- Page 1 HARVIA IRON STOVE Instructions for installation and use Harvia 10 06112013VTT...
- Page 2 Congratulations on a good choice of fireplace and thank you for your confidence in Harvia’s products. Read these instructions carefully before using the fireplace and save them for future reference. Iron stoves are long-lasting and reliable heat sour- ces when used correctly. Harvia’s iron stoves are designed to be safe and easy to use, while also looking good.
- Page 3 Fire chamber Cast iron Maximum lenght of firewood (cm) Diameter of firewood (cm) 8–15 Table 1. Technical Data Harvia Oy, PL 12, 40951 Muurame, Finland EN 13240:2001 Harvia 10 iron stove WU100 Intended use Intermittent burning room heater Fuel Wood...
- Page 4 2.2. Fuel sure that they burn down. Harvia iron stoves can use wood as a fuel (with a 8. The damper must not be closed until the length of 20–30 cm). The fuel must be dry.
- Page 5 The combustion gases are removed through a The iron stove is not suitable for installation in Harvia modular smoke pipe or a smoke flue made • a shared flue system. of bricks with a minimum size of 140 x 140 mm.
- Page 6 The smoke flue can be connected to the top, back or and push the iron stove into place. Leave a sides of Harvia’s iron stoves (figure 2). The stoves space of approximately 50 mm between the supplied directly from the factory are equipped with wall and the back of the furnace.
- Page 7 NOTE! For more detailed installation instructions, see the Instructions for installation of Harvia modular smoke pipes Rain cap Upper end Steel Chimney extension 1 m Clamp Rain flange (rubber) Minimum distance 100 mm Lead-through protector Lead-through insulation ZSH-200 or 100 mm...
-
Page 8: Spare Parts
4. SpARE pARTS Spare parts can be purchased at Harvia retailers. Glass for the stove door (171 mm x 171 mm) ZTS-37 Seal to the door WX055 Frame for hot plate (stainless steel) WX050 Glass door for the stove WX051...
