Mobily BB@work NTC-30 Series Installation Manual

Outdoor industrial router
Hide thumbs Also See for BB@work NTC-30 Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
Powering your Router
The outdoor router can be powered via DC power supply or Power over Ethernet (PoE).
DC power option
Business
Your router is provided with a waterproof DC jack allowing it to be powered by a 9~28V DC power
supply.
1. On the bottom interface panel of the router, locate the DC power port and unscrew the
protective cap to expose the connection pins.
2. Connect the DC power jack as shown below to the DC power port of the router and turn the
metal securing ring clockwise while pushing the conector in to secure the DC jack in position.
3. At the other end of the cable, wire the red (positive +) and black (grounding) wires to your
9~28V DC power supply source.
Installation Guide
Power
NTC-30 Series - Outdoor Industrial Router
2
www.linkedin.com/company/mobily
BB@work
Industrial Router
1
Pin
Signal
1
2
GND
:‫ﺗﺎﺑﻌﻮﻧﺎ ﻋﻠﻰ‬
Description
V+
Voltage+
Ground
04
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BB@work NTC-30 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mobily BB@work NTC-30 Series

Summary of Contents for Mobily BB@work NTC-30 Series

  • Page 1 3. At the other end of the cable, wire the red (positive +) and black (grounding) wires to your 9~28V DC power supply source. Installation Guide Power NTC-30 Series - Outdoor Industrial Router Signal Description Voltage+ Ground :‫ﺗﺎﺑﻌﻮﻧﺎ ﻋﻠﻰ‬ www.linkedin.com/company/mobily...

  • Page 3: Table Of Contents

    Contents Package Contents Package Contents Let’s get started Let’s get started Powering your Router Powering your Router Picking the best spot for Installation Picking the best spot for Installation Connecting via Ethernet Connecting via Ethernet Configure the Router Configure the Router Connecting Wirelessly Connecting Wirelessly Wall mounting your Outdoor Industrial Router...

  • Page 4: Package Contents

    Outdoor Industrial Router Package Contents a l l e r , i n t t i o t i v i t i h i l r i n u r i ITEM INTERFACE Router WiFi Antennas 3G Antennas Mounting Bracket i t i Set of wall mounting screws Set of mounting screws...

  • Page 5: Let's Get Started

    Powering your Router Let’s get Started The outdoor router can be powered via DC power supply or Power over Ethernet (PoE). SIM Card Installation DC power option 1. Remove the protective cap labelled SIM/Reset with a flathead screwdriver. Your router is provided with a waterproof DC jack allowing it to be powered by a 9~28V DC power NOTE: If you don’t have a flathead screwdriver or you’re having problems, a small coin will do the supply.
  • Page 6 Installing the Antenna 1. Remove the black protective caps from the Wi-Fi and 3G connectors. a l l e r , i n t t i o t i v 2. Each of the antennas are labelled 3G and Wi-Fi for easy installation. Connect the corresponding antenna to the antenna connectors by holding onto the metal part of the antenna and rotating it clockwise.

  • Page 7: Powering Your Router

    Powering your Router Powering your Router Pole Mounting Your Outdoor Industrial Router Make sure you have your included mounting bracket, mounting bracket screws and hose clamps. The outdoor router can be powered via DC power supply or Power over Ethernet (PoE). The outdoor router can be powered via DC power supply or Power over Ethernet (PoE).

  • Page 8: Picking The Best Spot For Installation

    Picking the best spot for installation 1. At this point your Outdoor Industrial Router is ready to be installed on the outside of your property, however before doing so, you will need to find the best location. 2. To get the strongest signal your Outdoor Industrial Router should ideally be placed towards your nearest 3G tower.

  • Page 9: Connecting Via Ethernet

    Powering your Router Installing Your Router Outside Your Outdoor Industrial Router can be mounted directly onto a wall or a pole. For wall mounting The outdoor router can be powered via DC power supply or Power over Ethernet (PoE). instructions see page 15, for pole mounting instructions see page 17. DC power option Connecting Via Ethernet Your router is provided with a waterproof DC jack allowing it to be powered by a 9~28V DC power...
  • Page 10 3. Plug the Ethernet cable into the RJ-45 connector and tighten the cable gland to ensure the seal is adequate. Use a shifter or spanner to ensure IP67 rating. a l l e r , i n t t i o t i v Connecting the Ferrite Core 1.

