Dual Channel In-Ceiling
Speakers
from EMPHASYS are de-
signed to deliver crisp, full-range sound
for today's home theater and distrib-
uted audio environments, where digital
media places extreme demands on a
speaker's capability. But while ordinary
speakers must be used in matching pairs
for correct stereo reproduction, the
Dual Channel In-Ceiling Series models
deliver awesome stereo sound from a
single speaker. EMPHASYS engineering
has combined a dual voice coil woofer
with twin tweeters, and as a result the
Dual Channel In-Ceiling models bring
high-quality stereo audio to even the
smallest room.
DC85 DC60
Installer's Guide

Positioning the Speakers

It is best, with the Dual Channel
In-Ceiling speaker or any
other unit, to position it
so that it aims directly
toward the listening
position. This will
ensure an accurate
stereo image and
help minimize the
creation of excessive
sound reflections.
If the listening room is
very large or the ceiling
is high, the DC85—with its 8"
aluminum woofer and greater power
handling—will be preferable to the DC60.

Advertisement

Table of Contents

   Summary of Contents for Emphasys DC85

  • Page 1: Positioning The Speakers

    If the listening room is with twin tweeters, and as a result the very large or the ceiling Dual Channel In-Ceiling models bring is high, the DC85—with its 8" high-quality stereo audio to even the aluminum woofer and greater power smallest room.
  • Page 2: Speaker Adjustments

    This will ensure an accurate stereo image and help minimize the creation of excessive sound reflections. If the speakers are to be mounted in a very high ceiling, the pivoting tweeters of the DC85 should be aimed directly toward the listening position. (See Diagram 1) In other cases it might be preferable to aim the tweeters slightly outward, away from the listening position.
  • Page 3: Installing The Speakers

    The paint masks provided in the carton must be installed between the grille and flange while they are being painted. Be sure to EMPHASYS recommends only light spray painting using five parts remove the white plastic blanket from beneath the grille before thinning agent to one part paint.
  • Page 4 Vendor’s to the terms of this standard warranty. Purchaser agrees that EMPHASYS shall expense or refund the purchase price. Replacement of any item hereunder...
