2. Place the photo to be scanned on the scanner glass surface.
3. Go to the Preview window of ScanWizard Pro, and choose Reflective from the
4. Optional: If calibration has been performed, go to the Settings window in
5. Click the Overview button to perform a preliminary scan of the image, which will
6. Select the Scan Frame tool from the Toolbar in the Preview window, and choose
7. Click the Prescan button to display a detailed image of area selected by the
8. Specify your scanning requirements in the Settings window.
9. Adjust image quality if necessary, using the Advanced Image Correction (AIC) tools.
10. If the colors in your photo are faded and need restoring, check the "Automatic
24 ArtixScan 3200XL User Guide
a) Raise the TMA 1600-III.
b) Use the red arrows printed on
the vertical rulers of both
sides of the scanner as an
alignment guide and then
place your photo face down
on the scanner glass surface,
towards the front of the
scanner.
c) Put the Black Plate on top of
the photo to cover it, with the
side of the Black Plate that
reads "This side up" facing
up. Follow the procedures on
page 18 for how to position
reflective originals and use the Black
Plate.
Scan Material menu.
ScanWizard Pro. Choose the profile you have just created in the Input Profile /
Scanner Profile menu.
appear in the Preview window.
the area to be scanned by dragging a rectangle around it. You will see a flashing
frame (marquee) around the selected area.
Scan Frame tool. A thumbnail of the image appears as well in the Scan Job
Queue window.
a) Select a desired image type.
b) Select a desired resolution.
c) Adjust the scan frame settings if necessary.
Color Restoration" box in the Settings window.
Calibration strip
(Keep clear and
unobstructed)
