Sanyo VPC-E7 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

SERVICE MANUAL

Digital Camera

Contents
1. OUTLINE OF CIRCUIT DESCRIPTION .................... 3
2. DISASSEMBLY ........................................................ 12
3. ELECTRICAL ADJUSTMENT .................................. 17
REGISTRATION ...................................................... 22
5. TROUBLESHOOTING GUIDE ................................. 23
6. PARTS LIST ............................................................. 24
RoHS
•This product does not contain any hazardous substances prohibited by the RoHS Directive.
WARNING
•You are requested to use RoHS compliant parts for maintenance or repair.
•You are requested to use lead-free solder.
(This product has been manufactured using lead-free solder. Be sure to follow the warning given on page 2 when
carrying out repair work.)
The components designated by a symbol ( ! ) in this schematic diagram designates components whose value are of
special significance to product safety. Should any component designated by a symbol need to be replaced, use only the part
designated in the Parts List. Do not deviate from the resistance, wattage, and voltage ratings shown.
CAUTION : Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer's instructions.
NOTE : 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N. S. P. : Not available as service parts.
Design and specification are subject to change without notice.
SX81W/U, EX (R)
PRODUCT SAFETY NOTICE
FILE NO.
VPC-E7
(Product Code : 168 071 00)
(U.S.A.)
(Canada)
(Korea)
(Taiwan)
(General)
VPC-E7EX
(Product Code : 168 071 01)
(Europe)
(U.K.)
(South America)
(China)
(Australia)
(Hong Kong)
(Russia)
(Middle East)
(Africa)
(Korea)
(Taiwan)
(General)
REFERENCE No. SM5310680
