- Page 1 0.9 cu. ft. Microwave Oven MCD990WF / MCD990BF Instruction Manual So Right at Home. Never operate the oven when it is empty or without the glass turntable. Before operating this oven, please read these instructions completely.
-
Page 2: Table Of Contents
ONE TOUCH COOKING ... 13 AUTO COOK ... 14 LESS, MORE... 15 CHILD SAFETY LOCK ... 15 TO STOP THE OVEN WHILE THE OVEN IS OPERATING ... 15 CARE OF YOUR MICROWAVE OVEN ...16 BEFORE YOU CALL FOR SERVICE ...17 CARE AND CLEANING ...17... -
Page 3: Important Safety Instructions
Use extreme care when inserting a spoon or other utensil into the container. 18. Do not use this microwave oven to heat corrosive chemicals (for example, sulfides and chlorides). Vapors from such corrosive chemicals may interact with the contact and springs of the safety interlock switches thereby rendering them inoperable. -
Page 4: Federal Communications Commission Radio Frequency Interference Statement
• Relocate the Microwave oven with respect to the receiver. • Move the microwave oven away from the receiver. • Plug the microwave oven into a different outlet so that microwave oven and receiver are on different branch circuits. THE MANUFACTURER is not responsible for any radio or TV interference caused by UNAUTHORIZED MODIFICATION to this microwave oven. -
Page 5: Installation
6. Power supply. This microwave oven requires a power supply of approximately 15 Amperes, 120 Volts, 60Hz and a grounded outlet. A short power cord is provided to reduce the risk of the user becoming entangled in or tripping over a longer cord. -
Page 6: Specifications
SPECIFICATIONS POWER SUPPLY POWER CONSUMPTION MICROWAVE OUTPUT POWER FREQUENCY OUTSIDE DIMENSIONS (W X H X D) CAVITY DIMENSIONS (W X H X D) CAVITY VOLUME NET WEIGHT TIMER POWER LEVELS * Specifications are subject to change without notice. 495 mm (19.5 in.) 120V AC 60 Hz SINGLE PHASE WITH GROUNDING 1350 W 900 W... -
Page 7: Features Diagram
FEATURES DIAGRAM 1. Door latch-When the door is closed it will automatically shut off. If the door is opened while the oven is operating, the magnetron will automatically shut off. 2. Door seal-The door seal maintains the microwave within the oven cavity and prevents microwave leakage. - Page 8 FEATURES DIAGRAM (continued) 10. Time set pad-Used to set the cooking time and the present time. 11. Display-Cooking time, power level, indicators and present time are displayed. 12. One touch-Used to cook or reheat specific quantities of food. 13. Auto Cook-Used to cook or reheat. 14.
-
Page 9: Operation Procedure
OPERATION PROCEDURE This section includes useful information about oven operation. 1. Plug power supply cord into a standard 3-pronged 15 Amp, 120V AC 60Hz power outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking. -
Page 10: Controls
CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash “:0” and a tone will sound. If the AC power ever goes off, the display shows “ : 0” when the power comes back on. 1. -
Page 11: Weight Defrosting
WEIGHT DEFROSTING AUTO DEFROST lets you easily defrost food by eliminating guesswork in determining defrosting time. Follow the steps below for easy defrosting. 1. Touch MEAT pad. MEAT 2. Select the desired defrosting weight. (Refer to the weight defrost chart below.) 3. -
Page 12: Cooking In One Stage
COOKING IN ONE STAGE 1. Touch POWER pad. POWER (Select the desired power level.) 2. Touch the time set pads for the cooking time. 3. Touch START pad. When you touch START pad, the M/W indicator starts blinking to show the oven is cooking. The display counts down the time to show how much cooking time is left. -
Page 13: Kitchen Timer Mode
KITCHEN TIMER MODE Timer operates as a minute timer, can be set to delay cooking and used to set a holding time after cooking. However delay cooking can not be programmed for defrost. Timer operates without microwave energy. HOW TO USE AS A MINUTE TIMER 1. -
Page 14: Speedy Cook
SPEEDY COOK SPEEDY COOK allows you to reheat for 30 seconds at full power by simply touching the SPEEDY COOK pad. By repeatedly touching the SPEEDY COOK pad, you can also extend reheating time to 5 minutes by 30 second increments. 1. -
Page 15: Auto Cook
ONE TOUCH COOKING (continued) 1. Touch DINNER PLATE pad once DINNER for 12 oz of dinner plate or twice for PLATE 15 oz of dinner plate. * DINNER PLATE * • 12 oz : Touch DINNER PLATE pad once. • 15 oz : Touch DINNER PLATE pad twice within 1.5 seconds. AUTO COOK AUTO COOK allows you to cook or reheat many of your favorite foods by repeatedly touching auto cook pad. -
Page 16: Less, More
LESS, MORE To alter one touch cooking or cooking time while oven is in operation, use LESS or MORE.(except for defrosting) Touch LESS/MORE pad to decrease/increase the one touch cooking time in multiples of 10 seconds. The overall one touch cooking time can be increased to a maximum of 59 minutes 50 seconds. Touch LESS/MORE pad to decrease/increase the cooking time in multiples of 1 minute. -
Page 17: Care Of Your Microwave Oven
Control Panel. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may occur when the microwave oven is operated under high humidity conditions and in no way indicates malfunction of the unit. -
Page 18: Before You Call For Service
BEFORE YOU CALL FOR SERVICE • The oven doesn’t work : 1. Check that the power cord is securely plugged 2. Check that the door is firmly closed. 3. Check that the cooking time is set. 4. Check for a blown circuit fuse or tripped main circuit breaker in your house. -
Page 19: Microwave Oven Warranty
Microwave Oven Warranty MC Appliance Corporation warrants each new Microwave Oven to be free from defects in material and workmanship and agrees to remedy any such defect or to furnish a new part(s) (at the company’s option) for any part(s) of the unit that has failed during the warranty period. Parts and labor expenses are covered on this unit for a period of one year after the date of purchase.
