OPERATOR'S
MANUAL
VARIABLE SPEED WOOD LATHE
MODEL: WL-1220VS
Baileigh Industrial, Inc.
P.O. Box 531
Manitowoc, WI 54221-0531
Phone: 920.684.4990
Fax: 920.684.3944
sales@baileighindustrial.com
REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL, INC.
IS PROHIBITED. Baileigh Industrial, Inc. does not assume and hereby disclaims any liability for any damage or loss
caused by an omission or error in this Operator's Manual, resulting from accident, negligence, or other occurence.
Rev. 10/2013
© 2013 Baileigh Industrial, Inc.
Advertisement
Table of Contents
Related Manuals for Baileigh WL-1220VS
Summary of Contents for Baileigh WL-1220VS
- Page 1 REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL, INC. IS PROHIBITED. Baileigh Industrial, Inc. does not assume and hereby disclaims any liability for any damage or loss caused by an omission or error in this Operator’s Manual, resulting from accident, negligence, or other occurence.
-
Page 2: Table Of Contents
Table of Contents THANK YOU & WARRANTY ..................1 INTRODUCTION ......................3 GENERAL NOTES......................3 SAFETY INSTRUCTIONS ....................4 SAFETY PRECAUTIONS ....................6 SPECIFICATIONS ......................9 TECHNICAL SUPPORT ....................9 UNPACKING ......................... 10 GETING TO KNOW YOUR MACHINE ................. 11 ASSEMBLY ........................ - Page 3 Wood Lathe Operation ....................41 PARTS DIAGRAM - SHEET 1 ..................43 PARTS DIAGRAM - SHEET 2 ..................44 Parts List ........................45...
-
Page 4: Thank You & Warranty
THANK YOU & WARRANTY Thank you for your purchase of a machine from Baileigh Industrial. We hope that you find it productive and useful to you for a long time to come. Inspection & Acceptance. Buyer shall inspect all Goods within ten (10) days after receipt thereof. Buyer’s payment shall constitute final acceptance of the Goods and shall act as a waiver of the Buyer’s rights to inspect or... - Page 5 Baileigh Industrial makes every effort to ensure that our posted specifications, images, pricing and product availability are as correct and timely as possible. We apologize for any discrepancies that may occur. Baileigh Industrial reserves the right to make any and all changes deemed necessary in the course of business including but not limited to pricing, product specifications, quantities, and product availability.
-
Page 6: Introduction
After receiving your equipment remove the protective container. Do a complete visual inspection, and if damage is noted, photograph it for insurance claims and contact your carrier at once, requesting inspection. Also contact Baileigh Industrial and inform them of the unexpected occurrence. Temporarily suspend installation. -
Page 7: Safety Instructions
IMPORTANT PLEASE READ THIS OPERATORS MANUAL CAREFULLY It contains important safety information, instructions, and necessary operating procedures. The continual observance of these procedures will help increase your production and extend the life of the equipment. SAFETY INSTRUCTIONS LEARN TO RECOGNIZE SAFETY INFORMATION This is the safety alert symbol. - Page 8 SAVE THESE INSTRUCTIONS. Refer to them often and use them to instruct others. PROTECT EYES Wear safety glasses or suitable eye protection when working on or around machinery. DUST HAZARD Wear appropriate dust mask. Dust created while using machinery can cause cancer, birth defects, and long term respiratory damage.
-
Page 9: Safety Precautions
SAFETY PRECAUTIONS Wood working can be dangerous if safe and proper operating procedures are not followed. As with all machinery, there are certain hazards involved with the operation of the product. Using the machine with respect and caution will considerably lessen the possibility of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator may result. - Page 10 SAFETY PRECAUTIONS (cont.) 11. Sanding Polishing. Remove the tool rest before performing polishing or sanding operations. 12. Keep work area clean. Cluttered areas invite injuries. 13. Overloading machine. By overloading the machine you may cause injury from flying parts. DO NOT exceed the specified machine capacities. 14.
- Page 11 SAFETY PRECAUTIONS (cont.) 27. Keep children away. Children must never be allowed in the work area. DO NOT let them handle machines, tools, or extension cords. 28. Know the location of the ON - OFF switch and the “E”- STOP button. 29.
