LIMITATION OF LIABILITY If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive remedy shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly limited to the lesser of the price you have paid for the product or the cost of repair or replacement of any hardware components that malfunction in conditions of normal use.

  • Page 15: Weee Declaration

    MANUFACTURER´S DECLARATIONS: WEEE-DECLARATION Your LD-Systems product was developed and manufactured with high quality materials and components wich can be recycled and/or reused. This symbol indicates that electrical and electronic equipment must be disposed of separately from normal waste at the end of its operational lifetime. Please dispose of this product by bringing it to your local collection point or recycling centre for such equipment.
  • Page 16 Thank you for choosing Cameo Lights! We have designed this product to give you reliable operation over many years. Please, take a few moments to read these instructions carefully, as we want you to enjoy your new Cameo Lights products quickly and to the fullest.
  • Page 17 PAR 56/64 1 W LED-STRAHLER CLP56RGB1W / CLP64RGB1W...
  • Page 18 • If your product fails to function correctly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Cameo dealer for service. • Only use fuses of same type and rating.

  • Page 19: Operating Determinations

    SICHERHEITSHINWEISE: OPERATING DETERMINATIONS If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and the warranty becomes void. Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks, lamp failure etc. Do not endanger your own safety and the safety of others! Incorrect installation or use can cause serious damage to people and property.

  • Page 20: Bedienung

    • Longlife-LEDs mit besonders langer Lebensdauer BEDIENUNG: Der Cameo LED CAN ist ein DMX-512-steuerbarer LED-Strahler mit RGB-Farbmischung, der sich durch hocheffiziente, besonders helle LEDs auszeichnet. Die Intensität der drei Farben (rot, grün, blau) kann unabhängig voneinander gesteuert werden und ermöglicht auf diese Weise eine unbegrenzte Anzahl unterschiedlicher Farbtöne.
  • Page 21 RÜCKSEITE:...

  • Page 22: Master/Slave-Betrieb

    AUSWAHL BETRIEBSART: Programmes STATISCHE FARBE: Drücken Sie die MODE-Taste, und wählen Sie anschließend mittels der Tasten UP und DOWN eine der 7 Farben aus. 1 = Rot, 2 = Grün, 3 = Blau, 4 = Gelb, 5 = Cyan, 6 = Violett, 7 = Weiß...
  • Page 23 AUSWAHL BETRIEBSART / DMX- STEUERUNG: Der Cameo PAR LED CAN bietet zwei verschiedene DMX-Betriebsarten: 4-Kanal- und 6-Kanal-Betrieb. Wenn Sie den 4-Kanal-Modus aktivieren Red Dot möchten, drücken Sie die MODE-Taste. Anschließend leuchtet unter der ersten Ziffer der DMX-Adresse ein roter Punkt, Nun arbeitet der Scheinwerfer im 4-Kanal-Modus.
  • Page 24 DMX-VERBINDUNG: DMX-512 DMX (Digital Multiplex) ist die Bezeichnung für ein universelles Übertragungsprotokoll, das der Kommunikation zwischen entsprechenden Geräten und Controllern dient. Ein DMX-Controller sendet DMX-Daten an das/die angeschlossene(n) DMX-Gerät(e). Die DMX-Datenübertragung erfolgt stets als serieller Datenstrom, der über die an jedem DMX-fähigen Gerät vorhandenen "DATA IN"- und "DATA OUT"- Anschlüsse (XLR-Steckverbinder) von einem angeschlossenen Gerät an das nächste weitergeleitet wird.
  • Page 25 DMX-KABEL: HINWEIS: • Beachten Sie bei der Anfertigung eigener Kabel unbedingt die Abbildungen 2 und 3. Verbinden Sie auf keinen Fall die Abschirmung des Kabels mit dem Massekontakt des Steckers, und achten Sie darauf, dass die Abschirmung nicht mit dem XLR-Steckergehäuse in Kontakt kommt. Hat die Abschirmung Massekontakt, kann dies zu Kurzschlüssen und Systemfehlern führen.

