FCC Notice
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in residential installation.
This equipment generates, uses and can radiate radio frequency energy and if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, detectable by turning the equipment in question off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna
Increase the distance between the equipment and the receiver
Connect the equipment to an outlet on a different circuit than that which the receiver
is connected to
Or consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to following
two conditions:
1.
This device may not cause harmful interference, and
2.
This device must accept any interference that may cause undesired operation.
http://www.pureglare.com.au
EN-1
Advertisement
Table of Contents
Related Manuals for BenQ MP514
Summary of Contents for BenQ MP514
-
Page 1: Fcc Notice
FCC Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 2: Safety Instructions
Safety Instructions Read all of these instructions before you operate your projector and save for future reference. Read instructions All the safety and operating instructions should be read before the appliance is operated. Notes and warnings All notes and warnings in the operating instructions should be adhered to. Cleaning Unplug the projector from the wall socket before cleaning. -
Page 3: Table Of Contents
CONTENTS Introduction ....................... 4 Projector Features ....................... 4 Package Contents ....................... 5 Projector Overview ...................... 6 Using the Product ..................8 Control Panel ......................8 Connection Ports ......................9 Remote Control ......................10 Replacing the Battery ....................11 Remote Control Operation ..................12 Installation ...................... -
Page 4: Introduction
Introduction Projector Features The projector integrates high-performance optical engine projection and a user - friendly design to deliver high reliability and ease of use. The projector offers the following features: ® Single chip 0.55" Texas Instruments DLP technology SVGA (800 x 600 pixels) Auto image re-sizing (Auto-Sync.) to 800 x 600 full screen with scaling compression compatibility for VGA, SVGA, XGA* and SXGA* ®... -
Page 5: Package Contents
Package Contents When you unpack the projector, make sure you have all these components: Projector with Lens Cap AC Power Cord VGA Cable (D-SUB to D-SUB) User Manual CD Quick Start Guide Remote Control (IR) Contact you dealer immediately if any items are missing, appear damaged, or if the unit does not work Caution Avoid using the projector in dust environment. -
Page 6: Projector Overview
Projector Overview Front View Tilt-adjustment feet Ventilation holes ((intake) Lens cap Zoom ring Projection lens Focus ring Front IR remote control sensor Control panel Caution Do not touch the lamp cover and exhaust vents during projector usage to prevent from possible burning. Do not looking into the lens or vents while the lamp is on. -
Page 7: Rear View
Rear View Security lock Kensington lock AC power socket Connection ports Ventilation holes (exhaust) Bottom View Ceiling mount Tilt-adjustment feet Lamp cover This projector can be used with a ceiling mount for support. The ceiling mount is not included in the package. Contact your dealer for information to mount the projector on a ceiling. -
Page 8: Using The Product
Using the Product Control Panel Lamp (Lamp LED indicator) Refer to “LED Indicator Messages”. Temp (Temperature LED indicator) Refer to “LED Indicator Messages”. Power LED Refer to “LED Indicator Messages”. Button Function Four directional buttons Use four directional buttons to select items or make adjustments to your selection. Resync Resynchronize the projector to the input signal from a computer. -
Page 9: Connection Ports
Connection Ports RS232 Reserved for installation control and firmware upgrades. COMPUTER IN Connect image input signal (analog RGB or component) to this jack. VIDEO Connect composite video output from video equipment to this jack. MONITOR OUT Connect to a computer display, etc. EN-9 http://www.pureglare.com.au... -
Page 10: Remote Control
Remote Control POWER Turn the projector on or off. Four directional buttons Use four directional buttons to select items or make adjustments to your selection. MENU Display or exit the on-screen display menus. RESYNC Resynchronize the projector to the input signal from a computer. SOURCE Manually select an input source. -
Page 11: Replacing The Battery
Replacing the Battery For the first time use: Remove the transparent insulation tape by pulling it before use. For battery change: Push the catch to the left and remove the battery holder. Remove the old Lithium coin cell and install new one (CR2025). -
Page 12: Remote Control Operation
Remote Control Operation Point the remote control at the infrared remote sensor and press a button. Operating the projector from the front The remote control may not operate when there is sunlight or other strong light such as a fluorescent lamp shining on the remote sensor. Operate the remote control from a position where the remote sensor is visible. -
