Keypad Control and Speaker Cable Wiring

The Genesis rooms wire in such a way that most every room's wiring is identical to the next.
The most important consideration to remember when wiring a Genesis System's room, is that
the speaker cable needs to wire past (through) the keypad's location and then back to the
system mainframe (home). Since the volume is controlled locally in each room, using either
the volume attenuator (autoformer) built into a Genesis keypad or controlled by a Decora style
volume attenuator (you have provided) when using the MC-1111 Decora control (shown
below), you will need the speaker's cable connected to the volume attenuator. Furthermore,
the keypad's control cable is a separate cable from the room's speaker cable.
Note
Even when using the Millennium System's 12 Conductor Control Cable with overall Foil Shield
and Drain for the Genesis, while there would be enough extra conductors available for use as
a speaker cable, the 20 Gauge (or 22 Gauge) wire is not the ideal gauge for powering speakers.
For the separate speaker cable, ADA recommends running a 4 Conductor/16 Gauge speaker
cable. This cable should loop through the keypad's wall box and can be cut during wire
termination. You can also opt to run a 4 conductor speaker cable to the keypad location from
the mainframe, while running two separate 2 Conductor speaker cables to the speakers from
the keypad location, one to the right channel speaker and one to the left channel speaker.
CAUTION: DISCONNECT SUPPLY CORD
AUDIO INPUTS BEFORE SERVICING.
ATTENTION: DEBRANCHER AVANTE
1
LE DEPANNAGE.
PROGRAM
2ND FUNCTION
2
1ST FUNCTION
3 POWER ON
IR
IR
SENSOR
REC
ERROR
OUT WARNING! RISK OF
HAZARDOUS ENERGY!
MAKE PROPER SPEAKER
OK
VAR
AVERTISSEMENT! ENERGIE
OUT
ELECTRIQUE DANGEREUSE!
PGM
FAIRE DES CONNEXIONS PROPRES
LOOP
POUR L'HAUTPARLEUR. VOIR LA
NOTICE DE FONCTIONNEMENT.
AMP
IN
IR OUTPUT
4 COND.
SPEAKER
CABLE
MULTI-CONDUCTOR
CONTROL CABLE
(MIN. 8 WIRES)
1 1
2 2
3 3
4 4
5 5
GENESIS
6 6
7 7
CAUTION
RISK OF ELECTRIC SHOCK
8
DO NOT OPEN 8
ATTENTION!
RISQUE DE CHOC ELECTRIQUE.
NE PAS OUVRIR
CONTROL CONTROL
MADE IN U.S.A.
INPUT INPUT
ROOM 1
ROOM 2
SPEAKER SPEAKER
CONNECTIONS.
OUTPUT OUTPUT
Ω Ω
Ω Ω
2 -16 2 -16
1 + 1 +
R R
2 - 2 -
3 - 3 -
L L
4 + 4 +
FM
DISC
AUX
ROOM
OFF
ROOM
2
FM
DISC
1
AUX
ROOM
OFF
ROOM
1
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8
8
CONTROL CONTROL CONTROL
INPUT INPUT INPUT
ROOM 3 ROOM 4 ROOM 5
SPEAKER SPEAKER SPEAKER
OUTPUT OUTPUT OUTPUT
Ω Ω Ω Ω Ω
2 -16 2 -16 2 -16
1 + 1 +
R R
2 - 2 -
3 - 3 -
L L
4 + 4 +
FM
DISC
1 1
AUX
ROOM
OFF
ROOM
4
FM
DISC
1
AUX
ROOM
OFF
ROOM
3
- 17 -
SWITCHED AC
1
2
3
SOURCE
4
ONE
5
6
7
8
SOURCE
TWO
CONTROL
INPUT
ROOM 6
STANDBY
SOURCE
2/10A S.B.
THREE
SPEAKER
OUTPUT
AMP
Ω Ω Ω
2 -16
5A S.B.
MAIN
1 +
OUTLET
R MAIN
2 -
7.5A S.B.
3 -
L
4 +
SW AC - 2.5A MAX
FM
DISC
1
AUX
ROOM
OFF
ROOM
1
FM
DISC
1
AUX
ROOM
OFF
ROOM
5
A
C
I
N
P
U
T