-
Page 12: Specifications
SPECIFICATIONS 12” (304.8mm) Swing Over Bed 9.4” (238.76mm) Swing Over Tool Rest 20” (508mm) Maximum Distance Between Centers 3” (76.2mm) Inboard Face Plate Diameter 13” (330mm) Distance - Beanch Top to Spindle Centerline 1”, 8TPI, RH thread Inboard Spindle 3/4”, 16TPI, LH thread Outboard Spindle Headstock Spindle Taper Tailstock Spindle Taper... -
Page 13: Unpacking
UNPACKING Remove lathe from the shipping cartons. Check for damage and ensure all parts are intact. Any damage should be reported immediately to your distributor and shipping agent. Before assembling, read the manual thoroughly, familiarizing yourself with correct assembly and maintenance procedures and proper safety precautions. -
Page 14: Geting To Know Your Machine
GETING TO KNOW YOUR MACHINE Outboard Tool Rest Mount Fig 1 Spindle Handwheel Headstock Faceplate Spur Center Tool Rest Tool Rest Lock Handle Tool Rest Base Live Center Quill Lock Handle Tailstock Quill Handwheel Tailstock Release Lever Leveling Foot Lathe Bed Tool Rest Base Release Lever Motor Belt Tension Lock Handle... -
Page 15: Assembly
ASSEMBLY WARNING: For your own safety, DO NOT connect the machine to the power source until the machine is completely assembled and you read and understand the entire instruction manual. Before use, the tool rest must be moved out of its shipping position and centers must be inserted. -
Page 16: Installation
INSTALLATION IMPORTANT: Consider the following when looking for a suitable location to place the machine: Overall weight of the machine. Weight of material being processed. Sizes of material to be processed through the machine. Space needed for auxiliary stands, work tables, or other machinery. ... -
Page 17: Mounting
Mounting Once you have confirmed that your machine is running properly, you may decide to mount it to a workbench. Remove the adjustable feet and mount it through the holes in the base. The strongest mounting option is a "Through Mount" where holes are drilled all the way through the workbench, and hex bolts, washers, and hex nuts are used to secure the machine to the workbench. -
Page 18: Electrical
ELECTRICAL CAUTION: HAVE ELECTRICAL UTILITIES CONNECTED TO MACHINE BY A CERTIFIED ELECTRICIAN! Check if the available power supply is the same as listed on the machine nameplate. WARNING: Make sure the grounding wire (green) is properly connected to avoid electric shock. DO NOT switch the position of the green grounding wire if any electrical plug wires are switched during hookup. -
Page 19: Extension Cord Safety
Use only 3-wire extension cords that have grounding type plugs and receptacles that accept the tool’s plug. Repair or replace damaged or worn cord immediately. Extension Cord Safety Extension cord should be in good condition and meet the minimum wire gauge requirements listed below: LENGTH AMP RATING... -
Page 20: Electrical Diagram
ELECTRICAL DIAGRAM... -
Page 21: Initial Startup
INITIAL STARTUP Once the setup is complete, test run your machine to make sure it runs properly and is ready for regular operation. This procedure should be used when ever the machine has been moved, repaired, out of service for and extended period of time, or when a new operator is becoming familiar with the machine. - Page 22 7. Remove the switch lockout key (C). 8. Try to turn the start the machine by lifting the paddle switch (B) with the lockout key removed. If the machine does not start, the switch lockout feature is working as designed. ...
