Scanning Photos
1. Raise the TMA 1600-III and place the photo to
be scanned face down on the scanner glass
surface, towards the front of the scanner. Then,
put the Black Plate on top of the photo to
cover it, with the side of the Black Plate that
reads "This side up" facing up. Follow the
procedures on page 18 for how to position
reflective originals and use the Black Plate.
2. Launch ScanWizard Pro either as a standalone
by clicking the program icon, or by using the File-Import or File-Acquire command
from your image-editing program (such as Adobe Photoshop). Alternatively, you
can start ScanWizard Pro from the Applications folder in your Mac OS X system.
3. Go to the Preview window of ScanWizard Pro, and choose Reflective from the
Scan Material menu.
4. Optional: If calibration has been performed, go to the Settings window in
ScanWizard Pro. Choose the profile you have just created in the Input Profile /
Scanner Profile menu.
5. Click the Overview button to perform a preliminary scan of the image, which will
appear in the Preview window.
6. Select the Scan Frame tool from the Toolbar in the Preview window, and choose
the area to be scanned by dragging a rectangle around it. You will see a flashing
frame (marquee) around the selected area.
7. Click the Prescan button to display a detailed image of area selected by the
Scan Frame tool. A thumbnail of the image appears as well in the Scan Job
Queue window.
8. Specify your scanning requirements in the Settings window.
a) Select a desired image type.
b) Select a desired resolution.
c) Adjust the scan frame settings if necessary.
9. Adjust image quality if necessary, using the Advanced Image Correction (AIC) tools.
10. If the colors in your photo are faded and need restoring, check the "Automatic
Color Restoration" box in the Settings window.
ArtixScan 3200XL User Guide
27