Page 13: Installation
Installation Connecting the Projector RS-232 Cable Composite Video Cable VGA Cable (D-Sub to D-Sub) VGA (D-Sub) to HDTV (RCA) Cable Laptop type Desktop type When connecting cable, power cords of both projector and external equipment should be disconnected from AC outlet. The figure above is a sample connection. -
Page 14: Powering On/Off The Projector
Powering On/Off the Projector Powering On the Projector: Remove the projector lens cap. Complete the AC power cord and peripheral signal cable(s) connections. Press button on the control panel or the POWER button on the remote control to turn on the projector. The projector takes a minute or so to warm up. -
Page 15: Adjusting The Projector
Adjusting the Projector Adjusting the Projector Height Tilt-adjustment feet The projector is equipped with two tilt-adjustment feet to adjust the image height. To level the image on the screen, turn the tilt-adjustment feet to fine-tune the height. To avoid damaging the projector, make sure that the tilt-adjustment feet are fully retracted before placing the projector in its carrying case. -
Page 16: Adjusting Projection Image Size
Adjusting Projection Image Size Refer to the graphic and table below to determine the screen size and projection distance. 200" 120" 100" 60" 40" Wide: 1.6m Tele: 1.76m Wide: 2.4m Tele: 2.63m Wide: 4m Tele: 4.39m Wide: 4.8m Tele: 5.27m Wide: 8.01m Tele: 8.78m 4 : 3 Screen Screen... -
Page 17: Menu Operation
Menu Operation The projector has multilingual on-screen display menus that allow you to make image adjustments and change a variety of settings. *1 Adjustable range and default setting vary depending on signal type. EN-17 http://www.pureglare.com.au... -
Page 18: How To Operate
How to operate Press the MENU button to open the OSD menu. When OSD is displayed, use to select any feature in the main menu. After selecting the desired main menu feature, press to enter sub-menu for feature setting. Adjust the settings with Press the MENU button, the screen will return to the main menu. - Page 19 Adjust the timing of the projector relative to the computer. Tracking Adjust the phase of the projector relative to the computer. H Position (Horizontal Position) Adjust the image left or right within the projection area. V Position (Vertical Position) Adjust the image up or down within the projection area. Video Image (Video Mode) Saturation Adjust a video image from black and white to fully saturated color.
- Page 20 Auto Source Automatically scan through all the input source. ECO Mode Use this function to dim the projector lamp light output which will lower power consumption and increase lamp life. High Altitude Use this function to allow the fans operates at full speed continuously to achieve proper high altitude cooling of the projector.
-
Page 21: Maintenance
Maintenance The projector needs proper maintenance. You should keep the lens clean as dust, dirt or spots will project on the screen and diminish image quality. If any other parts need replacing, contact your dealer or qualified service personnel. When cleaning any part of the projector, always switch off and unplug the projector first. -
Page 22: Replacing The Lamp
Replacing the Lamp As the projector operates over time, the brightness of the projector lamp gradually decreases and the lamp becomes more susceptible to breakage. We recommend replacing the lamp if a warning message is displayed. Do not attempt to replace the lamp yourself. - Page 23 Turn off the projector. Unplug the power cord. If the projector is installed in a ceiling mount, remove it from the mount. Place a protective sheet (cloth) beneath the projector. Turn the projector over so you can access the lamp cover. Loosen the screw in the lamp cover and remove the cover.
-
Page 24: Specifications
Specifications Display Type Single 0.55" DLP panel Resolution (Pixels) SVGA (800 x 600) Brightness 2000 ANSI Lumens Lens Manual Zoom (1.1x) Screen Size 30” – 300” Lamp 180W Input Source D-Sub 15 pin, composite video, RS232, Output Source D-Sub 15 pin Video Compatibility NTSC 3.58, NTSC4.43 PAL-60, M, N... -
Page 25: Appendix
Appendix LED Indicator Messages Lamp LED Temp LED Power LED Meaning 100% Stand-by mode blinking blue The projector is in good condition. When the Solid blue power button is pressed, the brightness is 100%. After 30 seconds, it turns into 20%. 20% solid The projector is shutting and the fan is cooling Solid red... -
Page 26: Compatibility Modes
Compatibility Modes Computer: Compatibility Resolution H-Sync [KHz] V-Sync [Hz] 640 x 480 31.5 59.9 37.9 72.8 37.5 75.0 43.3 85.0 SVGA 800 x 600 35.2 56.3 37.9 60.3 48.1 72.2 46.9 75.0 53.7 85.1 1024 x 768 48.4 60.0 56.5 70.1 60.0 75.0... -
Page 27: Troubleshooting
Troubleshooting Refer to the symptoms and measures listed below before sending the projector forrepairs. If the problem persists, contact your local reseller or service center. Please refer to "LED Indicator Messages" as well. Start-up problems If no lights turn on: Be sure that the power cord is securely connected to the projector and the other end is plugged into an outlet with power.
