- Page 1 For questions contact: Controlled Energy Corp. 340 Mad River Park Waitsfield VT 05673 TOLL FREE 866-330-2729 www.ControlledEnergy.com/tech...
-
Page 2: Table Of Contents
Important Safety Instructions When using this electrical equipment, basic safety precautions should always be followed, including the following: READ AND FOLLOW ALL INSTRUCTIONS. This appliance must be grounded. Disconnect this product from the electrical supply before cleaning, servicing or removing the cover. -
Page 3: Using The Powerstar
Using the PowerStar WARNING Do not use the unit if you think it may be frozen, as this could result in serious damage to the unit. Wait until you are sure that it has completely thawed out before you switch it on. •... -
Page 4: Mounting On The Wall
WARNING The unit must only be installed in the orientation shown in Diagram 1, i.e., mounted in a vertical position with the water fittings located at the bottom of the unit. Under no circumstances should the unit be mounted differently. •... - Page 5 Wiring to the unit WARNING The unit must be installed by a qualified electrician, in accordance with the current version of the National Electrical Code. The unit must be grounded. IMPORTANT When the PowerStar is not within sight of the electrical circuit breakers, a circuit breaker lockout or additional local means of disconnection for all non-grounded conductors must be provided that is within sight of the appliance.
- Page 6 Diagram 2 (AE115 unit) Supply 1 Supply 2 Diagram 3 (AE125 unit) Supply 1 Supply 2 Supply 3 • Make sure the terminal block screws are tightened securely. Loose connections can cause wires to heat up. • Make sure that the ground wire is wrapped around its terminal stud and into the saddle washer. The nut should be tightened securely.
-
Page 7: Spare Parts
Spare Parts Part Number Description For further information ask your (Refer to Diagram 1, Page 3) local dealer. 93 793770 4 way term. block (for AE115) FOR SERVICE AND INSTALLATION 93 793771 6 way term. block (for AE 125) QUESTIONS CALL TOLL FREE: 93 793772 Front cover 866-330-2729 (Toll Free) - Page 8 Graph 1 Outlet Temperature vs Maximum Flow Rate Setting (based on incoming water temperature of 55 Outlet Temperature ( For example: • For the AE115 unit, using a ball valve, ensure the flow rate does not exceed 2.3 US gallons / minute. •...
-
Page 9: How The Powerstar Works
How the PowerStar works • The PowerStar heats water instantaneously as it flows through the heater modules. • The electronic control monitors the flow rate and the incoming water temperature and then switches on the required number of heater modules to reach the temperature set by the adjustment dial. •... -
Page 10: Specifications
Specifications AE115 Unit AE125 Unit Voltage supply 2 x 240V AC 3 x 240V AC Amperage 2 x 40 A 3 x 40 A Maximum output 17.25 kW 26.85kW Temperature control range F to 131 F to 131 Pressure range 15 psi to 150 psi 15 psi to 150 psi Minimum flow rate... -
Page 11: Warranty
Symptom Cause What to do Adjust the water flow (see Water flow is too high. Graph 1 on Page 8). One of the power supplies is Check the supply voltages to the not on. heater and rectify if necessary. This is likely an issue with the power supply. - Page 12 Any Component Part Other Than the Heat Exchanger - If any other component part (other than the heat exchanger) proves to be defective in material or workmanship within one (1) year from the date of original installation of the water heater, CEC will furnish the owner with a replacement of the defective part(s).
