Dimplex DCF7850 Owner's Manual

Hide thumbs Also See for DCF7850:

Advertisement

Quick Links

Download this manual See also: Service Manual
Owner's Manual
Model Number:
DCF7850
Serial Number
Model Number
Part Number
Valued Customer,
Thank you and congratulations for purchasing a Dimplex
electric stove. Over the years, valuable memories will
occur around the warmth and comfort of your stove.
Thank you for allowing our product to be the backdrop
for those special
moments.
Quality checked by:
7207770100rev04

Advertisement

loading

Related Manuals for Dimplex DCF7850

Summary of Contents for Dimplex DCF7850

  • Page 1 Model Number Part Number Valued Customer, Thank you and congratulations for purchasing a Dimplex electric stove. Over the years, valuable memories will occur around the warmth and comfort of your stove. Thank you for allowing our product to be the backdrop for those special moments.
  • Page 2 (see page If you have any technical questions or concerns regarding the operation of your Corner Standing Stove, or require service contact Dimplex North America customer service at 1-888-DIMPLEX (1-888-346-7539) before returning the product to the point of...

  • Page 3: Table Of Contents

    CONTENTS Important Instructions ....PAGE 4 Model and Serial Number Information PAGE 6 Installation ..... . . PAGE 6 Operation .

  • Page 4: Important Instructions

    IMPORTANT INSTRUCTIONS Retain this User’s Guide for Future Reference When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1. Read all instructions before using the Corner Standing Stove. 2. The heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.

  • Page 5: Save These Instructions

    (one blade is wider than the other). The plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any way. Avoid the use of an extension cord. Extension cords may overheat and cause a risk of fire. If you must use an extension cord, the cord must be No. 14 AWG minimum size and rated no less than 1875 Watts. 15. Do not burn wood or other materials in the Corner Standing Stove. 16.

  • Page 6: Model And Serial Number Information

    Model and Serial Number Information If you have any questions about our products please have the catalogue/model and serial numbers available upon calling customer service. To locate the catalogue/model and serial number labels see below (Figure 1). Figure 1 Model Number Serial Number Rating Label Installation...
  • Page 7 building codes and other applicable regulations to reduce the risk of fire, electric shock and injury to persons. Do not attempt to wire your own new outlets or circuits. To reduce the risk of fire, electric shock or injury to persons, always use a licensed electrician. Securing Cord (Figure 2) Figure 2 Securing Strap Power cord View from back Stabilizing Strap The Corner Standing Stove is designed to fit tightly into the corner of a room.
  • Page 8 Figure 3 Wall Anchor ⅛” (3mm) hole in wall Safety Strap Bolt Figure 4 Support hole Figure 5 Safety Strap...

  • Page 9: Operation

    The controls (Figure 7) are located inside the door panel on the lower side of the Corner Standing Stove (Figure 6). Figure 6 Door Panel EMSC Models DCF7850 Models Figure 7 A. Main On/Off Switch The switch has two ON positions marked with “ ” and “ Manual ”.
  • Page 10 The “ ” position is for operating the unit with the provided remote control. When in “ ” position the unit is operated with the ON and OFF buttons of the remote control. When the switch is in the center “ O ”position the unit is off. B.
  • Page 11 ON/OFF Switch to OFF and waiting 5 minutes before switching the unit back on. CAUTION: If you need to continuously reset the heater, unplug the unit and call Dimplex North America Limited at 1-888-346-7539. NOTE: The heater may emit a slight, harmless odor when first used. This odor is a normal condition caused by initial heating of...

  • Page 12: Maintenance

    Maintenance WARNING: Disconnect power before attempting any maintenance or cleaning to reduce the risk of fire, electric shock or damage to persons. Light Bulb Replacement Allow at least five (5) minutes for light bulbs and heater to cool off before touching bulbs to avoid accidental burning of skin. Light bulbs need to be replaced when you notice a dark section of the flame or when the clarity and detail of the log exterior disappears.

  • Page 13: Glass Cleaning

    Figure 9 Screw Bottom of unit Rear Door Glass Cleaning The front glass is cleaned in the factory during the assembly operation. During shipment, installation, handling, etc., the front glass may collect dust particles, these can be removed by dusting lightly with a clean dry cloth.

  • Page 14: Warranty

    Dimplex surrounds (mantels) and trims covered by this limited warranty have been tested and inspected prior to shipment and, subject to the provisions of this warranty, Dimplex warrants such products to be free from defects in material and workmanship for a period of 1 year from the date of first purchase of such products. Warranty services do not include in-home services.
  • Page 15 If Dimplex is unable to repair or replace such product or part, or if repair or replacement is not commercially practicable or cannot be timely made, Dimplex may, in lieu of repair or replacement, choose to refund the purchase price for such product or part.
  • Page 16 Such costs shall not be the responsibility of Dimplex. • On-site or in-home services not provided under this warranty may be performed at the purchaser’s specific request and expense at Dimplex’s then-current rates for...
