DISCHARGING OF THE PB BATTERY

Discharging of the Pb battery
Set up the discharge current on the left and nominal voltage on the right.
Range of discharge current is 0.1-5.0A, the voltage should match the
battery being charged. Press START/ENTER key for more than 3
seconds to start charging.
The screen displays the real-time discharging status. Press
START/ENTER key to alter discharge current. Press START/ENTER key
again to store the parameter value you set. Press BATT TYPE/STOP key
to end the program.
31

Storage data program

For your convenience, the Prodigy 610 has a data storage and load program. It can store ten
batteries data representing the respective specifications of batteries. You can call back the data
when charging or discharging without setting up the program again. Press START/ENTER key to
make it blink, and use INC or DEC to set up the parameter.
Setting of the parameter in the screen will not affect the charge and
discharge process. They just present the specification of the battery.
The example is NiMH battery pack, including 12 cells, the capacity is
3000m Ah.
Set up the charge current in the manual mode, or current limit in the
auto mode. Press INC and DEC key simultaneously to make the
current field blink to switch the charge mode.
Set up the discharge current and final voltage.
STORAGE DATA PROGRAM
32