-
Page 23: Basic Controls
BASIC CONTROLS This manual describes the basic operation of this machine and is no substitute for training and experience. If you have never used this type of machine or equipment before, IT IS STRONGLY RECOMMEND that you get formal training from an experienced lathe operator, read books, or trade magazines, before beginning any projects. -
Page 24: Changing Speed Ranges
CHANGING SPEED RANGES The variable speed motor allows the spindle speed to vary within three separate ranges. For greater speed variations, the belt in the headstock can be repositioned. A label on the top of the headstock illustrates the belt positions and their speeds. 1. -
Page 25: Live Center Removal And Installation
5. Move the belt tension lever down, adjusting tension so that when the belt is pressed with moderate force, 1/2" of belt deflection is measured (D). Then tighten belt tension lever screw. 6. Close the rear covers. Fig 12 LIVE CENTER REMOVAL AND INSTALLATION 1. -
Page 26: Adjusting Tailstock
ADJUSTING TAILSTOCK The tailstock is equipped with a cam-action clamping system to secure it to the lathe bed. When the lever is engaged, a locking plate lifts and secures the tailstock to the bed. 1. Verify the ON/OFF switch is OFF and the Lockout Key is REMOVED. -
Page 27: Spur Center Removal And Installation
SPUR CENTER REMOVAL AND INSTALLATION The spur center installs into the headstock spindle with a taper fit. 1. Unplug or disconnect lathe from power source and lock out power. 2. Insert the tapered end of the center into the spindle, and push it in quickly and firmly. -
Page 28: Faceplate Removal And Installation
FACEPLATE REMOVAL AND INSTALLATION Removal 1. Unplug or disconnect lathe from power source and lock out power. 2. If installed, remove the spur center. 3. Hold the headstock spindle wheel (A) securely and turn the faceplate (B) counterclockwise until it is removed. -
Page 29: Outboard Turning
Outboard Turning This lathe is equipped with a detachable outboard turning attachment. This provides additional clearance for a greater variety of turning tasks. Follow the Faceplate mounting instructions to mount a workpiece to the spindle handwheel for outboard turning. The method for attaching a workpiece to the spindle is the same for both turning methods. -
Page 30: Operation
OPERATION The following directions will give the inexperienced operator a beginning point for common lathe operations. Practice on scrap material before attempting serious work. CAUTION: Always wear proper personal protection equipment, including but not limited to, safety eye protection with side shields, face shield, safety footwear, and leather gloves to protect from, chips, dust, burrs, and slivers. - Page 31 • Skew Chisel—A very versatile tool that can be used for planing, squaring, V-cutting, beading, and parting off. The skew chisel is flat, double- ground with one side higher than the other (usually at an angle of 20-40˚). Figure 25 shows an example of a skew chisel.
-
Page 32: Spindle Turning
SPINDLE TURNING Working with any material that is attached to the lathe centers is called a spindle turning. This is the principal type of wood turning (chair and table legs, lamp stems, etc.) The turning of spindles can be done with either a scraping or cutting technique. The cutting technique, by virtue of faster wood removal and a cleaner surface, is the preferred method. - Page 33 The diagonal method, Fig. 29, consists of drawing lines from corner to corner, with the intersection marking the center of the work. Fig 29 After marking each end, mark the true center with a punch awl or dividers (Fig. 30). If the stock is hardwood, the centers should be drilled to a depth of about 1/8”.
-
Page 34: Tool Rest Position
Tool Rest Position Mount the tool rest in place about 1/8” away from the work and 1/8” above the work centerline (Fig. 33). This position may be varied to suit the work and the operator. Place a guide mark on the tool rest shank as an aid to quick and accurate resetting. -
Page 35: Position Of Hands
1. The tool may be advanced along the work either from right to left or from left to right. Left to right (from headstock to tailstock) is preferred since this action throws chips clear of the operator. 2. The gouge is rolled over slightly in the same direction it is advancing. 3. -
Page 36: Smoothing A Cylinder
