Note:
• Before clicking the "Calibrate" button, make sure firmly that the TMA has been
• The calibration will take you amounts of time (approx. 10 minutes). Therefore,
• If you update the firmware to a new version, you have to redo the scanner
Notice to WIA Users
Before using the WIA (Windows Image Acquisition) scanning driver to scan, you should put the U-shaped
Ruler on the scanner glass surface, which ensures that your scanner will function properly. For more
details about how to position the U-Shaped Ruler on the scanner glass surface, see the "Using the U-
shaped Ruler" section in this manual.
20 ArtixScan 3200XL User Guide
connected properly with your scanner, the U-shaped Ruler (Calibration Ruler)
has been put on the scanner glass surface correctly, and the scanner glass
surface has been kept clear.
please be patient while the scanner is calibrating.
calibration for optimal images. Before recalibrating your scanner, the
calibration data made with the U-shaped Ruler (Calibration Ruler) should be
removed from your system. Using one of the following two methods to remove the
calibration data:
A. Switch to the folder "C:\Program Files\Microtek\ScanWizard Pro\Scanners"
(where C:\ is your ScanWizard Pro location), then delete the calibration
data Calidata91_ xxxxxxxxxx.dat, Calidata2191_ xxxxxxxxxx.dat or
Calidata219b_ xxxxxxxxxx.dat from the folder.
B. Reset all calibration data.
1) Launch ScanWizard Pro. In the Preview window, select "Calibration
Settings" from the Preferences menu.
2) Set the Calibration Mode as "Smart", and then click the "Execute"
button next to the "Reset All Calibration Data" to reset all calibration
data. The calibration data file saved in "C:\Program
Files\Microtek\ScanWizard Pro\Scanners" folder will be removed
automatically.
When done, launch ScanWizard Pro, you will be invited to calibrate the scanner
again. Follow the on-screen instructions to calibrate your scanner.