  • Page 26: Technische Daten

    TECHNISCHE DATEN: CLP 56 WEIGHT & DIMENSIONS (WITHOUT BRACKET) Length 220 mm Width 220 mm Height 370 mm Weight 2.1 kg Beam angle 25 ° POWER Power consumption 25 W AC input 100 V AC - 250 V AC / 50 Hz / 60 Hz FUSE Main F1A for 120V / F2A for 250V...

  • Page 27: Limited Warranty

    MANUFACTURER´S DECLARATIONS: LIMITED WARRANTY This Limited Warranty applies to the Adam Hall, LD Systems, Defender, Palmer, Cameo and Eminence branded products. The statutory warranty rights towards the seller are not affected by this guarantee. In fact, it justifies, additional independent warranty claims towards Adam Hall.

  • Page 28: Limitation Of Liability

    MANUFACTURER´S DECLARATIONS: LIMITATION OF LIABILITY If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive remedy shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly limited to the lesser of the price you have paid for the product or the cost of repair or replacement of any hardware components that malfunction in conditions of normal use.

  • Page 29: Weee Declaration

    MANUFACTURER´S DECLARATIONS: WEEE-DECLARATION Your LD-Systems product was developed and manufactured with high quality materials and components wich can be recycled and/or reused. This symbol indicates that electrical and electronic equipment must be disposed of separately from normal waste at the end of its operational lifetime. Please dispose of this product by bringing it to your local collection point or recycling centre for such equipment.
  • Page 30 Thank you for choosing Cameo Lights! We have designed this product to give you reliable operation over many years. Please, take a few moments to read these instructions carefully, as we want you to enjoy your new Cameo Lights products quickly and to the fullest.
  • Page 31 PAR 56/64 CANS LED 1 W CLP56RGB1W / CLP64RGB1W...

  • Page 32: Mesures Préventives

    • If your product fails to function correctly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Cameo dealer for service. • Only use fuses of same type and rating.

  • Page 33: Operating Determinations

    SÉCURITÉ: OPERATING DETERMINATIONS If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and the warranty becomes void. Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks, lamp failure etc. Do not endanger your own safety and the safety of others! Incorrect installation or use can cause serious damage to people and property.
  • Page 34 • LED à longue durée de vie INSTRUCTIONS D'UTILISATION Le Cameo LED CAN est un spot mélangeur de couleurs RGB, contrôlable via DMX 512, utilisant des LED haute efficacité et super-brillantes. On compte trois groupes de couleurs (rouge, vert et bleu), dont l'intensité est contrôlable individuellement, ce qui permet de créer une gamme illimitée de couleurs.

  • Page 35: Panneau Arrière

    PANNEAU ARRIÈRE :...

  • Page 36: Sélection De Mode

    SÉLECTION DE MODE: MODE COULEUR STATIqUE : Appuyez sur la touche Mode et sélectionnez, via les touches Haut/Bas, l'une des 7 couleurs désirées. 1 = rouge ; 2 = vert ; 3 = bleu ; 4 = jaune ; 5 = cyan ; 6 = violet ; 7 = blanc MODE CHANGEUR DE COULEURS Appuyez sur la touche Mode pour sélectionner le programme Colour Change.
  • Page 37 SÉLECTION DE MODE/ MODE CONTRÔLE DMX: Le Cameo PAR 56 CAN LED possède deux modes DMX : 4 canaux ou 6 canaux. Pour activer le mode 4 canaux, appuyez sur la touche Mode de façon Red Dot à faire apparaître un point rouge lumineux sous le premier chiffre de l'adresse DMX.
  • Page 38 COUPLAGE DMX: DMX-512 Le DMX (abréviation de Digital Multiplex) est un protocole de communication universel, utilisé entre contrôleurs et appareils d'éclairage. Un contrôleur DMX envoie des données DMX (des instructions) à l'appareil d'éclairage à contrôler. Les données DMX sont envoyées en série, et passent d'un appareil au suivant via les connecteurs XLR "DATA IN"...
  • Page 39 CÂBLES DMX: ATTENTION : • Si vous fabriquez vos câbles vous-même, conformez-vous aux figures 2 et 3. Ne reliez pas le blindage du câble à l'ergot de masse, et ne laissez pas le blindage entrer en contact avec l'extérieur du connecteur XLR. Mettre le blindage à...

