If you want to...

Select Near or Far Focus

Note: The Binocular focus knob
does not affect the camera focus.
The camera's focus is determined
by the Focus ring setting:
Near Focus: Use for objects that
are 30 to 60 feet away. Near focus
will capture crisp, sharp images of
nearby objects, especially people.
Far Focus: Use for objects more
than 60 feet away.
1. Press and hold the
Focus Ring
2. The binocular can be focused using
3. To set the Near focus: Position

Near and Far Focus

Do this...
seconds to turn on the camera.
the focus knob. However, the camera
can be set to Near or Far focus using
the focus ring, and is not affected by
the focus knob.
CaptureView so that you are looking
at the front lens and focus ring.
Rotate the focus ring to the "man"
icon. You will feel a click. Continue to
rotate slightly past this point. If you
are unable to rotate the ring to the
left, the camera may already be set
to Near focus.
To set the Far focus: Position the
binoculars so that you are looking at
the front lens and focus ring. Rotate
the focus ring to the "mountain" icon.
You will feel a click. Continue to rotate
slightly past this point. If you are
unable to rotate the ring to the right,
the camera may already be set to Far
focus.
Mode button for 3
13
