E-LED TV
50
OpEraTing insTrUcTiOn
ENG
please read these instructions before operating
your set and retain them for future reference.
Model: J50E602B1
EUF800-H107

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the J50E602B1 and is the answer not in the manual?

Questions and answers

Related Manuals for Tesla J50E602B1

Summary of Contents for Tesla J50E602B1

  • Page 1 E-LED TV OpEraTing insTrUcTiOn please read these instructions before operating your set and retain them for future reference. Model: J50E602B1 EUF800-H107...
  • Page 3 PRECAUTION 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. This is a CLASS II device. 6. Do not use the device near water. Please protect it from dripping or splashing and make sure that no objects filled with liquid, such as vases, are placed on the device.
  • Page 4 CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. Batteries shall not be exposed to excessive heat such as sunshine, fire or the like. Used batteries should not be thrown into garbage, please dispose of them at an appropriate place.

  • Page 5: Important Information

    ImPORTANT INfORmATION If a television is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling. Many injuries, particularly to children, can be avoided by taking simple precautions such as: • Using cabinets or stands recommended by the manufacturer of the television. • Only using furniture that can safely support the television.
  • Page 6 • Place the TV on a firm and flat surface, leaving a space of at least 10cm around the set and 30cm from the top of the set to the wall or cabinet. Ensure the TV is positioned close to the wall to avoid it falling when pushed. 10cm 30cm 10cm...

  • Page 7: Table Of Contents

    Contents 1. Connection and Preparation of TV ......8 1.1 Accessories......... 8 1.2 Installation of Stand .

  • Page 8: Connection And Preparation Of Tv

    1. connection and preparation of TV 1.1 accessories • User Manual x1 • Warranty card x1 • Remote Control x1 • Battery (UM-4/R03P/AAA) x2 1.2 installation of stand 1. Place the TV with the front panel facing downwards on the soft cloth or soft pads on a desk.

  • Page 9: Keys And Interfaces

    1.3 Keys and interfaces The design and speciication take actual products as standard. 1. Remote sensor window 2. Power indicator 3. Power switch 4. Menu key 5. Program+ key 6. Program- key 7. Volume+ key 8. Volume- key 9. Source key 10.

  • Page 10: Remote Control

    1.4 remote control 1. STANDBY ( ): Standby turn on and off 2. SOURCE Select signal source 3. 0~9 Continue to press the keys to select a channel 4. DISPLAY Display the information of current video and audio 5. RECALL Return to previous channel 6.

  • Page 11: Installation Of Batteries

    1.5 installation of Batteries 1. Open the back lid of the remote control. 2. Install two 7#(AAA)1.5V batteries. Make sure that the polarity of batteries is correct. 3. Cover the back lid. Please take the batteries out of the remote control if not in use for long time.

  • Page 12: Select Input Source

    3. select input source Press SOURCE button to display the input source list. or SOURCE button to select the input source you want Press / to, press ENTER button to enter the input source, then press EXIT button to quit. 4.

  • Page 13: Main Menu Operation

    5. Main Menu Operation 5.1 picture Menu Press MENU button to display the main menu. Press button select PICTURE in the main menu, then press ENTER to enter. 1. Press button to select the option that you want to adjust in the PICTURE Menu. 2.
  • Page 14 Aspect Ratio Press button to select Aspect Ratio, then press button to select. Auto Automatically adjust Aspect Ratio based on the TV size and TV program. Full/4:3 /Zoom1/Zoom2 To select the available display format. PC Setting Press SOURCE to select PC source. Press MENU to enter the main menu, then press button to select PICTURE menu.

  • Page 15: Sound Menu

    Dynamic Contrast Automatically adjust picture clarity and brightness. Press button to select Dynamic Contrast, then press button to select. (Available Dynamic Contrasts: Off, Week, Medium, Strong). 5.2 sound Menu Press MENU button to display the main menu. Press button to select SOUND in the main menu, then press ENTER to enter.

