External Control Harness
Caspian UVC
(Universal Concealed)
Installation and User Guide
User Information.
Installation of this product must be carried out by a qualified electrician.
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance. Cleaning and user
maintenance shall not be made by children without supervision. (Refer
EN 60335-1 clause 7.12).
Advertisement
Related Manuals for Smith's Heating First External Control Harness Caspian UVC
Summary of Contents for Smith's Heating First External Control Harness Caspian UVC
- Page 1 Products with this symbol (crossed out wheelie bin) cannot be disposed as household waste. Old electrical and electronic equipment must be recycled at a facility capable of handling these products and their waste by-products. If you are purchasing replacement equipment your retailer may offer a 'take back' scheme, or will be able to give details of the nearest approved authorised treatment facility.
- Page 2 __________________NOTES__________________ Introduction __________________________________________ This harness is for use with Smith’s Caspian Universal concealed range of products. The wall mounted control enables the fan speed to be adjusted and controlled remotely from the heater. This accessory can also be used in addition with Smith’s Adjustable low temperature cut-out. __________________________________________ Note: To facilitate remote wall mounting of the speed controller the user will need to prepare a suitable single gang pattress box (not supplied) for the wall plate to attach...
- Page 3 Installing the harness or harnesses to link a maximum of four machines together. Follow these instructions when using the harness to mount the controller externally from the heater: The harness should only be used to link heaters together when the master controller has been ENSURE THAT THE ELECTRICAL SUPPLY TO THE PRODUCT HAS BEEN ISOLATED removed from the master heater and mounted on the wall.
- Page 4 Linking multiple units together On the back side of the electrical panel there will be a stain relief cable clamp, Unscrew and fasten onto the exiting harness to the electrical panel (See Fig 5). Fig 5 Speed C ontroller TO FAN FIX CABLE CLAMP TO HOLES ON THE BACK OF Fig 4...
