Do not use this equipment before reading this manual!
Model Number:
High Rider Bare
High Rider Complete
Low Rider Bare
Low Rider Complete
Printed in the U. S. A.
840
Airless Sprayer
800-130
800-131
800-132
800-133
Owner's Manual
For professional use only
i
NOTE: This manual contains important warnings
NOTE: This manual contains important warnings
and instructions. Please read and retain for
and instructions. Please read and retain for
reference.
reference.
0208 © Titan Tool Inc. All rights reserved. Form No. 313-1656, REV B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 840i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Titan 840i

Summary of Contents for Titan 840i

  • Page 1 Please read and retain for and instructions. Please read and retain for Low Rider Bare 800-132 reference. reference. Low Rider Complete 800-133 0208 © Titan Tool Inc. All rights reserved. Form No. 313-1656, REV B Printed in the U. S. A.

  • Page 2: Safety Precautions

    Consultation with a plastic surgeon or • Use lowest possible pressure to flush equipment. reconstructive hand surgeon may be advisable. • Do not spray onto pump assembly. © Titan Tool Inc. All rights reserved.

  • Page 3: Grounding Instructions

    • For electric units — Always unplug cord from outlet before working on equipment. • Do not use the hose as a strength member to pull or lift the equipment. • Do not lift by cart handle when loading or unloading. © Titan Tool Inc. All rights reserved.

  • Page 4: Table Of Contents

    OFF position in the black zone. This equipment produces a fluid stream at extremely high pressure. Read and understand the warnings in the Safety Precautions section at the front of this manual before operating this equipment. © Titan Tool Inc. All rights reserved.

  • Page 5: Preparing To Paint

    1. Place the siphon tube into a container of paint. Motor Running Motor Running Indicator 2. Place the return hose into a metal waste container. Indicator Programmer Port 3. Move the PRIME/SPRAY valve down to the PRIME Programmer position. Port © Titan Tool Inc. All rights reserved.

  • Page 6: Pressure Relief Procedure

    Proper lapping (overlap of spray pattern) is essential to an even finish. Lap each stroke. If you are spraying horizontally, aim at the bottom edge of the preceding stroke, so as to lap the previous pattern by 50%. © Titan Tool Inc. All rights reserved.

  • Page 7: Practice

    The cloth should be removed as soon as possible. 10. Turn the unit on and set the pressure to Turbo PulseClean Titan gun extensions are extremely helpful in these situations. by turning the pressure control knob to its CLEAN position Nearby objects such as automobiles, outdoor furniture, etc.

  • Page 8: General Repair And Service Notes

    NOTE: The filter body for recommendations. should be hand- tightened, but make O-ring 4. If you have any further questions concerning your TITAN Airless Sprayer, call TITAN: sure it is seated fully into the filter Customer Service (U.S.) .......1-800-526-5362 Filter Housing housing.

  • Page 9: Replacing The Motor Assembly

    Front End Bell Assembly Gearbox Motor Mounting Armature Gear Housing Screw 1st Stage Gear Electronic Control Assembly 2nd Stage Gear Motor Front Gear Box Baffle Assembly Assembly Housing Housing Gasket Gasket Shroud Gasket Shroud Gasket © Titan Tool Inc. All rights reserved.

  • Page 10: Replacing The Transducer

    4. Remove the return hose from the clamp on the siphon tube. 5. Unscrew the siphon tube/siphon set from the foot valve. 6. Loosen and remove the high-pressure hose from the nipple on the back of the upper housing of the fluid section. © Titan Tool Inc. All rights reserved.
  • Page 11 35. Turn on the sprayer by following the procedure in the “Operation” section of this manual and check for leaks. NOTE: Repacking kit P/N 800-273 is available. For best results use all parts supplied in this kit. © Titan Tool Inc. All rights reserved.

  • Page 12: Troubleshooting

    2. Needle assembly out of adjustment 2. Adjust 3. Dirty gun 3. Clean Gun does not spray 1. No paint 1. Check fluid supply 2. Plugged filter or tip 2. Clean 3. Broken needle in gun 3. Replace © Titan Tool Inc. All rights reserved.