  • Page 40: Caractéristiques

    CARACTÉRISTIqUES: CLP 56 WEIGHT & DIMENSIONS (WITHOUT BRACKET) Length 220 mm Width 220 mm Height 370 mm Weight 2.1 kg Beam angle 25 ° POWER Power consumption 25 W AC input 100 V AC - 250 V AC / 50 Hz / 60 Hz FUSE Main F1A for 120V / F2A for 250V...

  • Page 41: Limited Warranty

    MANUFACTURER´S DECLARATIONS: LIMITED WARRANTY This Limited Warranty applies to the Adam Hall, LD Systems, Defender, Palmer, Cameo and Eminence branded products. The statutory warranty rights towards the seller are not affected by this guarantee. In fact, it justifies, additional independent warranty claims towards Adam Hall.

  • Page 42: Limitation Of Liability

    MANUFACTURER´S DECLARATIONS: LIMITATION OF LIABILITY If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive remedy shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly limited to the lesser of the price you have paid for the product or the cost of repair or replacement of any hardware components that malfunction in conditions of normal use.

  • Page 43: Weee Declaration

    MANUFACTURER´S DECLARATIONS: WEEE-DECLARATION Your LD-Systems product was developed and manufactured with high quality materials and components wich can be recycled and/or reused. This symbol indicates that electrical and electronic equipment must be disposed of separately from normal waste at the end of its operational lifetime. Please dispose of this product by bringing it to your local collection point or recycling centre for such equipment.
  • Page 44 Thank you for choosing Cameo Lights! We have designed this product to give you reliable operation over many years. Please, take a few moments to read these instructions carefully, as we want you to enjoy your new Cameo Lights products quickly and to the fullest.
  • Page 45 PAR 56/64 FOCOS LED 1 W CLP56RGB1W / CLP64RGB1W...

  • Page 46: Medidas De Seguridad

    • If your product fails to function correctly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Cameo dealer for service. • Only use fuses of same type and rating.

  • Page 47: Operating Determinations

    SEGURIDAD: OPERATING DETERMINATIONS If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and the warranty becomes void. Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks, lamp failure etc. Do not endanger your own safety and the safety of others! Incorrect installation or use can cause serious damage to people and property.
  • Page 48 • LEDs de larga duración INSTRUCCIONES DE USO El foco LED de Cameo es un foco con mezclador de colores controlado por DMX-512, equipado con LEDs de alta eficiencia y ultrabrillantes. Dispone de tres colores (rojo, verde y azul) cuya intensidad se puede controlar individualmente, lo que permite crear una gama infinita de colores.

  • Page 49: Panel Posterior

    PANEL POSTERIOR:...

  • Page 50: Selección Del Modo

    SELECCIÓN DEL MODO: MODO COLOR FIjO: Pulse el botón MODE y utilice los botones UP (arriba) y DOWN (abajo) para seleccionar uno de los 7 colores siguientes: 1 rojo, 2 verde 3 azul, 4 amarillo, 5 cian, 6 violeta y 7 blanco. MODO CAMBIO DE COLOR Pulse el botón MODE para seleccionar la función de cambio de color.
  • Page 51 SELECCIÓN DEL MODO / MODO CONTROL DMX: El foco PAR LED de Cameo ofrece dos modos DMX: 4 canales o 6 canales. Para acceder al modo 4 canales, pulse el botón MODE para que se ilumine Red Dot el piloto rojo debajo del primer dígito de la dirección DMX. El equipo está...

