Installation
ProSAFE 5 Port and 8 port 10/100 Switch
FS105 v3 FS108 v3
Step 1. Connect the equipment.
Computer
Server
FS105 v3
Optional router
Step 2. Connect to power and power on.
OFF/ON switch
Move the OFF/ON switch to the ON
Note:
position to provide power to the device.
Internet
Optional modem
Step 3. Check the status.
Power LED
Port LEDs
On
10/100 Mbps link
Off
Activity (blinking)
No link (off)
Power LED
Port LEDs
On
10/100 Mbps link
Off
Activity (blinking)
No link (off)
Advertisement
Related Manuals for NETGEAR FS105
Summary of Contents for NETGEAR FS105
- Page 1 Step 2. Connect to power and power on. Step 3. Check the status. ProSAFE 5 Port and 8 port 10/100 Switch OFF/ON switch FS105 v3 FS108 v3 Power LED Port LEDs 10/100 Mbps link Move the OFF/ON switch to the ON Note: position to provide power to the device.
- Page 2 NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered June 2014 trademarks of NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. 350 East Plumeria Drive Information is subject to change without notice. © NETGEAR, Inc. All rights reserved.
