- Page 1 User Manual...
-
Page 2: Table Of Contents
Sound-Active Mode ..........................10 Automatic Mode ............................10 Master/Slave Mode ..........................10 Footswitch Operation ..........................11 5. Technical Information ....................12 Product Maintenance ........................12 6. Technical Specifications ....................13 Returns ............................14 Contact Us ........................14 Page 2 of 14 4BAR™ User Manual (Rev. 6) -
Page 3: Before You Begin
Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection. For other issues, such as missing components or parts, damage not related to shipping, or concealed damage, file a claim with Chauvet within 7 days of delivery. Text Convention Meaning 1–512... -
Page 4: Product At A Glance
· Keep this User Manual for future use. If you sell the product to another user, be sure to give this document to the next owner. Page 4 of 14 4BAR™ User Manual (Rev. 6) -
Page 5: Introduction
Microphone Fuse Holder Connection Sound Sensitivity Power In Adjustment Knob Back Panel View Clamp Hanging Bolts Pan Angle Adjustment Knobs (4) Tripod Insertion Point Tilt Angle Front View Adjustment Knob Dimensions 4BAR™ User Manual (Rev. 6) Page 5 of 14... -
Page 6: Setup
3. S ETUP AC Power The 4BAR™ has an auto-ranging power supply and it can work with an input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 7: Mounting
Before mounting the product, read and follow the safety recommendations indicated in Safety Notes. Orientation The 4BAR™ may be mounted in any position; however, make sure adequate ventilation is provided around the product. · Rigging Before deciding on a location, always make sure there is easy access to the product for maintenance and programming. -
Page 8: Operation
DMX mode uses. If you choose a starting address that is too high, you could restrict the access to some of the product’s channels. The 4BAR™ uses up to 15 DMX channels in single DMX mode, which defines the highest configurable address to 498. -
Page 9: Dmx Channel Modes, Assignments, And Values
Green 4 Pod 4 000 ó 255 Blue 4 (0–100%) Blue 4 Channel Function Value Setting 3-CH 000 ó 255 0–100% 000 ó 255 0–100% Green 000 ó 255 0–100% Blue 4BAR™ User Manual (Rev. 6) Page 9 of 14... -
Page 10: Standalone
Master/Slave The Master/Slave mode allows a single 4BAR™ unit (the “master”) to control the actions of one or more 4BAR™ units (the “slaves”) without the need of a DMX controller. The Mode master unit will be set to operate in either Automatic or Sound Active mode, while the slave units will be set to operate in Slave Mode. -
Page 11: Footswitch Operation
9 x press Color change every 3 seconds in a continuous loop Sound-activated (Sound) The 4BAR™ footswitch will work properly in any mode. No settings need to be modified before using the footswitch. 4BAR™ User Manual (Rev. 6) Page 11 of 14... -
Page 12: Technical Information
When cleaning units with one or more movable mirrors, you should keep the contact with the mirror’s surface to a minimum to avoid scratching or damaging it. Always dry the external optics and transparent surfaces carefully after cleaning them. Page 12 of 14 4BAR™ User Manual (Rev. 6) -
Page 13: Technical Specifications
Maximum External Temp. Cooling System 104 °F (40 °C) Convection I/O Connectors Connector Type Channel Range 3-pin XLR Sockets 3 or 15 Ordering Product Name Item Code Item Number 4BAR™ 03030047 4BAR 4BAR™ User Manual (Rev. 6) Page 13 of 14... -
Page 14: Returns
