Summary of Contents for Chauvet Core par UV
- Page 1 User Manual...
-
Page 2: Table Of Contents
ABLE OF ONTENTS 1. Before You Begin ......................3 What Is Included ..........................3 Unpacking Instructions ........................3 Claims ..............................3 Text Conventions ..........................3 Symbols ............................3 Disclaimer ............................3 Product at a Glance ........................4 Safety Notes ............................ 4 2. -
Page 3: Before You Begin
Useful information. Disclaimer Chauvet believes that the information contained in this manual is accurate in all respects. However, Chauvet assumes no responsibility and specifically disclaims any and all liability to any party for any loss, damage or disruption caused by any errors or omissions in this document, whether such errors or omissions result from negligence, accident or any other cause. -
Page 4: Product At A Glance
Product at a Use on Dimmer Auto Programs Outdoor Use Auto-ranging Power Supply Glance Sound-Active Replaceable Fuse User-Serviceable Master/Slave Safety Notes Please read the following Safety Notes carefully before working with the product. The Notes include important safety information about installation, usage, and maintenance. ·... -
Page 5: Introduction
2. I NTRODUCTION Product Overview Mounting Brackets IR Sensor Bracket Adjustment Knob Front View LCD Display D-Fi USB Port Power In Menu Buttons Fuse holder Safety Cable Pass Power Out DMX In DMX Out Through Back Panel View WARNING! DO NOT plug anything other than a D-Fi USB into the USB port. Doing so may cause damage to the product. -
Page 6: Product Dimensions
Product Dimensions 10 in 253 mm 5.5 in 139 mm 7.9 in 200 mm Page 6 of 19 COREpar UV USB User Manual Rev. 1... -
Page 7: Setup
3. S ETUP Fresnel Lens This Fresnel lens produces a very even light that is soft at the edges, which makes the COREpar UV USB a 2-in-1 light. Attach the Fresnel lens easily with the built-in magnets. Magnetic Fresnel Lens AC Power The COREpar UV USB has an auto-ranging power supply and it can work with an input voltage range of 100 to 240 VAC, 50/60 Hz. -
Page 8: Power Linking
The power linking diagram corresponds to the North American version of the product ONLY! If using the product in other markets, you must consult with the local Chauvet distributor as power linking connectors and requirements may differ in your country or region. -
Page 9: Mounting
The bracket adjustment knobs allow for directional adjustment when aiming the product to the desired angle. Only loosen or tighten the bracket knobs manually. Using tools could damage the knobs. Safety Cable (such as CH-05 from Chauvet) Mounting Clamp (such as the CLP-15N from Chauvet) -
Page 10: Operation
4. O PERATION Control Panel To access the control panel functions, use the four buttons located underneath the display. Please refer to the Product Overview to see the button locations on the control panel. Operation Button Function <MENU> Exits from the current menu or function <UP>... -
Page 11: Dmx Linking
The COREpar UV USB is able to become a D-Fi wireless receiver/transmitter with the D-Fi USB use of the D-Fi USB from Chauvet DJ. Simply set the product's DMX Personality and Connectivity DMX Address, set the DIP switch D-Fi receiving/transmitting channel, then plug it into the D-Fi USB port. -
Page 12: Dmx Personality And Starting Address
DMX Personality When selecting a starting DMX address, always consider the number of DMX channels the selected DMX mode uses. If you choose a starting address that is too high, you could and Starting restrict the access to some of the product’s channels. Address The COREpar UV USB uses up to 5 DMX channels in a 5-CH DMX mode, which defines the highest configurable address to 508. -
Page 13: Configuration (Standalone)
Configuration Set the product in one of the standalone modes to control without a DMX controller. Connect the product to a suitable power outlet. (Standalone) Never connect a product that is operating in any standalone mode to a DMX string connected to a DMX controller. -
Page 14: Irc-6 Infrared Remote Control
The COREpar UV USB is compatible with the IRC-6 infrared remote control from IRC-6 Infrared Chauvet. To activate IR mode, follow the instructions below: Remote Press <MENU> repeatedly until SEr shows on the display. Control Press <ENTER> to accept. Press <UP> or <DOWN> to select On or OFF. -
Page 15: Master/Slave Mode (Wired)
Master/Slave The Master/Slave mode allows a single COREpar UV USB product (the “master”) to control the actions of one or more COREpar UV USB products (the “slaves”) without the Mode need of a DMX controller. The master product will be set to operate in either Stand-Alone (wired) mode or with the IRC-6, while the slave products will be set to operate in Slave mode. -
Page 16: Maintenance
5. M AINTENANCE Product Dust build-up reduces light output performance and can cause overheating. This can lead to reduction of the light source’s life and/or mechanical wear. To maintain optimum Maintenance performance and minimize wear, clean your lighting products at least twice a month. However, be aware that usage and environmental conditions could be contributing factors to increase the cleaning frequency. -
Page 17: Technical Specifications
6. T ECHNICAL PECIFICATIONS Dimensions and Length Width Height Weight Weight 5.5 in (139 mm) 7.9 in (200 mm) 10 in (253 mm) 4.6 lb (2.1 kg) Note: Dimensions in inches rounded to the nearest decimal digit. Power Supply Type Range Voltage Selection Power... -
Page 18: Returns
If you are located in Mexico, contact Chauvet Mexico. · If you are located in Benelux, contact Chauvet Europe BVBA. · If you are located in any other country, DO NOT contact Chauvet. Instead, contact your local distributor. See www.chauvetlighting.com for distributors outside the U.S., UK, Ireland, Mexico, or Benelux. -
Page 19: Contact Us
(954) 577-4455 Email: tech@chauvetlighting.com Fax: (954) 929-5560 World Wide Web Toll free: (800) 762-1084 www.chauvetlighting.com EUROPE General Information - Chauvet Europe BVBA Technical Support Address: Stokstraat 18 Email: Eutech@chauvetlighting.eu 9770 Kruishoutem Belgium World Wide Web Voice: +32 9 388 93 97 www.chauvetlighting.eu...