  • Page 13: Spray Patterns

    2. Use a minimum of 50' (15m) of 1/4" high pressure hose 3. Tip too large or worn 3. Replace with a new or smaller tip Patents These products are covered by one or more of the following U.S. patents: 4,500,119 4,768,929 © Titan Tool Inc. All rights reserved.

  • Page 14: Français

    • Se servir de la pression la plus basse possible pour vidanger s’avérer nécessaire de consulter un plasticien ou un spécialiste l’appareil. en chirurgie reconstructive de la main. • Ne pas pulvériser de produit sur la pompe. Français © Titan Tool Inc. Tous droits réservés.
  • Page 15 électrique de la prise avant de travailler sur l’équipement. • N’utilisez pas le tuyau pour tirer ou soulever l’équipement. • Ne pas soulever par la poignée de chariot en chargeant ou en déchargeant. Français © Titan Tool Inc. Tous droits réservés.

  • Page 16: Español

    Puede ser • No rocíe el ensamblaje de la bomba. aconsejable consultar con un cirujano plástico o un cirujano especialista en reconstrucción de las manos. Español © Titan Tool Inc. Todos los derechos reservados.
  • Page 17 • No utilice la manguera como elemento de fuerza para tirar del equipo o levantarlo. • No levantar por la manija del carro al cargar o descargando. Español © Titan Tool Inc. Todos los derechos reservados.

  • Page 18: Parts Listings

    PRIME/SPRAY valve assembly....1 858-625 Screw............2 800-269 Fitting ............1 800-328 Knock-off nut..........1 800-267 Fitting ............1 800-300 Fluid section assembly .......1 860-002 Lock washer..........2 451-241 Siphon tube..........1 860-535 Screw............2 730-334 Hose clamp..........1 800-266 Hose (not shown) ........1 © Titan Tool Inc. All rights reserved.

  • Page 19: Drive Assembly

    Circuit breaker ..........1 800-366 Wire cover, 7” (not shown) ......1 800-075 Mounting plate ..........1 800-368 Wire assembly (not shown) ......1 NOTE: All electrical work should be performed by a Titan authorized service center. © Titan Tool Inc. All rights reserved.

  • Page 20: Fluid Section Assembly

    NOTE: When repacking the fluid section, make sure the raised lip on the bottom of the lower packing is fully outside the packing around the piston rod after insertion of the piston rod. © Titan Tool Inc. All rights reserved.

  • Page 21: High Rider Cart

    800-915 PRIME/SPRAY valve assembly....1 800-279 Cart (includes items 7 and 9) .....1 800-907 Plug, 1/4” ............1 335-018 Plug.............2 800-437 Transducer..........1 856-002 Washer............4 856-921 Screw............4 800-007 Axle.............1 670-109 Wheel............2 870-004 Washer............2 800-019 Cap .............2 © Titan Tool Inc. All rights reserved.

  • Page 22: Siphon Set Assembly (Low Rider)

    Handle assembly 800-109 Wheel spacer..........2 (includes items 1–3 and 5–7) .....1 800-593 Wheel............2 590-508 Roll pin............2 800-111 Cap .............2 856-921 Screw............4 800-112 Cart weldment (includes items 8 and 10)...1 856-002 Washer............4 700-674 Plug.............2 © Titan Tool Inc. All rights reserved.

  • Page 23: Prime/Spray Assembly

    Potentiometer Assy BLACK ORANGE 800-277 Electronic Control Assy GREEN Motor BLACK WHITE Relay 800-276 WHITE Indicator Lights Assembly 800-278 BLACK/RED/WHITE NOTE: All electrical work should be performed by a Titan authorized service center. © Titan Tool Inc. All rights reserved.

  • Page 24: Warranty

    Warranty Titan Tool, Inc., (“Titan”) warrants that at the time of delivery to the original purchaser for use (“End User”), the equipment covered by this warranty is free from defects in material and workmanship. Titan’s obligation under this warranty is limited to replacing or repairing without charge those parts which, to Titan’s reasonable satisfaction, are shown to be defective within twenty-five (25) months after sale to the End User.
