SPECIAL FEATURES
Capacity limit
The charging capacity is always calculated as the charging current multiplied by time. If the charging
capacity exceeds the limit, the process will be terminated automatically when you set the maximum
value.
Temperature threshold
The battery's internal chemical reaction will cause the temperature of the battery to rise. If the
temperature limit is reached, the process will be terminated. This function is available by connecting
temperature probe, which is included in the package.
Processing time limit:
You can also limit the maximum process time to avoid any possible defect.
Data store/load
For users convenience, it can store maximum 10 data of different batteries. You can establish
the data contains program setting of the battery to charge or discharge. These data can be called
back at any time you need and the process can be executed without program setting.
Cyclic charging/discharging
1 to 5 cyclic and continuous process of charge>discharge or discharge>charge is operable for battery
refreshing and balancing to stimulate the battery's activity.
PC based analysis using USB Communication
The B6 Ultimate is fitted with a mini USB port on the right-hand side of the case; a USB wire can be
connected to this socket in order to link the charger to a PC. "Charge Monitor" program enable you
to view graphs of charge and discharge curves, with a capacity, voltage, temperature and ampere display,
and individual curves can be individually suppressed or superimposed to allow a visual comparison of the
data.
07
PC based analysis using USB
Communication
USB Power Supply
The USB power supply can provide 5V, 1A continue current. You can power your mobile phone, digital
camera or even your IPod via the USB power supply.
SPECIAL FEATURES
USB Power Supply
