Assembly

WARNING
Do not plug in your deep cleaner until you are familiar with all instructions
and operating procedures.
Your deep cleaner
comes in four
easy-to-assemble
components and
an accessory bag.
1
First, insert
the upper
handle at the
top of the
base until you
hear a "click".
3
Using a Phillips screwdriver,
secure the carry handle with
the screw that's taped to the
upper handle.
• Base
• Upper Handle
• Clean Water Tank
• Carry Handle
click
4
Wrap the cord around
the carry handle and quick
release hook.
The only tool you will need to assemble
your deep cleaner is a Phillips screwdriver.
2
Side
View
Next, align the carry handle with the slots
on either side of the base (behind the
power switch and cleaning mode switch).
The carry handle will "click" into place.
5
Side
View
At the bottom of the
upper handle, align the
clean water tank with
the grooves and slide
the tank into place.
www.BISSELL.com
