How to Use Your Binocular

If you want to...
Adjust Eye Relief
Fold down
Adjust the Barrels
You need to adjust the barrels, as the
distance between your eyes is usually
different than the distance between
another person's eyes.
Barrel
10
Do this...
If you wear eyeglasses, fold down the
rubber eyecups and hold the
eyepieces up against your glasses.
1. Hold CaptureView up to your eyes in
the normal viewing position. Use
both hands to hold each barrel firmly.
2. Pull the barrels apart or push the
barrels together until you see a
single circular field with both of your
eyes.
Barrel
