  • Page 1 Avaya Installation Guide P112T 24-P TACKABLE THERNET ORKGROUP WITCH...

  • Page 3: Safety Precautions

    SICHERHEITSVORKEHRUNG ACHTUNG – ZUR VERHINDERUNG DES RISIKOS VON ELEKTRISCHEM SCHLAG UND FEUER 1. Die Geräte enthalten keine Bauteile, die außerhalb des Avaya Servicezentrums gewartet oder repariert werden können. Die Wartung darf NUR von qualifiziertem, technischem Personal durchgeführt werden. 2. NIEMALS ein beschädigtes Gerät einschalten, oder versuchen es zu bedienen.
  • Page 4 Stromzufuhr wo sich auch der Sicherungskasten befindet. 5. Bedienen Sie das Gerät NICHT an einer Stelle an der die Umgebungstemperatur 50ºC übersteigt. 6. Ziehen Sie das Netzkabel raus, BEVOR Sie versuchen die Hauptsicherung zu kontrollieren oder auszutauschen. P112T Stackable Switch Installation Guide...
  • Page 5 A stack of two or more switches requires a P110 NMA management agent. The P112T Stackable Switch has a set of services which ensure zero data loss. An automatic fairness mechanism ensures that all ports gain fair access to the P110 Exoplane even at very high network utilization.
  • Page 6 Chapter 1 Overview P112T Stackable Switch Installation Guide...

  • Page 7: Installation

    To install the P110 NMA, refer to its Installation Guide. Stacking Operation To make the P112T work as part of a stack (and to give SNMP management capabilities to a single P112T), a P110 NMA with the correct software version is required.
  • Page 8 Once you have downloaded the new software, set the port to disabled again and then reconnect the cable. 4. Place the P112T in the stack. The P110 NMA must be in the top switch of the stack. To ensure proper ventilation, ensure that all empty P110 NMA slots in the stack are closed.

  • Page 9: Chapter 2 Hub Installation

    8. Connect the fiber-optic cables to the front panel ports. If the P110 NMA in the stack contains the correct software version (as specified in the P112T Stackable Switch Release Note) or higher, the stack is now fully operational. When a new version of the P110 NMA software becomes available, you should perform software download to benefit from the extra capabilities provided.

  • Page 10: Rack Mounting

    4. Connect the Exoplane cables, as described above, and as illustrated in Figure 1. 5. Snap closed the hinged ends of the front panel. Figure 2 P110 rack mounting arrangement P112T Stackable Switch Installation Guide...
  • Page 11 Chapter 2 Hub Installation Diagnostics The following tables explain the meaning of the P112T Stackable Switch Select and Reset button and diagnostic LED indicators. Figure 3 – The P112T Stackable Switch front panel LEDs and buttons PWR NMA Table 1...
  • Page 12 Data Received © 2003 Avaya Inc. All rights reserved. All trademarks identified by the ® or TM are registered trademarks or trademarks, respectively, of Avaya Inc. All other trademarks are the property of their respective owners. Document number: 130001 Rev. A...