  • Page 52: Conexión Dmx

    CONEXIÓN DMX: DMX-512 DMX (Digital Multiplex) es un protocolo universal utilizado como medio de comunicación entre equipos inteligentes y controladores. Un controlador DMX envía instrucciones de datos DMX al equipo. Los datos DMX se envían como datos serie que se transmiten de equipo a equipo a través de los conectores XLR "DATA IN”...
  • Page 53 CABLES DMX: NOTA: • Siga las instrucciones de las figuras 2 y 3 cuando fabrique sus propios cables. No conecte la malla del cable a la toma de tierra ni permita que la malla entre en contacto con la carcasa externa del XLR. La puesta a tierra de la malla puede causar un cortocircuito y un funcionamiento inestable del equipo.

  • Page 54: Características Técnicas

    CARACTERíSTICAS TÉCNICAS: CLP 56 WEIGHT & DIMENSIONS (WITHOUT BRACKET) Length 220 mm Width 220 mm Height 370 mm Weight 2.1 kg Beam angle 25 ° POWER Power consumption 25 W AC input 100 V AC - 250 V AC / 50 Hz / 60 Hz FUSE Main F1A for 120V / F2A for 250V...

  • Page 55: Limited Warranty

    MANUFACTURER´S DECLARATIONS: LIMITED WARRANTY This Limited Warranty applies to the Adam Hall, LD Systems, Defender, Palmer, Cameo and Eminence branded products. The statutory warranty rights towards the seller are not affected by this guarantee. In fact, it justifies, additional independent warranty claims towards Adam Hall.

  • Page 56: Limitation Of Liability

    MANUFACTURER´S DECLARATIONS: LIMITATION OF LIABILITY If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive remedy shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly limited to the lesser of the price you have paid for the product or the cost of repair or replacement of any hardware components that malfunction in conditions of normal use.

  • Page 57: Weee Declaration

    MANUFACTURER´S DECLARATIONS: WEEE-DECLARATION Your LD-Systems product was developed and manufactured with high quality materials and components wich can be recycled and/or reused. This symbol indicates that electrical and electronic equipment must be disposed of separately from normal waste at the end of its operational lifetime. Please dispose of this product by bringing it to your local collection point or recycling centre for such equipment.
  • Page 58 Thank you for choosing Cameo Lights! We have designed this product to give you reliable operation over many years. Please, take a few moments to read these instructions carefully, as we want you to enjoy your new Cameo Lights products quickly and to the fullest.
  • Page 59 REFLEKTOR DIODOWy PAR 56/64 1 W TRÓjKOLOROWE DIODy LED CLP56RGB1W / CLP64RGB1W...

  • Page 60: Środki Ostrożności

    • If your product fails to function correctly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Cameo dealer for service. • Only use fuses of same type and rating.

  • Page 61: Operating Determinations

    BEZPIECZEŃSTWO: OPERATING DETERMINATIONS If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and the warranty becomes void. Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks, lamp failure etc. Do not endanger your own safety and the safety of others! Incorrect installation or use can cause serious damage to people and property.
  • Page 62 • Diody LED o długiej żywotności INSTRUKCjA OBSłUGI Urządzenie Cameo LED CAN to sterowany za pomocą systemu DMX-512 punkt oświetleniowy z pełnym mieszaniem kolorów, wykonany z użyciem wysoko wydajnych i bardzo jasnych diod. Dostępne są trzy grupy kolorów (czerwony, zielony i niebieski), których natężeniem można sterować indywidualnie, co umożliwia tworzenie kolorów w nieograniczonym zakresie.

  • Page 63: Panel Tylny

    PANEL TyLNy:...

