- Page 1 MICROWA VE OVEN MCD991R OPERATING INSTRUCTIONS & COOK BOOK Before operating this oven, please read these instructions completely.
- Page 2 Product Registration Copy Thank you for purchasing a Magic Chef product. The first step in protecting your new product is to complete the product registration form on our website at www.mcappliance.com/register. The benefits of registering your product include the following.
-
Page 3: Table Of Contents
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances, basic safety precautions should be followed, including the following: WARNING-To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: 1. Read all instructions before using the appliance. cord, or shut off power at the fuse or circuit breaker panel. -
Page 5: Federal Communications Commission Radio Frequency Interference Statement
FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: This equipment generates and uses ISM frequency energy and if not installed and used properly, that is in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception. It has been type-tested and found to comply with limits for an ISM Equipment pursuant to part 18 of FCC Rules, which are designed to provide reasonable protection against such interference in a residential installation. -
Page 6: Installation
INSTALLATION 1. Examine the oven after unpacking. Check for damage such as a misaligned door, broken door or dent in the cavity. If any damage is visible, DO NOT INSTALL, and notify your dealer immediately. 2. Level, flat location. Install the microwave oven on a level, flat surface. 3. -
Page 7: Specifications
SPECIFICATIONS POWER SUPPLY 120V AC, 60Hz SINGLE PHASE WITH GROUNDING INPUT POWER 1350 W MICROWAVE ENERGY OUTPUT 900 W FREQUENCY 2,450MHz OUTSIDE DIMENSIONS (W 18.3 x 11.0 x 14.8 in. (465 x 280 x 375 mm) CAVITY DIMENSIONS (W 12.4 x 9.3 x 13.6 in. (314 x 235 x 346 mm) CAVITY VOLUME 0.9 cu.ft (26 Liters) NET WEIGHT... -
Page 8: Features Diagram
FEATURES DIAGRAM 1 Door latch-When the door is closed it will 6 Glass cooking tray-Made of special heat resistant automatically shut off. If the door is opened while glass. The tray can be easily removed for cleaning. the oven is operating, the magnetron will Make sure it is correctly positioned (indentation) automatically shut off. -
Page 9: Features Diagram (Continued)
FEATURES DIAGRAM (continued) 1 Display - Cooking time, power level, indicators and 8 Up/Down - Used to set weight of food. current time are displayed. 9 TIME SET PAD - Used to set the cooking time and 2 Auto cook - Used to cook or reheat many of the current time. -
Page 10: Operation Procedure
OPERATION PROCEDURE This section includes useful information about oven operation. Plug power supply cord into a standard 3-pronged Time clock returns to the present time when the 12 Amp, 120V AC 60Hz power outlet. cooking time ends. After placing the food in a suitable container, When the STOP/CLEAR pad is touched during the open the oven door and put it on the glass tray. -
Page 11: Controls
CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will show “:0” and a tone will sound. If the AC power ever goes off, the display show “ : 0” when the power comes back on. 1. -
Page 12: Defrosting Automatically
DEFROSTING AUTOMATICALLY To thaw frozen food, set the weight of the food and the microwave automatically sets the defrosting time, power level. 1. Touch the AUTO DEFROST pad to set the item. Touch the AUTO DEFROST pad repeatedly to select the item you want. (Refer to the AUTO DEFROST chart below) 2. -
Page 13: Setting Cooking Times & Power Levels
SETTING COOKING TIMES & POWER LEVELS 1. Touch the Power level pad to set the power level. Touch the Power level pad repeatedly to select the power level you want. 2. Touch the Time set pad to set the cooking times. You can set the time up to 59 minutes 99 seconds. -
Page 14: Auto Cook
AUTO COOK 1. Touch the AUTO COOK pad to set the item. Touch the AUTO COOK pad repeatedly to select the item you want. (Refer to the AUTO COOK chart below) 2. Touch the Up/Down pad to set the weight of the food. 3. -
Page 15: Quick Defrost
QUICK DEFROST Use this function to thaw only 1.0lb of minced meat very quickly. This will require a standing time to allow the center to thaw. 1. Touch the Quick defrost pad to set defrosting. 2. Touch the START pad to start defrosting quickly. The oven calculates the defrosting time. -
Page 16: Beverage
BEVERAGE 1. Touch the Beverage pad. The display shows “A--1”. 2. Touch the Up/Down pad to select the quantity of food from 1 cup to 3 cups. (200ml/cup) 3. Touch the START pad to start cooking. FROZEN MEAL 1. Touch the Frozen meal pad. The display shows “A--2”. -
Page 17: Child Safety Lock
CHILD SAFETY LOCK The safety lock prevents unwanted oven operation such as by small children. To set, touch and hold the STOP/CLEAR pad for 3 seconds, a beep sounds. To cancel, touch and hold the STOP/CLEAR pad for 3 seconds, a beep sounds. DISPLAY OFF. -
Page 18: Care Of Your Microwave Oven
CARE OF YOUR MICROWAVE OVEN The oven should be cleaned regularly and any food deposits removed. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation. Turn the oven off before cleaning. -
Page 19: Before You Call For Service
BEFORE YOU CALL FOR SERVICE Refer to following checklist, you may prevent an unnecessary service call. * The oven doesn’t work : * Sparking in the cavity; 1. Check that the power cord is securely plugged in. 1. Check utensils. Metal containers or dishes with 2. -
Page 20: Questions And Answers
QUESTIONS AND ANSWERS * Q : I accidentally ran my microwave oven without * Q : What does “standing time” mean? any food in it. Is it damaged? A : “Standing time” means that food should be removed A : Running the oven empty for a short time will not from the oven and covered for additional time to damage the oven. -
Page 21: Cooking Instructions
COOKING INSTRUCTIONS Utensil Guide Only use utensils that are suitable for use in microwave ovens. To cook food in the microwave oven, the microwaves must be able to penetrate the food, without being reflected or absorbed by the dish used. Care must therefore be taken choosing the utensil. If the utensil is marked microwave- safe, you do not need to worry. -
Page 22: Use Your Microwave Oven Safely
USE YOUR MICROWAVE OVEN SAFELY General Use Do not attempt to defeat or tamper with safety Do not operate the oven if door seals or sealing interlocks. surfaces are damaged; or if door is bent; or if hinges Do not place any object between the oven front frame are loose or broken. -
Page 23: Microwave Oven Warranty
MC Appliance corp. Model Parts Labor Magnetron (Part Only) Type of Service MCD991R One-Year One-Year Eight-Year Carry In For Service or Assistance please call 888 775-0202 Or visit us on the web at www.macppliance.com...
