www.actronair.com.au
1800 119 229
The design and specifications are subject to change without prior notice for product
improvement. Consult with the sales agency or manufacturer for details.
C R 03 8-R G 35D
2020550A5693
27052014
last updated 27052014
Before using your air conditioner, please read
this manual carefully and keep it for future reference.
AIR CONDITIONER
REMOTE CONTROLLER
User's Manual
Model Numbers
SWB52C/E
SWB70C/E
SWB82C/E
Read This Manual
Thank you very much for purchasing an ActronAir
air conditioner.
Please read this owner's manual
carefully before using your air conditioner.
Copyright 2014 ActronAir.
©
® Registered Trade Mark of ActronAir [ABN 34 002 767 240]
05/2014.
Advertisement
Table of Contents
Related Manuals for ActronAir SWB52E
Summary of Contents for ActronAir SWB52E
- Page 1 Consult with the sales agency or manufacturer for details. carefully before using your air conditioner. C R 03 8-R G 35D 2020550A5693 27052014 last updated 27052014 Copyright 2014 ActronAir. © ® Registered Trade Mark of ActronAir [ABN 34 002 767 240] 05/2014.
- Page 2 Handling the remote controller CONTENTS Location of the remote controller. Use the remote controller within a distance of 8 Handling the remote controller ............metres from the appliance, pointing it towards the Remote controller specifications ........... receiver. Reception is confirmed by a beep. Function buttons ....
- Page 3 Function buttons ON/OFF Button Remote Controller Specifications Operation starts when this button is pressed and stops when this button is pressed again. Model RG35D // BG(C)EF MODE Button Each time the button is pressed, the operation mode is selected in a sequence of following: 3.0V(Dry batteries 1.5V AAA x 2) Rated Voltage AUTO...
- Page 4 TIMER OFF Button TIMER ON Button Press this button to initiate the auto-off time Press this button to initiate the auto-on time sequence. Each press will increase the auto- sequence. Each press will increase the auto-timed timed setting in 30 minutes increments. When setting in 30 minutes increments.
- Page 5 Indicators on LCD How to use the buttons Auto operation Transmission Indicator The transmission indicator lights when remote Ensure the unit is plugged in and power is controller transmits signals to the indoor unit. ava ilable. T he OPERATION indicator on the Mode display display panel of the indoor unit start s flashing.
- Page 6 Dehumidifying operation Timer operation Press the TIMER ON button to set the auto-on Ensure the unit is plugged in and power is time of the unit. Press the TIMER OFF button available. The OPERATION indicator on t he display panel of the indoor un it starts flashing. to set the auto-off time of the unit.
- Page 7 TIMER OFF CAUTION TIMER OFF (Auto-off Operation) The effective operation time set by the remote controller for the timer function The TIMER OFF feature is useful when you want the is limited to the following settings: 0.5, 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, unit to turn off automatically after you go to bed.
- Page 8 TIMER ON TIMER OFF LED / FOLLOW ME function (Off Start Stop operation) TIMER ON OFF When this button is pressed for less than This feature is useful when you want to start 2 seconds this will initiate the LED function. the air conditioner before you wake up and If this button is pressed for more than 2 seconds, stop it after you leave the house.