  • Page 64: Wybór Trybu

    WYBÓR TRyBU: TRYB KOLORU STATYCZNEGO: Nacisnąć przycisk „MODE” i za pomocą przycisków góra/dół wybrać jeden z 7 żądanych kolorów. 1 – czerwony, 2 – zielony, 3 – niebieski, 4 – żółty, 5 – błękitny, 6 – purpurowy, 7 – biały TRYB ZMIANY KOLORU Przyciskiem „Mode”...
  • Page 65 WYBÓR TRyBU / TRyB STEROWANIA DMX: W urządzeniu Cameo LED CAN dostępne są dwa tryby DMX: 4-kanałowy i 6-kanałowy. Aby uzyskać dostęp do trybu 4-kanałowego, naciśnij przycisk Red Dot Mode, aby zaświeciła się czerwona kropka pod pierwszą cyfrą adresu DMX.

  • Page 66: Połączenie Dmx

    POŁĄCZENIE DMX: DMX-512 DMX (Digital Multiplex – multipleks cyfrowy) jest uniwersalnym protokołem wykorzystywanym do komunikacji pomiędzy „inteligentnymi” urządzeniami a sterownikami. Sterownik DMX wysyła instrukcje danych DMX do urządzenia. Dane DMX są przesyłane pomiędzy urządzeniami jako dane szeregowe poprzez złącza XLR DATA IN i DATA OUT, znajdujące się we wszystkich urządzeniach DMX (większość sterowników jest wyposażona tylko w złącze wyjściowe DATA OUT).
  • Page 67 KABLE DMX: UWAGA: • Wykonując własne kable, postępować zgodnie z rys. 2 i 3. Nie podłączać ekranu kabla do zacisku uziemienia ani nie pozwalać, by ekran ten stykał się z zewnętrzną obudową złącza XLR. Uziemienie ekranu może spowodować zwarcie i nieprawidłowe zachowanie się urządzeń. wspólne Wyjście DMX-512 Wejście DMX-512...
  • Page 68 SPECYFIKACjA: CLP 56 WEIGHT & DIMENSIONS (WITHOUT BRACKET) Length 220 mm Width 220 mm Height 370 mm Weight 2.1 kg Beam angle 25 ° POWER Power consumption 25 W AC input 100 V AC - 250 V AC / 50 Hz / 60 Hz FUSE Main F1A for 120V / F2A for 250V...

  • Page 69: Limited Warranty

    MANUFACTURER´S DECLARATIONS: LIMITED WARRANTY This Limited Warranty applies to the Adam Hall, LD Systems, Defender, Palmer, Cameo and Eminence branded products. The statutory warranty rights towards the seller are not affected by this guarantee. In fact, it justifies, additional independent warranty claims towards Adam Hall.

  • Page 70: Limitation Of Liability

    MANUFACTURER´S DECLARATIONS: LIMITATION OF LIABILITY If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive remedy shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly limited to the lesser of the price you have paid for the product or the cost of repair or replacement of any hardware components that malfunction in conditions of normal use.

  • Page 71: Weee Declaration

    MANUFACTURER´S DECLARATIONS: WEEE-DECLARATION Your LD-Systems product was developed and manufactured with high quality materials and components wich can be recycled and/or reused. This symbol indicates that electrical and electronic equipment must be disposed of separately from normal waste at the end of its operational lifetime. Please dispose of this product by bringing it to your local collection point or recycling centre for such equipment.
  • Page 72 Thank you for choosing Cameo Lights! We have designed this product to give you reliable operation over many years. Please, take a few moments to read these instructions carefully, as we want you to enjoy your new Cameo Lights products quickly and to the fullest.
  • Page 73 PAR 56/64 LED CANS DA 1 W CLP56RGB1W / CLP64RGB1W...

