AVE MX 4 User Manual

Analogue/digital 4-channel mixer

Advertisement

Quick Links

Audio Vertriebs-
Entwicklungsgesellschaft
mbH
MX 4
Analogue/digital 4-channel mixer
User guide
Table of contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX 4 and is the answer not in the manual?

Questions and answers

Summary of Contents for AVE MX 4

  • Page 1 Audio Vertriebs- Entwicklungsgesellschaft MX 4 Analogue/digital 4-channel mixer User guide Table of contents...
  • Page 2: Table Of Contents

    Introduction ......................... 3 Security advice ....................3 Description of front and rear panel ................4 Basic operation of the MX-4 ..................5 Programmable settings („presets“) ..............5 Changing between presets ................5 Temporarily changing an existing preset ............6 Extended functions ..................... 6 Programming a new preset (or reprogramming an existing one) ......
  • Page 3: Introduction

    Introduction Thank you for choosing the A.V.E. analogue/digital 4-channel mixer MX-4 with four microphone/line inputs; an outstanding unit that was designed particularly for superior audio quality in churches. Each microphone/line input is equipped with a compressor/limiter, 3-band equalizer, as well as indicators for volume, operating status, and peak, respectively.
  • Page 4: Description Of Front And Rear Panel

    Description of front and rear panel 1. Volume control (for channels 1 – 4): Allows adjustment of the level of the signal sources connected to the microphone/line inputs (26.). During installation by the technician, the optimal level will be marked on the unit. 2.
  • Page 5: Basic Operation Of The Mx-4

    Power connector: Connector for power cord to a 230 V / 50 Hz AC voltage source. Fuse: 315 mA Main on/off switch Output: Output connectors (to power amplifiers, etc.) Direct OUT: Direct output without any signal processing. This output can be used for capturing and transmitting the ambiance of e.g.
  • Page 6: Temporarily Changing An Existing Preset

    name (in this case „Sonntag“) as well as the value of the master volume in percent (total output volume, here 70%). The bar above the preset name is an analogue representation of the master volume.  On the right-hand side of the display the four little squares represent the 4 outputs (the numbers 1 through 4 are written above and below the display).
  • Page 7: Programming The Mx-4 / The Parameter Menu

    name has been given so far).  In case you wish to choose a different preset slot, briefly push the volume knob twice. That way you move back to the main menu and can chose a different preset by pushing and turning the preset knob. ...
  • Page 8: Preset

     Turning the preset knob one click to the right will always bring you to the next item of a menu, i. e. to the next parameter to be programmed. This knob is therefore also marked „parameter“. For simplicity, we will continue to name this knob the preset knob. ...
  • Page 9: Config

     Param EQ 1 Q: Set the Q-factor for the 1 band (range: 0.2 to 100; logarithmic increments 0.2, 0.22, 0.25, 0.28, 0.32, etc.). The high Q-factors enable extremely narrow-band notch-filters for ideal feedback elimination.  Param EQ 2-4 Freq: Proceed as described above for bands 2, 3, and 4. ...
  • Page 10: Quick Reference: Table With All Programmable Parameters

    4.2.5 Quick reference: Table with all programmable parameters Where is which parameter set? The following table lists the parameter menu with its items and parameters: Item Parameter Description Preset Preset name Name of the preset Preset master volume Master volume of the preset Preset output Choice of active outputs Parameters...
  • Page 11: Phantom Voltage, Microphone/Line, High-Pass Filter

    EFORE OPENING THE UNIT TURN IT OFF AND REMOVE THE POWER CORD NLY THEN REMOVE THE SIX SCREWS AN THE COVER 4.3.1 Phantom voltage, microphone/line, high-pass filter These modifications are performed by means of jumpers. Within the MX-4, there are two groups of jumpers for each of the four outputs.
  • Page 12: 3-Band Equalizer, Compressor/Limiter, Gain, Threshold

    The following image shows the second group of jumpers: 6 jumpers for each of the four channels. (The numbers 1 through 6 denote the six potentiometers for each channel. Their functions will be described in section 4.3.3)  THD: low noise threshold, on/off. A noise gate, determining the response sensitivity of the microphones, can be either enabled or disabled here.
  • Page 13: Microprocessor Gate Control

    6. Low frequencies:  12 dB at 70 Hz 4.3.4 Microprocessor Gate Control  Continous level monitoring of 8 input channels by RISC microprocessor  Level compare accuracy better than ±2 dB  Channel on attack time less than 10 ms ...
  • Page 14  VariGraph: frequencies for the bands 1 and 12 can be arbitrarily chosen (for each channel, minimum spacing approx. 2 octaves), Q-factors as well as all intermediate bands are automatically calculated accordingly (allows for an optimal adaption of the equalizer to each application) Fully parametric equalizer ...
  • Page 15  Output level Out 1, 2, 3, 4: 0 dBu (with master volume at 82 %)  Output level OUT 1, 2, 3, 4: +9 dBu (with master volume at 100 %)  Output impedance Direct-OUT: 140  balanced; 70  unbalanced ...
  • Page 16 AVE mbH Corporation. Trademarks AVE mbH and the AVE logo are trademarks or registered trademarks of AVE mbH in the Germany and other countries. Other company and product names may be trademarks of the respective companies with which they are associated.
