P5B Premium Series specifications summary

CPU
Chipset
System Bus
Memory
Expansion Slots
Storage
LAN
Audio
IEEE 1394
USB
ASUS AI Lifestyle
Unique features
LGA775 socket for Intel
Core™2 Extreme / Core™2 Duo / Pentium
Pentium D / Pentium
®
Compatible with Intel
Intel Hyper-Threading Technology ready
®
* Refer to www.asus.com for Intel CPU support list
Intel P965 / ICH8R with Intel
®
Technology
1066 / 800 / 533 MHz
4 x DIMM, max. 8GB, DDR2 800 / 667 / 533 MHz,
non-ECC, un-buffered memory
Dual channel memory architecture
* Refer to www.asus.com or user manual for Memory
QVL (Qualify Vendor List)
2 x PCI-E x16 (blue @ x16 mode, black @ x4 or x2
mode) supports CrossFire technology
1 x PCI-E x1 (x1 or disabled mode)
3 x PCI 2.2
Southbridge
- 6 x SATA 3.0 Gb/s ports
- Intel Matrix Storage Technology supports RAID 0, 1,
5 and 10.
JMicron JMB363 PATA and SATA controller
®
- 1 x UltraDMA 133/100/66 for up to 2 PATA devices
- 1 x Internal SATA 3.0 Gb/s port
- 1 x External SATA 3.0 Gb/s port (SATA On-the-Go)
- Support SATA RAID 0, 1 and JBOD (by 1 x External
SATA and 1 x Internal SATA)
Dual Gigabit LAN controllers, both featuring AI NET2
Marvell PCI-E and PCI Gigabit LAN controllers
®
ADI AD1988B 8-channel High Definition Audio CODEC
®
- Coaxial / Optical S/PDIF out ports at back I/O
TI 1394a controller supports 2 x IEEE 1394a ports (one
®
at midboard; one at back panel)
8 x USB2.0 ports (4 ports at mid-board, 4 ports at back
panel)
ASUS AI Lifestyle Vista Edition Features:
ScreenDUO
AI Remote
ASAP (ASUS Accelerated Propeller)
AP Trigger
TPM Support (The TPM module is purchased separately)
* ScreenDUO, AI Remote, AP Trigger and TPM can run
both in Windows Vista and Windows XP.
* ScreenDUO, AI Remote, ASAP and AP Trigger are for
P5B Premium Vista Edition only.
(continued on the next page)
Core™2 Quad /
®
4 / Celeron D Processors
® ®
05B/05A/06 processors
®
Fast Memory Access
®
Extreme /
®
xi