Smoothing a Cylinder To smooth a cylinder, use a large skew chisel. This requires practice, but experience with this tool is very important. Place the cutting point near the center of chisel and high on the work (Fig. 39). Sometimes, in striving for a certain position in relation to the work, the beginner will often overlook this all-important point. -
Page 37: Faceplate Turning
FACEPLATE TURNING Faceplate turning is when a workpiece is mounted to the faceplate, which is mounted to the headstock spindle. This type of turning is usually done with open- faced workpieces such as bowls. Fig. 41. If screws cannot be placed into the workpiece, then a backing block must be glued to the workpiece and attached to the faceplate with screws. -
Page 38: Maintenance
MAINTENANCE WARNING: Make sure the electrical disconnect is OFF before working on the machine. Maintenance should be performed on a regular basis by qualified personnel. Always follow proper safety precautions when working on or around any machinery. Maintenance on your lathe should be done at periodic intervals to ensure that the machine is in good working order. -
Page 39: Lubrication
Lubrication Lubricate the locations shown (A) in Figure 43 with light machine oil. Fig 43... -
Page 40: Changing Belt
CHANGING BELT Removal 1. Unplug or disconnect lathe from power source and lock out power. 2. Loosen the belt tension lock lever (A). Be sure the belt tension lever (B) moves freely to release tension from the belt. 3. Open the rear access covers (C). Fig 44 4. -
Page 41: Installation
Installation 1. Place the new belt over the spindle pulley. 2. Slide the spindle back through the headstock and into the original position. A mallet may be required. 3. Install the headlock spindle handwheel and tighten both set screws (D). 4. -
Page 42: Motor Service
Motor Service Keep the motor as clean as possible. Prevent any water, oil, or wood chips from entering inside the motor housing. Be sure to clean the machine after every use. The bearings inside the motor are shielded and lubricated for the life of the bearing and require no routine maintenance. -
Page 43: Troubleshooting
TROUBLESHOOTING WARNING: Make sure the electrical disconnect is OFF before working on the machine. Motor & Electrical Symptom Possible Cause Possible Solution 1. Test for good contacts; correct the wiring. 2. Ensure hot lines have correct voltage on 1. Plug/receptacle is at fault or all legs and main power supply is switched wired incorrectly. -
Page 44: Wood Lathe Operation
Wood Lathe Operation Symptom Possible Cause Possible Solution Vibration noise while machine 1. If necessary, install a soft, vibration is running; 1. Belt cover loose. dampening material between the belt cover noise changes and the headstock casting. when speed is changed. - Page 45 Symptom Possible Cause Possible Solution 1. Tailstock mounting bolt loose. 1. Tighten. Tailstock 2. Too much clamping pressure 2. Apply less clamping pressure with moves. applied by tailstock. tailstock. 3. Bed surface is oily or greasy. 3. Clean bed surface to remove oil/grease. Spindle RPM 1.
-
Page 46: Parts Diagram - Sheet 1
PARTS DIAGRAM - SHEET 1... -
Page 47: Parts Diagram - Sheet 2
PARTS DIAGRAM - SHEET 2... -
Page 48: Parts List
Parts List Item Description Specification Qty. Spindle Handwheel Set Screw 1/4"-20UNC x 1/4" Ball Bearing 6004 Wavy Washer BWW-6302 Collar Sensor Ring Round Head Screw 3/16"-24UNC x 5/8" Wire Clip ACC-2.5 Hex Nut 3/16"-24UNC Set Screw M4 x 0.7P x 6 Headstock Cap Screw M4 x 0.7P x 8... - Page 49 Item Description Specification Qty. Tailstock Lock Handle Assembly 5/16"-18UNC-15L S-Ring STW-10 Handle Bolt Tailstock Handwheel Cranks Bolt Clamp Lock Nut M10 x 1.5P Tailstock Lock Handle Assembly 5/16"-18UNC-20L Tool Rest 6" Turret Seat Bushing S-Ring STW-12 Locking Handle Clamp Bolt Large Handle Assembly 3/8"-16UNC-1"L Flat Washer...
- Page 50 Item Description Specification Qty. Lathe Bed Tooth Washer 5.3 x 10 x 0.6T (BW-5) Round Head Screw 3/16"-24UNC x 7/8" Digtal Display Switch Box Assembly 110V,61HZ/VR (CSA/UL) 63.1 Digital Display Board 110VVR 63.2 Box Switch 63.3 Switch Box Plate 63.4 Safety Switch 63.5 Switch Box Cover 63.6 Wire Protector 10 x 14 x 3.5...
- Page 51 NOTES...
- Page 52 , WI 54220 UFEK RIVE ANITOWOC : 920. 684. 4990 F : 920. 684. 3944 HONE BAILEIGHINDUSTRIAL BAILEIGH INDUSTRIAL, INC. 1455 S. C , CA 91761 AMPUS VENUE NTARIO : 920. 684. 4990 F : 920. 684. 3944 HONE BAILEIGH INDUSTRIAL LTD. U...
