ming length:
3. Begin trimming your beard using smooth, even
strokes. Start with your sideburns and work downward
toward your chin. (Never attempt to trim against the
natural growth of your beard because the hair will be
cut too short.)
4. If you decide you want a closer trim, you can now
adjust the 10-position comb attachment to a shorter
setting (such as 5.5mm or 6mm) and go over your
beard again until you achieve the desired length.
blendIng the JawlIne
1. The three jawline attachments will help you to
achieve a neat, finished trim under your chin. To use
one of the attachments, press it down over the trimmer
blades until it clicks into position.
2. Hold the trimmer in an upright position and begin
trimming under your jawline, using short, even
strokes.
3. After your beard is blended, turn off the trimmer and
remove the attachment by gently pulling up on tab.
to trIm your muStache
1. For best results, start
with a clean, slightly damp
mustache.
2. Comb through your
mustache in the direction
it grows.
3. Place the 10-position comb over the facial hair blade
and snap it into position. It is a good idea to start with
the longest trim setting adjustment. (You can always
go back and cut your mustache more closely with a
shorter setting.)
alwayS trIm your muStache
from the top down
4. After your mustache has been trimmed to the desired
length, remove the 10-position comb and, using the
blades only, define the outline of the bottom of your
mustache.
5. Use the 8mm Switchcut™
detailing blade for fine detail-
ing and hair art.
to trIm your goatee and
other precISIon trImmIng
For precision trimming of tight areas, you will need to
use the 8mm detailing blade.
1. Remove any guide comb that may be attached to the
trimmer.
2. With the power on or off, simply slide the top button
forward to change from the main trimming blade to
the 8mm detailing blade. This easy motion disen-
gages the trimmer blade and activates the detailing
blade.
3. Trim goatee or any other tight areas.
4. When precision trimming is completed, slide the
button back and the detailing blade retracts.
5. The trimmer blade is now ready to use again.
on /off SwItch
To operate, simply slide switch
toward blade, to stop push slide
away from blade.
care of your
trI mmer
replacement (removal) of
blade Set
To remove blade set from your trimmer, make sure the
trimmer is in the OFF position. Remove the blade set by
placing thumb against the smaller cutter and pushing
forward, releasing the cutter assembly from the trim-
mer housing. Replace with shaver foil attachment and
reverse the removal procedure, only this time place your
thumb on the large cutter and snap into place. Make
sure the taper control is set to the longest #1 position.
battery removal
CONTAINS NICKEL METAL
HYDRIDE BATTERY. MUST BE
COLLECTED, RECYCLED OR
DISPOSED OF PROPERLY.
DO NOT DISPOSE OF IN
THE MUNICIPAL WASTE.
1. Pop-off decorative plate on bottom housing.
2. Using a small Phillips head screwdriver, remove
the two screws at the back of the trimmer.
3. Remove the bottom housing and flip it over to
remove the four screws in the battery cover. Bring
the batteries to the nearest collection center for
proper disposal. DO NOT throw the battery into the
normal municipal waste system.