  • Page 11: Connecting The Ethernet Cable

    Powering your Router Connecting the Ethernet Cable 1. Remove the protective cap labelled Ethernet with a flathead screwdriver or a small coin. The outdoor router can be powered via DC power supply or Power over Ethernet (PoE). DC power option Your router is provided with a waterproof DC jack allowing it to be powered by a 9~28V DC power supply.
  • Page 12 3. Slide the cable gland towards the Ethernet port. You may need to loosen the bottom part of the cable gland so you can move it. a l l e r , i n t t i o t i v 4.

  • Page 13: Configure The Router

    Powering your Router Configure the Router The outdoor router can be powered via DC power supply or Power over Ethernet (PoE). Step 1: Access Router’s Homepage DC power option Your outdoor router’s homepage can be accessed by using the web address via default IP address http://192.168.1.1 or alternatively via URL http://my.router.
  • Page 14 Step 2: Unlock the SIM If the SIM card is locked you will need to unlock it with the appropriate PIN code. You can find out if the SIM is locked by viewing the SIM Status at the bottom of the Status page.
  • Page 15 Powering your Router Step 3: Connect to Internet Your router should automatically connect to the Internet if the SIM status reads SIM OK. If it does The outdoor router can be powered via DC power supply or Power over Ethernet (PoE). not, follow the steps listed below to setup the Mobile Broadband connection.

  • Page 16: Connecting Wirelessly

    Verify Connection Status Click on the Status link to return to the status page. The WWAN Status should be Up. The IP Address field shows the current IP address that the network has allocated for the router. a l l e r , i n t t i o...

  • Page 17: Wall Mounting Your Outdoor Industrial Router

    Powering your Router Wall Mounting Your Outdoor Industrial Router The outdoor router can be powered via DC power supply or Power over Ethernet (PoE). Locate your mounting bracket, mounting bracket screws, wall mount screws, and grey wall plugs. DC power option 1.
  • Page 18 7. Insert the 4 grey wall plugs into the wall. a l l 8. Mount the mounting bracket horizontally to the back of the Outdoor Industrial Router with the e r , i n t mounting bracket screws. t i o t i v i t i h i l...

  • Page 19: Pole Mounting Your Outdoor Industrial Router

    Powering your Router Pole Mounting Your Outdoor Industrial Router Make sure you have your included mounting bracket, mounting bracket screws and hose clamps. The outdoor router can be powered via DC power supply or Power over Ethernet (PoE). 1. Before you start make sure all cables have been disconnected from your Outdoor Industrial Router and that your antenna have been attached and your SIM card is inserted.
  • Page 20 4. Straighten out the end of the hose clamps and slide them through the rectangular holes in the mounting bracket. a l l e r , i n t t i o t i v 5. Wrap the metal strap around the pole. 6.

  • Page 21: Get To Know Your Outdoor Industrial Router Better

    Powering your Router Get to know your Outdoor Industrial Router better The outdoor router can be powered via DC power supply or Power over Ethernet (PoE). DC power option Your router is provided with a waterproof DC jack allowing it to be powered by a 9~28V DC power supply.
  • Page 22 a l l e r , i n t t i o t i v Mounting Bracket Height 290 mm Length 110 mm Depth 12 mm Weight 410 g i t i h i l r i n u r i i t i 3G AND WiFi Height...

  • Page 23: What It All Means

    Powering your Router What it all means The outdoor router can be powered via DC power supply or Power over Ethernet (PoE). The Outdoor Industrial Router has 7 LEDs to display the current system and connection status. DC power option Your router is provided with a waterproof DC jack allowing it to be powered by a 9~28V DC power supply.

  • Page 24: Powering Your Router (Poe)

    Powering your Router Power Over Ethernet option Please Note: If you choose to use PoE to power your router, we recommend you purchase an outdoor rated RJ45 Ethernet cable Remove the protective cap labelled Ethernet with a flathead screwdriver or coin. a l l e r , i n t...
  • Page 25 Powering your Router Slide the cable gland towards the Ethernet port. You may need to loosen the bottom part of the cable gland so you can move it. The outdoor router can be powered via DC power supply or Power over Ethernet (PoE). DC power option Your router is provided with a waterproof DC jack allowing it to be powered by a 9~28V DC power supply.
  • Page 26 Connect the other end of the cable to the PWR + DATA OUT Port on the Power over Ethernet adaptor. a l l Connect the power adaptor to the DC IN Power port on the Power over Ethernet Adaptor. e r , i n t t i o t i v...
  • Page 27 Powering your Router The outdoor router can be powered via DC power supply or Power over Ethernet (PoE). DC power option Your router is provided with a waterproof DC jack allowing it to be powered by a 9~28V DC power supply.