  • Page 74: Misure Precauzionali

    • If your product fails to function correctly, discontinue use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Cameo dealer for service. • Only use fuses of same type and rating.
  • Page 75 SICUREZZA: OPERATING DETERMINATIONS If this equipment is operated in any other way, than those described in this manual, the product may suffer damage and the warranty becomes void. Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks, lamp failure etc. Do not endanger your own safety and the safety of others! Incorrect installation or use can cause serious damage to people and property.
  • Page 76 ISTRUZIONI PER L'USO Il Cameo LED CAN è un DMX-512 regolabile, con fascio di luce a miscelazione dei colori composto da LED ultra brillanti ad alta efficienza. Il sistema dispone di tre gruppi di colori (rosso, verde e blu) la cui intensità può essere regolata individualmente per creare un numero infinito di combinazioni di colori.

  • Page 77: Pannello Posteriore

    PANNELLO POSTERIORE:...

  • Page 78: Selezione Delle Modalità

    SELEZIONE DELLE MODALITÀ: MODALITÀ COLORE FISSO Premere il tasto mode e usare i tasti su e giù per selezionare il colore desiderato tra i 7 disponibili. 1 rosso, 2 verde, 3 blu, 4 giallo, 5 ciano, 6 porpora, 7 bianco MODALITÀ...
  • Page 79 SELEZIONE DELLE MODALITÀ / MODALITÀ DI CONTROLLO DMX: Il Cameo PAR LED CAN ha due modalità DMX tra cui scegliere, una a 4 e una a 6 canali. Per accedere alla modalità a 4 canali, premere il tasto mode fino Red Do a far apparire un punto rosso sotto la prima cifra dell'indirizzo DMX.

  • Page 80: Collegamento Dmx

    COLLEGAMENTO DMX: DMX-512 Il DMX (Digital Multiplex) è un protocollo universale, utilizzato come mezzo di comunicazione tra dispositivi intelligenti e unità di controllo. L'unità di controllo DMX trasferisce i dati DMX contenenti le istruzioni dall'unità di controllo agli apparecchi. I dati DMX vengono inviati in serie e viaggiano da un apparecchio all'altro tramite i connettori XLR di ingresso e di uscita dei dati presenti su tutte le apparecchiature DMX (la maggior parte delle unità...
  • Page 81 CAVI DMX: N.B.: • Assicurarsi di seguire le istruzioni riportate nelle figure 2 e 3 quando si procede alla fabbricazione dei propri cavi. Non collegare il conduttore schermato del cavo al capocorda di messa a terra ed evitare che il conduttore schermato venga a contatto con il rivestimento esterno del connettore XLR.
  • Page 82 SPECIFICHE: CLP 56 WEIGHT & DIMENSIONS (WITHOUT BRACKET) Length 220 mm Width 220 mm Height 370 mm Weight 2.1 kg Beam angle 25 ° POWER Power consumption 25 W AC input 100 V AC - 250 V AC / 50 Hz / 60 Hz FUSE Main F1A for 120V / F2A for 250V...
  • Page 83 MANUFACTURER´S DECLARATIONS: LIMITED WARRANTY This Limited Warranty applies to the Adam Hall, LD Systems, Defender, Palmer, Cameo and Eminence branded products. The statutory warranty rights towards the seller are not affected by this guarantee. In fact, it justifies, additional independent warranty claims towards Adam Hall.
  • Page 84 MANUFACTURER´S DECLARATIONS: LIMITATION OF LIABILITY If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive remedy shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly limited to the lesser of the price you have paid for the product or the cost of repair or replacement of any hardware components that malfunction in conditions of normal use.
  • Page 85 MANUFACTURER´S DECLARATIONS: WEEE-DECLARATION Your LD-Systems product was developed and manufactured with high quality materials and components wich can be recycled and/or reused. This symbol indicates that electrical and electronic equipment must be disposed of separately from normal waste at the end of its operational lifetime. Please dispose of this product by bringing it to your local collection point or recycling centre for such equipment.
  • Page 86 WWW.CAMEOLIGHT.COM Adam Hall GmbH | Daimlerstrasse 9 | 61267 Neu-Anspach | Germany Tel. +49(0)6081/9419-0 | Fax +49(0)6081/9419-1000 web : www.adamhall.com | e-mail : mail@adamhall.com...