  • Page 16: Channel Menu

    Set auto volume control. Press button to select AVL, then press button to select On or Off. SPDIF Press button to select SPDIF then press button to select Off /Auto /PCM. Audio Description Press button to select Audio Description, then press Enter button to enter sub-menu.
  • Page 17 Auto Scan Press button to select Auto Scan, then press ENTER button to enter sub- menu. Tuner type is Antenna Tuner type is Cable Country Press button to select country. Mode Press button to select Mode: DTV+ATV, DTV, ATV. Scan Type Press button to select Scan Type: Advanced, Quick, Full.
  • Page 18 Digital Manual Scan button to select Digital Manual Scan, then press ENTER Press button to enter sub-menu. Tuner type is Antenna Tuner type is Cable Network ID Press button to select Network ID: Auto or enter digital numbers. Frequency Press button to select Frequency: Auto or enter digital numbers.
  • Page 19 Color System Press button to select Color System: Auto, PAL or SECAM. Sound System Press button to select Sound System: Auto, DK, BG, I or L. Automatic Fine tuning. Press button to select select On or Off. Start Press ENTER button to start channel searching.

  • Page 20: Lock System Menu

    5.4 Lock system Menu Press MENU button to display the main menu. Press button to select Lock system in the main menu, then press ENTER to enter. 1. Press button to select the option that you want to adjust in the PARENTAL menu.

  • Page 21: Setup Menu

    5.5 setup Menu Press MENU button to display the main menu. Press button select SETUP in the main menu, then press ENTER to enter. 1. Press button to select the option that you want to adjust in the SETUP menu. 2.
  • Page 22 Teletext Adjust Teletext settings. Only available under DTV and ATV source. Press button to select Teletext, then press ENTER button to enter sub-menu. Under DTV source, press button to select Digital Teletext Language. Under ATV source, press button to select Decoding Page Language.
  • Page 23 Time Press button to select Time, then press ENTER button to enter sub-menu. Set Auto Sync to Off, Power On/Off Timer to On, then you can set the time manually. Note: In case of power loss, the clock setup will be lost. PVR Settings Press button to select PVR Settings, then press ENTER button to enter sub-menu.

  • Page 24: Usb Operation

    aTV / HDMi / aV / Ypbpr / pc 1. PC Setting in PICTURE menu is aviliable in PC Input only. Screen Mode in PICTURE menu and HDMI CEC Control in SETUP menu is aviliable in HDMI Input only. 2. Audio Description and Sound Type in AUDIO menu is invalid. 3.

  • Page 25: Music

    6.2 Music Press button to select MUSIC in the main menu, then press Enter button to enter. Press button to select the drive disk you want to watch, then press Enter button to enter. Press button to select return option to go back to the previous menu.

  • Page 26: Technical Specification

    7. Technical specification Product Model J50E602B1 Screen Size 50” diagonal Aspect Ratio 16:9 Power Supply AC 100-240V~, 50/60Hz Power Consumption 130W TV System PAL B/G D/K I, SECAM B/G D/K DVB-T Audio Output Power (Internal) 8Wx2 Input Terminal Antenna Input x1...

  • Page 27: Supported Signal Modes

    8. supported signal Modes a. Vga Mode Resolution Horizontal Frequency (Khz) Vertical Frequency (Hz) 640 x 480 31.50 60.00 800 x 600 35.16 56.25 37.90 60.00 1024 x 768 48.40 60.00 1366 x 768 47.70 60.00 1920 x 1080 67.50 60.00 Note: In order to ensure optimal quality of picture, it is suggested that the VGA connecting cord in use is no more than 5 meters long.

  • Page 28: Simple Troubleshooting

    9. simple Troubleshooting If the display breaks down or performance changes dramatically, check the display in accordance with the following instructions. Remember to check the peripherals to pinpoint the source of failure. Symptom Solution Power cannot be turned • Check that both ends of power cable are plugged into on.
  • Page 30 Model: J50E602B1 EUF800-H107...
