Getting to know the device

Upper hooking hole
Vent
Power-switch
DC power jack
Lower hooking hole
HOBOT-168 shall always connect power cable for normal using.
Make sure the battery was full-charged (green lamp ON) before using.
(1) First, turn off the power-switch on the device. Plug in the power. Orange lamp
ON means charging.
(2) Green lamp ON means the battery was full-charged.
How to put device onto glass to start using
(1) Turn on power-switch, and then make sure the fan is running.
Buzzer
Remote receiving window
Safety rope
- 4 -
Blue lamp: Normal
Red lamp: Abnormal
Orange lamp: charging
Green lamp: full-charged
HOBOT
